Jagged 1 Antibody (J1G53-3) [FITC] - Azide and BSA Free

Novus Biologicals | Catalog # NBP3-11671

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Human

Applications

Western Blot, Flow Cytometry, Surface Plasmon Resonance

Label

FITC (Excitation = 495 nm, Emission = 519 nm)

Antibody Source

Monoclonal Mouse IgG Kappa Clone # J1G53-3

Format

Azide and BSA Free
View all Jagged 1 Primary Antibodies »

Product Specifications

Immunogen

Recombinant human Jagged 1.

Specificity

Recognizes human Jagged 1. Detects a band of ~180kDa by Western blot.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG Kappa

Scientific Data Images for Jagged 1 Antibody (J1G53-3) [FITC] - Azide and BSA Free

Western Blot: Jagged 1 Antibody (J1G53-3)Azide and BSA Free [NBP3-11671]

Western Blot: Jagged 1 Antibody (J1G53-3)Azide and BSA Free [NBP3-11671]

Western Blot: Jagged 1 Antibody (J1G53-3) [NBP3-11671] - "Western blot analysis using Jagged 1 antibody (J1G53-3) at 1:1000 dilution.1: Human Jagged-1 Fc fusion protein.2. Transfected human Jagged-1 cell lysate (HEK 293).3. Mock transfected HEK 293 cell lysate.
Immunohistochemistry: Jagged 1 Antibody (J1G53-3) - Azide and BSA Free [NBP3-11671]

Immunohistochemistry: Jagged 1 Antibody (J1G53-3) - Azide and BSA Free [NBP3-11671]

Immunohistochemistry: Jagged 1 Antibody (J1G53-3) [NBP3-11671] - Immunohistochemical staining of JAG1 using Jagged 1 antibody (J1G53-3) in Pancreas, Acini and Duct (2.5 ug/ml). This antibody has been tested in immunohistochemistry, analyzed by an anatomic pathologist and validated for use in IHC applications against formalin-fixed, paraffin-embedded human tissues. The image shows the localization of the antibody as the precipitated red signal, with a hematoxylin purple nuclear counterstain.
Flow Cytometry: Jagged 1 Antibody (J1G53-3) - Azide and BSA Free [NBP3-11671]

Flow Cytometry: Jagged 1 Antibody (J1G53-3) - Azide and BSA Free [NBP3-11671]

Flow Cytometry: Jagged 1 Antibody (J1G53-3) [NBP3-11671] - FACS staining of human Lymphocyte(CD4+) using Jagged 1 antibody (J1G53-3) (PerCP).
Surface Plasmon Resonance: Jagged 1 Antibody (J1G53-3)Azide and BSA Free [NBP3-11671]

Surface Plasmon Resonance: Jagged 1 Antibody (J1G53-3)Azide and BSA Free [NBP3-11671]

Surface Plasmon Resonance: Jagged 1 Antibody (J1G53-3) [NBP3-11671] - SPR analysis of the interaction between Jagged 1 antibody (J1G53-3) derivative hJagged1-Fc fusion protein. SPR response was taken when 13, 6.5, 3.25, 1.625, and 0.8125nM of J1G53-3 were injected onto the hJagged1-Fc fusion protein. J1G53-3 exhibited the highest binding affinity, and its property and binding ability was studied in detail by spectroscopy and surface Plasmon resonance (SPR). The result acquired through SPR was as follows: Kd value was 1.08nM and value of chi-square was 0.0237 through SPR analysis.

Applications for Jagged 1 Antibody (J1G53-3) [FITC] - Azide and BSA Free

Application
Recommended Usage

Flow Cytometry

Optimal dilutions of this antibody should be experimentally determined.

Surface Plasmon Resonance

Optimal dilutions of this antibody should be experimentally determined.

Western Blot

Optimal dilutions of this antibody should be experimentally determined.
Application Notes
Western blot: 1:2000-1:5000 using ECL. Suggested blocking and dilution buffer is PBST with 0.05% Tween 20 and 5% skim milk. Suggested incubation time is 1 hour at rooom temperature.

Spectra Viewer

Plan Your Experiments

Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.

Spectra Viewer
Spectra Viewer

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

0.2 um-filtered solution in PBS, pH 7.4

Format

Azide and BSA Free

Preservative

No Preservative

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: Jagged 1

The jagged 1 protein encoded by JAG1 is the human homolog of the Drosophilia jagged protein. Human jagged 1 is theligand for the receptor notch 1, the latter a human homolog of the Drosophilia jagged receptor notch. Mutations thatalter the jagged 1 protein cause Alagille syndrome. Jagged 1 signalling through notch 1 has also been shown to play arole in hematopoiesis. (provided by RefSeq)

Alternate Names

CD339, JAG1

Gene Symbol

JAG1

Additional Jagged 1 Products

Product Documents for Jagged 1 Antibody (J1G53-3) [FITC] - Azide and BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for Jagged 1 Antibody (J1G53-3) [FITC] - Azide and BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
