HLA DR/DP Antibody (SC06-78)

Novus Biologicals | Catalog # NBP2-67610

Recombinant Monoclonal Antibody
Novus Biologicals
Loading...

Key Product Details

Validated by

Biological Validation

Species Reactivity

Human, Mouse, Rat

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # SC06-78 expressed in HEK293
Loading...

Product Specifications

Immunogen

Synthetic peptide within Human HLA DR/DP aa 159-195 / 254. (SwissProt: P01903 Human)

Localization

Cell membrane, Endoplasmic reticulum membrane, Golgi apparatus, Endosome membrane, Lysosome membrane.

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for HLA DR/DP Antibody (SC06-78)

Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Western blot analysis of HLA DR/DP on Daudi cell lysates. Proteins were transferred to a PVDF membrane and blocked with 5% BSA in PBS for 1 hour at room temperature. The primary antibody (1/500) was used in 5% BSA at room temperature for 2 hours. Goat Ant
Immunocytochemistry/ Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunocytochemistry/ Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunocytochemistry/Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Staining HLA-DR in B16-F1 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Immunohistochemical analysis of paraffin-embedded human tonsil tissue using anti-HLA DR/DP antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1610-66, 1/200) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Flow Cytometry: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Flow Cytometry: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Flow Cytometry: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of Jurkat cells with HLA-DR antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti rabbit IgG was used as the secondary antibody.
Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Western Blot: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of HLA-DR on Daudi cells lysates using anti-HLA-DR antibody at 1/1,000 dilution.
Immunocytochemistry/ Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunocytochemistry/ Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunocytochemistry/Immunofluorescence: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Staining HLA-DR in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of paraffin-embedded human kidney tissue using anti-HLA-DR antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of paraffin-embedded human liver tissue using anti-HLA-DR antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of paraffin-embedded human spleen tissue using anti-HLA-DR antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of paraffin-embedded human tonsil tissue using anti-HLA-DR antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Analysis of paraffin-embedded mouse kidney tissue using anti-HLA-DR antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Immunohistochemical analysis of paraffin-embedded human liver tissue using anti-HLA DR/DP antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1610-66, 1/200) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610]

Immunohistochemistry-Paraffin: HLA DR/DP Antibody (SC06-78) [NBP2-67610] - Immunohistochemical analysis of paraffin-embedded human spleen tissue using anti-HLA DR/DP antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1610-66, 1/200) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Applications for HLA DR/DP Antibody (SC06-78)

Application
Recommended Usage

Flow Cytometry

1:50-1:100

Immunocytochemistry/ Immunofluorescence

1:50-1:200

Immunohistochemistry-Paraffin

1:50-1:200

Western Blot

1:500

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

TBS (pH7.4), 0.05% BSA, 40% Glycerol

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: HLA DR/DP

Human MHC class II antigens are transmembrane glycoproteins composed of an alpha (36 kDa) and a beta chain (27kDa) and are expressed primarily on antigen presenting cells. Human MHC class II genes are located in the HLA-D region that encodes at least 6 alpha and 10 beta chain genes. Three loci, DR, DQ and DP, encode the major products of the human class II region. The human MHC class II molecules bind intracellularly processed peptides and present them to T-helper cells and therefore have a critical role in the initiation of the immune response. It has been shown that some autoimmune diseases are associated with certain class II alleles.

Alternate Names

FLJ51114, histocompatibility antigen HLA-DR alpha, HLA class II histocompatibility antigen, DR alpha chain, HLA-DRA1, major histocompatibility complex, class II, DR alpha, MHC cell surface glycoprotein, MHC class II antigen DRA, MLRW

Gene Symbol

HLA-DRA
