![Immunocytochemistry/ Immunofluorescence: Lyp/PTPN22 Antibody [NBP2-69989]](https://resources.rndsystems.com/images/products/Lyp-PTPN22-Antibody-Immunocytochemistry-Immunofluorescence-NBP2-69989-img0001.jpg "Immunocytochemistry/ Immunofluorescence: Lyp/PTPN22 Antibody [NBP2-69989]")
Loading...
Key Product Details
Species Reactivity
Human
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Peptide ELISA, Flow Cytometry, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
Peptide with sequence CPPNKPAESVQSNNS, from the internal region of the protein sequence according to NP_057051; NP_036543.4; NP_001180360.1; NP_001295226.1.
Reactivity Notes
Expected from sequence similarity: Chimpanzee
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Scientific Data Images for Lyp/PTPN22 Antibody
Immunocytochemistry/ Immunofluorescence: Lyp/PTPN22 Antibody [NBP2-69989]
Immunocytochemistry/Immunofluorescence: Lyp/PTPN22 Antibody [NBP2-69989] - Analysis of paraformaldehyde fixed U2OS cells, permeabilized with 0.15% Triton. Primary incubation 1hr (10ug/ml) followed by Alexa Fluor 488 secondary antibody (2ug/ml), showing nuclear staining. Actin filaments were stained with phalloidin (red). Negative control: Unimmunized goat IgG (10ug/ml) followed by Alexa Fluor 488 secondary antibody (2ug/ml).![Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]](https://resources.rndsystems.com/images/products/Lyp-PTPN22-Antibody-Immunohistochemistry-Paraffin-NBP2-69989-img0005.jpg "Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]")
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989] - (3.75ug/ml) Human Adrenal Gland. Steamed antigen retrieval with citrate buffer pH 6, AP-staining.![Flow Cytometry: Lyp/PTPN22 Antibody [NBP2-69989]](https://resources.rndsystems.com/images/products/Lyp-PTPN22-Antibody-Flow-Cytometry-NBP2-69989-img0002.jpg "Flow Cytometry: Lyp/PTPN22 Antibody [NBP2-69989]")
Flow Cytometry: Lyp/PTPN22 Antibody [NBP2-69989]
Flow Cytometry: Lyp/PTPN22 Antibody [NBP2-69989] - Analysis of paraformaldehyde fixed Jurkat cells (blue line), permeabilized with 0.5% Triton. Primary incubation 1hr (10ug/ml) followed by Alexa Fluor 488 secondary antibody (1ug/ml). IgG control: Unimmunized goat IgG (black line) followed by Alexa Fluor 488 secondary antibody.![Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]](https://resources.rndsystems.com/images/products/Lyp-PTPN22-Antibody-Immunohistochemistry-Paraffin-NBP2-69989-img0003.jpg "Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]")
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989] - (3.75ug/ml) Human Small Intestine. Steamed antigen retrieval with citrate buffer pH 6, AP-staining.![Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]](https://resources.rndsystems.com/images/products/Lyp-PTPN22-Antibody-Immunohistochemistry-Paraffin-NBP2-69989-img0004.jpg "Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]")
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989]
Immunohistochemistry-Paraffin: Lyp/PTPN22 Antibody [NBP2-69989] - (3.75ug/ml) Human Thyroid. Steamed antigen retrieval with citrate buffer pH 6, AP-staining.Applications for Lyp/PTPN22 Antibody
Application
Recommended Usage
Flow Cytometry
10 ug/ml
Immunocytochemistry/ Immunofluorescence
10 ug/ml
Immunohistochemistry
3.75 ug/ml
Immunohistochemistry-Paraffin
3.75 ug/ml
Peptide ELISA
1:32000
Western Blot
0.5-1ug/ml
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Formulation
TBS (pH 7.3), 0.5% BSA
Preservative
0.02% Sodium Azide
Concentration
0.5 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Background: Lyp
Long Name
Lymphoid Phosphatase
Alternate Names
LyPTP, PEP, PTPN22, PTPN8 (former)
Gene Symbol
PTPN22
Additional Lyp Products
Product Documents for Lyp/PTPN22 Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for Lyp/PTPN22 Antibody
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Related Research Areas
Customer Reviews for Lyp/PTPN22 Antibody
There are currently no reviews for this product. Be the first to review Lyp/PTPN22 Antibody and earn rewards!
Have you used Lyp/PTPN22 Antibody?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
