Evans Blue tetrasodium salt

Tocris Bioscience | Catalog # 0845

Dye for assessing cell viability and blood brain barrier permeability; also EAAT inhibitor and iGluR antagonist
Tocris Bioscience

Key Product Details

Description

Dye for assessing cell viability and blood brain barrier permeability; also EAAT inhibitor and iGluR antagonist
View all Glutamate (EAAT) Transporter Inhibitors »

Product Description

Evans Blue tetrasodium salt is a potent inhibitor of L-glutamate uptake into synaptic vesicles. Also inhibits AMPA and kainate receptor-mediated currents (IC50 values are 220 and 150 nM respectively). P2X-selective purinoceptor antagonist. Also a non-permeating dye, stains damaged plasma membrane and enters in the cytoplasm and nucleus, used for checking cell viability.

Optical Data

Emission Color Red
λem 680 nm

Product Specifications for Evans Blue tetrasodium salt

Molecular Weight

960.82

Formula

C34H24N6Na4O14S4

Storage

Store at RT

Purity

≥90% (HPLC)

Chemical Name

6,6-[(3,3'-Dimethyl[1,1'-biphenyl]-4,4'-diyl)bis(azo)bis[4-amino- 5-hydroxy-1,3-naphthalenedisulphonic acid] tetrasodium salt

CAS Number

314-13-6

PubChem ID

101102794

InChI Key

ATNOAWAQFYGAOY-UHFFFAOYSA-J

SMILES

[Na+].[Na+].[Na+].[Na+].CC1=CC(=CC=C1\N=N\C1=C(O)C2=C(C=C1)C(=CC(=C2N)S([O-])(=O)=O)S([O-])(=O)=O)C1=CC(C)=C(C=C1)\N=N\C1=C(O)C2=C(N)C(=CC(=C2C=C1)S([O-])(=O)=O)S([O-])(=O)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Solubility

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
water 9.61 10

Preparing Stock Solutions for Evans Blue tetrasodium salt

The following data is based on the product molecular weight 960.82.

Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which all affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:

Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
0.1 mM 10.41 mL 52.04 mL 104.08 mL
0.5 mM 2.08 mL 10.41 mL 20.82 mL
1 mM 1.04 mL 5.20 mL 10.41 mL
5 mM 0.21 mL 1.04 mL 2.08 mL

Calculators

Calculate the mass, volume, or concentration required for a solution.

=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Calculate the dilution required to prepare a stock solution.

x
=
x

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background References

References are publications that support the biological activity of the product. See our Citations tab to view 9 publications citing the usage of this product.

Product Documents for Evans Blue tetrasodium salt

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for Evans Blue tetrasodium salt

For research use only

Citations for Evans Blue tetrasodium salt

Customer Reviews for Evans Blue tetrasodium salt (2)

5 out of 5
2 Customer Ratings
5 Stars
100%
4 Stars
0%
3 Stars
0%
2 Stars
0%
1 Stars
0%

Have you used Evans Blue tetrasodium salt?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Customer Images

Showing  1 - 2 of 2 reviews Showing All
Filter By:
Clear Filters X
  • test
    Name: Chi Ngo
    Species: Mouse
    Assay Type: In Vivo
    Verified Customer | Posted 09/06/2025
    Evans Blue was dissolved in DDW to a final concentration of 1% (w/v). 1 ul of %Evan blue was microinjected to mouse brain at a speed of 0.1 ul/min. Brains was fixed in 4% PFA, dehydrated in 30% and 10% succrose and dissected.
    Evans Blue was used to mark the site of injection while optimizing microinjection of mouse brains.
    Evans Blue tetrasodium salt 0845
  • Used for injection
    Name: Anonymous
    Species: Mouse
    Assay Type: In Vivo
    Cell Line/Tissue: muscle
    Verified Customer | Posted 06/06/2020
    Evans blue solution 50 μl/g body weight injection to allow imaging of necrotic tissue in muscle dystrophy mouse model
    Evans Blue tetrasodium salt 0845
