Recombinant Human Insulin R/CD220 (aa 28-956) Protein, CF

B Isoform
Catalog # Availability Size / Price Qty
Best Seller
R&D Systems Recombinant Proteins and Enzymes
1 Image
Product Details
Supplemental Products

Recombinant Human Insulin R/CD220 (aa 28-956) Protein, CF Summary

Product Specifications

>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining.
Endotoxin Level
<0.10 EU per 1 μg of the protein by the LAL method.
Measured by its binding ability in a functional ELISA. When 15 ng/mL of biotinylated recombinant human Insulin is added to serially diluted Recombinant Human Insulin R/CD220 B Isoform, the concentration of Recombinant Human Insulin R/CD220 B Isoform that produces 50% of the optimal binding response is 0.1-0.5 μg/mL.
Human embryonic kidney cell, HEK293-derived human Insulin R/CD220 protein
His28-Arg762( alpha subunit) and Ser763-Lys956 with a c-terminal 10-His tag ( beta subunit)
Accession #
N-terminal Sequence
His28 ( alpha subunit), Ser763 ( beta subunit)
Structure / Form
Disulfide-linked heterotetramer
Predicted Molecular Mass
107 kDa ( alpha & beta heterodimer)
105-120 kDa ( alpha subunit) and 37-49 kDa ( beta subunit), reducing conditions

Product Datasheets

You must select a language.



Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.


Formulation Lyophilized from a 0.2 μm filtered solution in PBS.
Reconstitution Reconstitute at 250 μg/mL in PBS.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Background: Insulin R/CD220

The Insulin Receptor (gene name INSR, designated CD220) is a type I transmembrane glycoprotein in the Insulin/IGF Receptor family of receptor tyrosine kinases that share structural similarity and overlapping intracellular signaling events (1-3). The 1382 amino acid (aa) human Insulin R preproprotein (B isoform) is processed by proteolysis to remove the signal peptide and produce an extracellular alpha portion (aa 28-762), and an extracellular/transmembrane/cytoplasmic beta  subunit (aa 763-1382) (4). The extracellular domain (ECD) contains two homologous globular domains separated by a cysteine-rich domain and followed by three fibronectin type III domains. The intracellular region contains insulin-receptor substrate (IRS) docking sites, the kinase domain, and a phosphotyrosine-containing linker region. The human Insulin R ECD shares 96% aa sequence identity with mouse, rat, equine and canine Insulin R. As a result of alternative splicing, two INSR isoforms that differ by the absence (IR-A) or presence (IR-B) of a 12 aa residue sequence in the carboxyl terminus of the alpha subunit exist (4). IR-A expression is highest in fetal tissues and cancer cells, while IR-B is concentrated in adult differentiated cells (2-5). IR-A and IR-B may homodimerize, or heterodimerize with the IGF-I receptor (1, 3, 4). All receptor combinations bind insulin, IGF-I or IGF-II, but with differing affinities; for example, IR-A has considerably higher affinity for IGF-II as compared to IR-B (2-5). This system allows fine tuning of signaling pathways according to the concentrations of insulin, IGF-I and IGF-II, and expression of receptor subunits on the cell surface (2, 3). Insulin R signaling regulates glucose uptake and metabolism, but also contributes to cell growth, differentiation and apoptosis (2, 3, 5, 6). Mutations in the Insulin R gene have been linked severe insulin resistance (type A and Rabson-Mendenhall syndrome) that may include type II diabetes mellitus and, rarely, leprechaunism (Donohue syndrome) that also includes growth delays and endocrine system abnormalities (1, 7). This human Insulin R product consists of the entire ECD of the IR-B isoform.

  1. Nakae, J. et al. (2001) Endoc. Rev. 22:818.
  2. Sciacca, L. et al. (2003) Endocrinology 144:2650.
  3. Belfiore, A. et al. (2009) Endocrine Rev. 30:586.
  4. Lawrence, M.C. et al. (2007) Curr. Opin. Struct. Biol. 17:699.
  5. Sacco, A. et al. (2009) Endocrinology 150:3594.
  6. Kitamura, T. et al. (2004) J. Clin. Invest. 113:209.
  7. Musso, C. et. al. (2004) Medicine (Baltimore) 83: 209.
Long Name
Insulin Receptor
Entrez Gene IDs
3643 (Human); 16337 (Mouse)
Alternate Names
CD 220; CD220 antigen; CD220; EC 2.7.10; EC; HHF5; INSR; Insulin R; insulin receptor; InsulinR; IR
