Recombinant Human CD39/ENTPD1 Protein, CF

  (2 citations)
Datasheet / CoA / SDS
Product Details
Citations (2)
FAQs
Supplemental Products
Reviews
  • Purity
    >95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining
  • Endotoxin Level
    <1.0 EU per 1 μg of the protein by the LAL method.
  • Activity
    Measured by its ability to hydrolyze the 5’-phosphate groups from the substrate adenosine-5’-triphosphate (ATP). The orthophosphate product is measured by a Malachite Green Phosphate Detection Kit (Catalog # DY996). The specific activity is >5,000 pmol/min/µg, as measured under the described conditions.
  • Source
    Chinese Hamster Ovary cell line, CHO-derived human CD39/ENTPD1 protein
    Thr38-Val478, with a C-terminal 6-His tag
  • Accession #
  • N-terminal Sequence
    Analysis
    Thr38
  • Predicted Molecular Mass
    51 kDa
  • SDS-PAGE
    65-90 kDa, reducing conditions
Product Datasheets

Certificate of Analysis Lookup

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Certificate of Analysis Lookup

Certificate of Analysis Request Form

To download a Certificate of Analysis, please enter the catalog and lot numbers in the search box below.

Note: Certificate of Analysis not available for kit components.

4397-EN

Formulation Supplied as a 0.2 μm filtered solution in Tris, NaCl, CaCl2 and Glycerol.

Shipping The product is shipped with dry ice or equivalent. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 6 months from date of receipt, -20 to -70 °C as supplied.
  • 3 months, -20 to -70 °C under sterile conditions after opening.

Assay Procedure
Materials
  • Assay Buffer: 25 mM Tris, 5 mM CaCl2, pH 7.5
  • Recombinant Human CD39/ENTPD1 (rhCD39) (Catalog # 4397-EN)
  • Substrate: ATP (Sigma, Catalog # A-7699), 10 mM stock in deionized water
  • Malachite Green Phosphate Detection Kit (Catalog # DY996)
  • 96-well Clear Plate (Costar, Catalog # 92592)
  • Plate Reader (Model: SpectraMax Plus by Molecular Devices) or equivalent
  1. Dilute rhCD39 to 0.04 µg/mL in Assay Buffer.
  2. Prepare a standard curve from the 1 M Phosphate Standard supplied in the malachite green phosphate detection kit. First, add 10 µL of the 1 M Phosphate Standard to 990 µL of Assay Buffer for a 10 mM stock. Then, add 10 µL of the 10 mM phosphate stock to 990 µL of Assay Buffer for a 100 µM stock. (This is the first dilution to use as a standard.) Finally, perform six additional two-fold serial dilutions of the 100 µM phosphate stock. The standard curve has a range of 0.039 to 2.5 nmol per well.
  3. Transfer to a 96 well clear plate (in duplicate) 25 µL of diluted rhCD39 at 0.04 µg/mL, standard curve, and blanks (Assay Buffer).
  4. Dilute Substrate to 100 µM in Assay Buffer.
  5. Add 25 µL of the diluted Substrate to all wells. Mix well.
  6. Cover the plate with parafilm or a plate sealer and incubate at 37 °C for 30 minutes.
  7. After incubation, add 10 µL of the Malachite Green Reagent A to each sample, standard, and blank. Mix and incubate for 10 minutes at room temperature.
  8. Add 10 µL of the Malachite Green Reagent B to each sample, standard, and blank. Mix and incubate for 20 minutes at room temperature.
  9. Read plate at 620 nm (absorbance) in endpoint mode.
  10. Calculate specific activity:

     Specific Activity (pmol/min/µg) =

Phosphate released* (nmol) x (1000 pmol/1 nmol)
Incubation time (min) x amount of enzyme (µg)

     *Derived from the phosphate standard curve using linear or 4-parameter fitting and adjusted for Substrate Blank.

Per Well:
  • rhCD39: 0.001 µg
  • Substrate: 35.7 µM
Background: CD39/ENTPD1

Ectonucleoside triphosphate diphosphohydrolase-1 (NTPDase-1) is an integral membrane protein with an extracellular active site. Recombinant human NTPDase-1 was expressed as a protein lacking its N- and C-terminal transmembrane domains, resulting in the secretion of the soluble recombinant human NTPDase-1 ectodomain. NTPDase-1 was originally described as CD39, a B lymphocyte cell surface marker (2), but it is also present on the surface of natural killer cells, T cells, and some endothelial cells (3). NTPDase-1 hydrolyzes the beta - and gamma  phosphate residues of nucleotides, preferring ATP as the substrate. Through its hydrolysis of extracellular nucleotides, NTPDase-1 plays a role in the regulation of purinergic signaling (4). NTPDase-1 is involved in the processes of thromboregulation and vascular inflammation (5). The administration of soluble NTPDase-1 may have therapeutic applications for the treatment of some vascular and transplantation-associated diseases (6).

  • References:
    1. Maliszewski, C.R. et al. (1994) J. Immunol. 153:3574.
    2. Rowe, M. et al. (1982) Int. J. Cancer 29:373.
    3. Kansas, G.S. et al. (1991) J. Immunol. 146:2235.
    4. Kishore, B.K. et al. (2005) Am. J. Physiol. Renal Physiol. 288:F1032.
    5. Marcus, A.J. et al. (2005) Semin. Thromb. Hemost. 31:234.
    6. Robson, S.C. et al. (2005) Semin. Thromb. Hemost. 31:217.
  • Long Name:
    Ecto-Nucleoside Triphosphate Diphosphohydrolase 1
  • Entrez Gene IDs:
    953 (Human); 12495 (Mouse); 64519 (Rat); 102132860 (Cynomolgus Monkey)
  • Alternate Names:
    ADPase; ATPDase; ATP-diphosphatase; CD39 antigen; CD39; CD39EC 3.6.1.5; DKFZp686D194; DKFZp686I093; EC 3.6.1; ecto-apyrase; Ecto-ATP diphosphohydrolase 1; Ecto-ATPase 1; Ecto-ATPDase 1; ectonucleoside triphosphate diphosphohydrolase 1; ENTPD1; FLJ40921; FLJ40959; Lymphoid cell activation antigen; NTPD1; NTPDase 1; NTPDase-1
Related Research Areas
Citations:

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

2 Citations: Showing 1 - 2
Filter your results:

Species
Applications
Sample Type
  1. ADPase CD39 Fused to Glycoprotein VI-Fc Boosts Local Antithrombotic Effects at Vascular Lesions
    Authors: H Degen, O Borst, M Ziegler, AK Mojica Mun, J Jamasbi, B Walker, S Göbel, J Fassbender, K Adler, R Brandl, G Münch, R Lorenz, W Siess, M Gawaz, M Ungerer
    J Am Heart Assoc, 2017;6(8):.
    Application: EnzAct
  2. The ubiquitin ligase ASB4 promotes trophoblast differentiation through the degradation of ID2.
    Authors: Townley-Tilson, W H Davi, Wu, Yaxu, Ferguson, James E, Patterson, Cam
    PLoS ONE, 2014;9(2):e89451.
    Species: Human
    Sample Type: Whole Cells
    Application: Bioassay
