Luminex Instruments

Luminex instruments offer proven precision and reliability, making them among the most widely used multiplexing platforms in the market. Using a mixture of color-coded beads pre-coated with capture antibodies, powerful xMAP technology offers the ability to bind up to 500 different analyte targets in solution. Upon completion of an R&D Systems Luminex assay, beads are analyzed with a dedicated dual-laser flow-based detection instrument. From the Luminex® 200 to the advanced xMAP INTELLIFLEX®, choose the Luminex instrument that best meets your unique application requirements.

R&D Systems Luminex Assays are compatible with all Luminex Instruments. These systems can be obtained from R&D Systems.

Luminex 200 Instrumentation FLEXMAP 3D Luminex Instrumentation
Luminex 200 Luminex FLEXMAP 3D®
Learn More Learn More
Affordable, simple and compact multiplexing instrument Flexible multiplexing instrument based upon the principle of flow cytometry
luminex xmap intelliflex luminex xmap intelliflex dr-se ruo
XMAP INTELLIFLEX RUO XMAP INTELLIFLEX DR-SE RUO
Learn More Learn More
Compact with largest dynamic range Dual Reporter INTELLIFLEX option


Compare Luminex Instruments

  Luminex 200 FLEXMAP 3D XMAP INTELLIFLEX RUO XMAP INTELLIFLEX DR-SE RUO
Number of targets Multiplex capacity Up to 80 Up to 500 Up to 500 Up to 500
Microtiter wells 96 96 and 384 96 and 384 96 and 384
Read time for 96 wells ~40 min ~20 min ~20 min ~20 min
Read time for 384 wells N/A ~75 min ~75 min ~75 min
Dynamic Range 3.5 logarithmic 4 logarithmic ≥5.5 logarithmic ≥5.5 logarithmic
Touchscreen N/A N/A Yes Yes
Reporter Laser 532 nm (green) 532 nm (green) 532 nm (green) 532 nm (green)
405 nm (violet)
Dual Reporter Readout N/A N/A N/A Yes
Barcode reader N/A N/A N/A Yes


Luminex Instrument Accessories

INTELLIFLEX accessories Luminex 100/200 accessories Luminex FLEXMAP 2D accessories Magnetic Plate Separator MAGPIX accessories
INTELLIFLEX Luminex® 100/200 Luminex FLEXMAP 3D Magnetic Plate Separator Luminex MAGPIX®
See Products See Products See Products See Products See Products


Quantist Luminex Analysis Software

Quantist Luminex data analysis software helps you extract insight from complexity. Use this software to evaluate the quality of your standards, controls, and unknowns. Evaluate the long-term consistency of your Luminex data by using Quantist to make inter-assay comparisons.

Quantist Features:

  • Compatible with .csv files from all Luminex instruments
  • Intuitive and easy-to-use design and interface
  • Adjustable standard curve parameters
  • Easily exclude data points
  • Export data into a comprehensive excel report

Purchase Quantist Analysis Software License

Quantist Luminex Analysis Software Image


Resources

Enhanced Dynamic Range and Sample Detectability with the Luminex INTELLIFLEX Instrument thumbnail RnD Systems Luminex Instruments Assays and Software thumbnail Luminex Assay Users Guide thumbnail
Enhanced Dynamic Range & Sample Detectability with the Luminex INTELLIFLEX Instrument R&D Systems Luminex® Instruments, Assays, and Software Luminex Assay Users Guide
Read Now Read Now Read Now



Related Luminex Products

Luminex Custom Services High Performance Luminex Assays Discovery Luminex Assays Luminex Assay Builder
Luminex
Custom Services
High Performance
Luminex Assays
Discovery
Luminex Assays
Luminex
Assay Builder
Explore Explore Explore Explore



Request Quote





 Luminex®, Luminex® 200, Luminex FLEXMAP 3D®, XMAP INTELLIFLEX®, Luminex® 100/200, MAGPIX®, and xPONENT® are trademarks of Luminex Corporation.
