Human Siglec-1/CD169 Antibody

R&D Systems | Catalog # AF5197

R&D Systems

Key Product Details

Species Reactivity

Validated:

Human

Cited:

Human

Applications

Validated:

Western Blot, Neutralization

Cited:

Immunohistochemistry, Immunohistochemistry-Paraffin, Flow Cytometry

Label

Unconjugated

Antibody Source

Polyclonal Sheep IgG
Loading...

Product Specifications

Immunogen

Mouse myeloma cell line NS0-derived recombinant human Siglec‑1/CD169
Ser20-Gln1641
Accession # Q9BZZ2

Specificity

Detects human Siglec‑1/CD169 in direct ELISAs and Western blots.

Clonality

Polyclonal

Host

Sheep

Isotype

IgG

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.

Scientific Data Images for Human Siglec-1/CD169 Antibody

Detection of Human Siglec‑1/CD169 by Western Blot.

Western blot shows lysates of SH‑SY5Y human neuroblastoma cell line and human lymph node. PVDF membrane was probed with 0.5 µg/mL of Sheep Anti-Human Siglec‑1/CD169 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF5197) followed by HRP-conjugated Anti-Sheep IgG Secondary Antibody (HAF016). A specific band was detected for Siglec‑1/CD169 at approximately 180-200 kDa (as indicated). This experiment was conducted under reducing conditions and using Western Blot Buffer Group 1.
Cell Adhesion Mediated by Siglec‑1/CD169 and Neutralization by Human Siglec‑1/CD169 Antibody.

Cell Adhesion Mediated by Siglec‑1/CD169 and Neutralization by Human Siglec‑1/CD169 Antibody.

Recombinant Human Siglec-1/CD169 Fc Chimera (Catalog # 5197-SL), immobilized onto a microplate, supports the adhesion of human red blood cells in a dose-dependent manner (orange line). Adhesion elicited by Recombinant Human Siglec-1/CD169 Fc Chimera (5 µg/mL) is neutralized (green line) by increasing concentrations of Sheep Anti-Human Siglec-1/CD169 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF5197). The ND50 is typically 1.5-7.5 µg/mL.
Detection of Siglec-1/CD169 by Immunohistochemistry

Detection of Siglec-1/CD169 by Immunohistochemistry

Confirmation of novel SSM markers in regional lymph nodes from head and neck cancer patients with multiplex immunohistochemistry. (A) Sequential staining for Hematoxylin (left), CD169, CD16A and CD64 on same lymph node section shows the co-localization of the three markers. Of note, CD169+ macrophages in closer proximity to the sub-capsular sinus were also positive for CD16A and CD64. (B) Sequential staining for Hematoxylin (left), CD169, CD16A and MMP14 on same lymph node section shows the co-localization of the three markers. N = 2; Representative pictures are shown. Image collected and cropped by CiteAb from the following open publication (https://pubmed.ncbi.nlm.nih.gov/34168645), licensed under a CC-BY license. Not internally tested by R&D Systems.

Applications for Human Siglec-1/CD169 Antibody

Application
Recommended Usage

Western Blot

0.5 µg/mL
Sample: SH‑SY5Y human neuroblastoma cell line and human lymph node

Neutralization

Measured by its ability to neutralize Siglec‑1/CD169-mediated adhesion of human red blood cells. Kelm, S. et al. (1994) Current Biology 4:965. The Neutralization Dose (ND50) is typically 1.5-7.5 µg/mL in the presence of 5 µg/mL Recombinant Human Siglec‑1/CD169 Fc Chimera.

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.


Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Calculators

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: Siglec-1/CD169

Siglecs are sialic acid specific I-type lectins that belong to the immunoglobulin superfamily. Structurally, they are transmembrane proteins with an N-terminal Ig-like V‑set domain followed by varying numbers of Ig-like C2-set domains (1, 2). Human Siglec-1, also known as sialoadhesin and CD169, is a 175‑185 kDa glycoprotein. It contains a 1622 amino acid (aa) extracellular domain (ECD) with one Ig-like V‑set domain and 16 Ig-like C2-set domains, a 21 aa transmembrane segment, and a 44 aa cytoplasmic domain (3). Within the ECD, human Siglec-1 shares approximately 70% aa sequence identity with mouse and rat Siglec-1. Alternate splicing generates a potentially soluble form of the ECD, and a second isoform with a substituted cytoplasmic domain. Siglec-1 expression is restricted to lymph node and splenic macrophages, plus some tissue macrophages (3). The adhesive function of Siglec-1 is supported by the N-terminal Ig-like domain which shows a selectivity for alpha 2,3‑linked sialic acid residues (3‑5). Siglec-1 binds a number of sialylated molecules including the mannose receptor, MGL1, MUC1, PSGL-1, and different glycoforms of CD43 (6‑9). Its binding capacity can be masked by endogenous sialylated molecules (10, 11). The sialylated and sulfated N-linked carbohydrates that modify Siglec-1 itself are required for ligand binding (6, 7). Siglec-1 is expressed on dendritic cells following rhinovirus exposure, and these DC promote T cell anergy (12). It is also induced on circulating monocytes during systemic sclerosis and HIV-1 infection (13‑15). Siglec-1 can trap HIV-1 particles for trans infection of permissive cells (14).

References

  1. Varki, A. and T. Angata (2006) Glycobiology 16:1R.
  2. Crocker, P.R. et al. (2007) Nat. Rev. Immunol. 7:255.
  3. Hartnell, A. et al. (2001) Blood 97:288.
  4. Nath, D. et al. (1995) J. Biol. Chem. 270:26184.
  5. Crocker, P.R. et al. (1991) EMBO J. 10:1661.
  6. Martinez-Pomares, L. et al. (1999) J. Biol. Chem. 274:35211.
  7. Kumamoto, Y. et al. (2004) J. Biol. Chem. 279:49274.
  8. Nath, D. et al. (1999) Immunology 98:213.
  9. van den Berg, T.K. et al. (2001) J. Immunol. 166:3637.
  10. Nakamura, K. et al. (2002) Glycobiology 12:209.
  11. Barnes, Y.C. et al. (1999) Blood 93:1245.
  12. Kirchberger, S. et al. (2005) J. Immunol. 175:1145.
  13. York, M.R. et al. (2007) Arthritis Rheum. 56:1010.
  14. Rempel, H. et al. (2008) PloS ONE 3:e1967.
  15. van der Kuyl, A.C. et al. (2007) Plos ONE 2:e257.

Long Name

Sialic Acid Binding Ig-like Lectin 1

Alternate Names

CD169, Siglec1

Entrez Gene IDs

6614 (Human); 20612 (Mouse); 311426 (Rat)

Gene Symbol

SIGLEC1

UniProt
