Janelia Fluor® 549, NHS ester
Tocris Bioscience | Catalog # 6147
Key Product Details
Description
Alternative Names
Wavelength
Product Description
Key Information:Janelia Fluor® 549, NHS ester is a yellow fluorescent dye; supplied with an NHS ester reactive group for the labeling of primary amines. Suitable for live cell imaging.
Application: Suitable for flow cytometry, confocal microscopy, super resolution microscopy (SRM) including dSTORM and STED. Janelia Fluor® 549, NHS ester is cell permeable.
Properties and Photophysical Data: NHS ester can be converted to relevant substrate for use in self-labeling tag systems, e.g. HaloTag® and SNAP-tag®. Excitation and emission maxima (λ) are 549 nm and 571 nm, respectively; quantum yield = 0.88; extinction coefficient = 101,000 M-1cm-1; A280 correction factor = 0.169; lactone-zwitterion equilibrium constant (KL-Z) = 3.5.
Please see the protocol for further information on protein/antibody labeling and conjugation.
We also offer custom conjugation antibody services.
HaloTag® is a registered trademark of Promega Corporation, and SNAP-tag® is a registered trademark of New England BioLabs, Inc.
Janelia Fluor® is a registered trademark of Howard Hughes Medical Institute.
This product has been recently renamed. The previous name for this product was Janelia Fluor® 549, SE.
Scientific Data Images for Janelia Fluor® 549, NHS ester
Application of Janelia Fluor® 549, NHS ester in Cardiac Tissue.
An adult pig heart tissue section, 10 μm thick, labelled with abs against SERCA2ATPase, exhibits the intricate structure of the sarcoplasmic reticulum. A super-resolution image (top), obtained by exploiting spontaneous photo-switching of JF549 (dSTORM), shows superior detail to the diffraction limited widefield image (bottom). Scale: 200 nm. Image kindly provided by Prof. Christian Soeller, University of Exeter; acquired by Alex Clowsley and Anna Meletiou.
Application of Janelia Fluor® 549, NHS ester in Cardiac Tissue.
A single isolated Wistar rat cardiomyocyte stained against alpha -actinin, displaying its periodic structure localised at the ends of sarcomeres (Z-discs). Widefield fluorescence of JF549 (left), prior to illuminating with a 561 nm laser to induce photoswitching and produce a dSTORM super-resolution image (right). Scale: 1 μm. Image kindly provided by Prof. Christian Soeller, University of Exeter; acquired by Alex Clowsley and Anna Meletiou.
Application of Janelia Fluor® Dyes in Cardiac Tissue.
Widefield fluorescence image of muscle tissue from an adult pig heart, displaying the distribution of collagen VI in the interstitial space between muscle cells. The sample was labelled with a primary ab against collagen VI and a secondary ab conjugated to JF549, NHS ester. Scale: 50 μm. Image kindly provided by Prof. Christian Soeller, University of Exeter; acquired by Alex Clowsley and Anna Meletiou.Licensing Information
Sold under license from the Howard Hughes Medical Institute, Janelia Research CampusOptical Data
| Emission Color | Yellow |
| Brightness | |
| λabs | 549 nm |
| λem | 571 nm |
| Extinction Coefficient (ε) | 101,000 M-1cm-1 |
| Quantum Yield (φ) | 0.88 |
| Closest Laser line | 532 nm |
| Reactive Group | NHS ester |
| Reactivity | Primary amines |
| Cell Permeable | Yes |
| Correction Factor 280 | 0.169 |
| Application | Confocal Microscopy, Flow Cytometry, Super Resolution Microscopy, dSTORM, STED |
| Alternative For | Alexa Fluor® 546, Alexa Fluor® 555, BDY TMR-X, Atto 550, CF 555, TAMRA, Cyanine 3 |
Trademarks and registered trademarks are the property of their respective owners.
Spectra Viewer
Plan Your Experiments
Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.
Spectra Viewer
Product Specifications for Janelia Fluor® 549, NHS ester
Molecular Weight
Formula
Storage
Chemical Name
CAS Number
PubChem ID
InChI Key
SMILES
The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.
Solubility
| Solvent | Max Conc. mg/mL | Max Conc. mM | |
|---|---|---|---|
| Solubility | |||
| DMF | 55.16 | 100 | |
| DMSO | 55.16 | 100 |
Preparing Stock Solutions for Janelia Fluor® 549, NHS ester
The following data is based on the product molecular weight 551.56.
Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which all affect the solvent volumes required to prepare stock solutions.
| Concentration / Solvent Volume / Mass | 1 mg | 5 mg | 10 mg |
|---|---|---|---|
| 1 mM | 1.81 mL | 9.07 mL | 18.13 mL |
| 5 mM | 0.36 mL | 1.81 mL | 3.63 mL |
| 10 mM | 0.18 mL | 0.91 mL | 1.81 mL |
| 50 mM | 0.04 mL | 0.18 mL | 0.36 mL |
Calculators
Background References
References are publications that support the biological activity of the product. See our Citations tab to view 17 publications citing the usage of this product.
- Zheng Rational design of fluorogenic and spontaneously blinking labels for super-resolution imaging. ACS Cent.Sci. 2019 PMID: 31572787
- Legant High-density three-dimensional localization microscopy across large volumes. Nat.Methods 2016 PMID: 26950745
- Deng CASFISH: CRISPR/Cas9-mediated in situ labeling of genomic loci in fixed cells. Proc.Natl.Acad.Sci.USA. 2015 PMID: 26324940
- Knight Dynamics of CRISPR-Cas9 genome interrogation in living cells. Science 2015 PMID: 26564855
- Grimm A general method to improve fluorophores for live-cell and single-molecule microscopy. Nat.Methods 2015 PMID: 25599551
