Recombinant Human Serpin E1/PAI-1 Protein, CF

Catalog # Availability Size / Price Qty
1786-PI-010
Recombinant Human Serpin E1/PAI-1 Protein Enzyme Activity
1 Image
Product Details
Citations (9)
FAQs
Supplemental Products
Reviews

Recombinant Human Serpin E1/PAI-1 Protein, CF Summary

Product Specifications

Purity
>95%, by SDS-PAGE under reducing conditions and visualized by silver stain.
Endotoxin Level
<1.0 EU per 1 μg of the protein by the LAL method.
Activity
Measured by its ability to inhibit uPA cleavage of a peptide substrate, N-carbobenzyloxy-Gly-Gly-Arg-7-amido-4-methylcoumarin (Z-GGR-AMC). The IC50 value is <13 nM, as measured under the described conditions.
Source
Spodoptera frugiperda, Sf 21 (stably transfected)-derived human Serpin E1/PAI-1 protein
Met1-Pro402, with a C-terminal 10-His tag
Accession #
N-terminal Sequence
Analysis
Ser22 & Val24
Predicted Molecular Mass
44 kDa
SDS-PAGE
43 kDa, reducing conditions

Product Datasheets

You must select a language.

x

1786-PI

Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.

1786-PI

Formulation Lyophilized from a 0.2 μm filtered solution in Sodium Acetate, NaCl and CHAPS.
Reconstitution Reconstitute at 500 μg/mL in sterile 50 mM Sodium Acetate and 100 mM NaCl, pH 5.5.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 6 months from date of receipt, -20 to -70 °C as supplied.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.

Assay Procedure

Materials
  • Assay Buffer: 50 mM Tris, 0.01% (v/v) Tween® 20, pH 8.5
  • Recombinant Human Serpin E1/PAI-1 (rhSerpin E1/PAI-1) (Catalog # 1786-PI)
  • Recombinant Human u‑Plasminogen Activator (uPA)/Urokinase (rhuPA) (Catalog # 1310-SE)
  • Substrate: Z-Gly-Gly-Arg-AMC (Bachem, Catalog # I-1140)
  • F16 Black Maxisorp Plate (Nunc, Catalog # 475515)
  • Fluorescent Plate Reader (Model: SpectraMax Gemini EM by Molecular Devices) or equivalent
  1. Dilute rhuPA to 2 µg/mL in Assay Buffer.
  2. Prepare a rhSerpin E1/PAI-1 (MW: 44146 Da) dilution curve in Assay Buffer. Make the following serial dilutions:  1500, 750, 375, 187.5, 125, 75, 50, 25, and 12.5 nM.
  3. Mix equal volumes of the rhSerpin E1/PAI-1 curve and the diluted rhuPA at 2 µg/mL. Include 2 controls containing rhuPA and Assay Buffer only.
  4. Incubate mixtures at room temperature for 15 minutes.
  5. After incubation, dilute the mixtures 5 fold in Assay Buffer.
  6. Dilute the Substrate to 200 µM in Assay Buffer.
  7. Load 50 µL of the incubated reactions into a plate, and start the reaction by adding 50 µL of 200 µM Substrate to each well.
  8. Read at excitation and emission wavelengths of 380 nm and 460 nm (top read), respectively, in kinetic mode for 5 minutes.
  9. Determine the 50% inhibiting concentration (IC50) for rhSerpin E1 by plotting RFU/min (or specific activity) vs. concentration with 4‑PL fitting.
  10. The specific activity for rhuPA at each point may be determined using the following formula (if necessary):

     Specific Activity (pmol/min/µg) =

Adjusted Vmax* (RFU/min) x Conversion Factor** (pmol/RFU)
amount of enzyme (µg)

     *Adjusted for Substrate Blank
     **Derived using calibration standard 7-amino, 4-Methyl Coumarin (AMC) (Sigma, Catalog # A-9891).

Per Well:
  • rhuPA: 0.010 µg
  • rhSerpin E1/PAI-1 curve: 75, 37.5, 18.75, 9.375, 6.25, 3.75, 2.5, 1.25, and 0.625 nM
  • Substrate: 100 µM

Scientific Data

Enzyme Activity Recombinant Human Serpin E1/PAI-1 Protein Enzyme Activity View Larger

Recombinant Human Serpin E1/PAI-1 (Catalog # 1786-PI) is measured by its ability to inhibit uPA cleavage of a peptide substrate, N-carbobenzyloxy-Gly-Gly-Arg-7-amido-4-methylcoumarin (Z-GGR-AMC).

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: Serpin E1/PAI-1

As a member of the Serpin superfamily of serine protease inhibitors, Serpin E1/PAI‑1 is the principal inhibitor of urokinase‑type plasminogen activator (uPA) and tissue‑type PA (1, 2). As important regulators of extracellular matrix remodeling, uPA and PAI‑1 play a major role in many processes such as angiogenesis, tumor invasion and obesity (2‑4). For example, uPA and PAI-1 are the only tumor prognostic factors validated at the highest level of evidence with regard to their clinical utility in breast cancer (5). The human PAI-1 is initially synthesized as 402 amino acid precursor with a N‑terminal signal peptide (6, 7). PAI‑1 may exist in one of two possible conformations, designated as active or latent (8). The purified rhPAI‑1 is active against rhuPA. The heterogeneity at the N‑terminus of the purified
rhPAI‑1 has been observed before for both the recombinant and native proteins (9).

References
  1. Silverman, G.A. et al. (2001) J. Biol. Chem. 276:33293.
  2. Stefansson, S. et al. (2003) Curr. Pharm. Des. 9:1545.
  3. Duffy, M.J. (2002) Clin. Chem. 48:1194.
  4. Juhan-Vague, I. et al. (2003) J. Thromb. Haemost. 1:1575.
  5. Harbeck, N. et al. (2002) Clin. Breast Cancer 3:196.
  6. Pannekoek, H. et al. (1986) EMBO J. 5:2539.
  7. Ginsburg, D. et al. (1986) J. Clin. Invest. 78:1673.
  8. Wang, Z. et al. (1996) Biochemistry 35:16443.
  9. Stromqvist, M. et al. (1994) Protein Expr. Purif. 5:309.
Long Name
Plasminogen Activator Inhibitor
Entrez Gene IDs
5054 (Human); 18787 (Mouse)
Alternate Names
Endothelial plasminogen activator inhibitor; Nexin; PAI1; PAI-1; PAI1PAI-1; PAISerpin E1; PLANH1; PLANH1plasminogen activator inhibitor 1; serine (or cysteine) proteinase inhibitor, clade E (nexin, plasminogenactivator inhibitor type 1), member 1; Serpin E1; serpin peptidase inhibitor, clade E (nexin, plasminogen activator inhibitortype 1), member 1
