Human CXCL16 Quantikine ELISA Kit

R&D Systems | Catalog # DCX160

R&D Systems
100% Guarantee

Key Product Details

Assay Length

4.5 hours

Sample Type & Volume Required Per Well

Cell Culture Supernates (50 µL), Serum (50 µL), EDTA Plasma (50 µL), Heparin Plasma (50 µL)

Sensitivity

0.017 ng/mL

Assay Range

0.156-10 ng/mL (Cell Culture Supernates, Serum, EDTA Plasma, Heparin Plasma)
View all CXCL16 ELISA Kits »

Product Summary for Human CXCL16 Quantikine ELISA Kit

The Quantikine Human CXCL16 Immunoassay is a 4.5 hour solid-phase ELISA designed to measure human CXCL16 in cell culture supernates, serum, and plasma. It contains E. coli-expressed recombinant human CXCL16 and has been shown to accurately quantitate the recombinant factor. Results obtained using natural human CXCL16 showed linear curves that were parallel to the standard curves obtained using the Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values for naturally occurring human CXCL16.

Product Specifications

Assay Type

Solid Phase Sandwich ELISA

Format

96-well strip plate

Measurement

Quantitative ELISA

Detection Method

Colorimetric - 450nm (TMB)

Conjugate

HRP

Species

Human

Specificity

Natural and recombinant human CXCL16

Cross-reactivity

< 0.5% cross-reactivity observed with available related molecules. < 50% cross-species reactivity observed with species tested.

Interference

No significant interference observed with available related molecules.

Precision

Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision.

Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision.

Cell Culture Supernates, EDTA Plasma, Heparin Plasma, Serum

Intra-Assay Precision Inter-Assay Precision
Sample 1 2 3 1 2 3
n 20 20 20 40 42 42
Mean (pg/mL) 0.92 2.85 6.33 1.00 3.30 7.30
Standard Deviation 0.04 0.10 0.31 0.10 0.30 0.70
CV% 4.3 3.5 4.9 10.0 9.1 9.6

Recovery for Human CXCL16 Quantikine ELISA Kit

The recovery of CXCL16 spiked to levels throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=4) 98 93-110
EDTA Plasma (n=4) 102 94-112
Heparin Plasma (n=4) 97 85-105
Serum (n=4) 103 89-113

Linearity

To assess the linearity of the assay, samples containing and/or spiked with high concentrations of CXCL16 were serially diluted with the appropriate Calibrator Diluent to produce samples with values within the dynamic range of the assay.

Human CXCL16 ELISA Linearity

Scientific Data Images for Human CXCL16 Quantikine ELISA Kit

Human CXCL16 ELISA Standard Curve

Human CXCL16 ELISA Standard Curve

Preparation and Storage

Shipping

The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store the unopened product at 2 - 8 °C. Do not use past expiration date.

Background: CXCL16

CXC chemokine ligand 16 (CXCL16) is a type I membrane protein that has a non-ELR CXC chemokine domain in its extracellular region. Fractalkine (CX3CL1) and CXCL16 constitute the only two transmembrane chemokines. Mouse and human CXCL16 share 70% amino acid sequence similarity within their chemokine domains and 49% overall amino acid sequence identity.

Alternate Names

CXCL16

Entrez Gene IDs

58191 (Human); 66102 (Mouse)

Gene Symbol

CXCL16

Additional CXCL16 Products

Product Documents for Human CXCL16 Quantikine ELISA Kit

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Human CXCL16 Quantikine ELISA Kit

For research use only

⚠ WARNING: This product can expose you to chemicals including N,N-Dimethylforamide, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

Citations for Human CXCL16 Quantikine ELISA Kit

Customer Reviews for Human CXCL16 Quantikine ELISA Kit

There are currently no reviews for this product. Be the first to review Human CXCL16 Quantikine ELISA Kit and earn rewards!

Have you used Human CXCL16 Quantikine ELISA Kit?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for Human CXCL16 Quantikine ELISA Kit (DCX160):

Refer to the product for complete assay procedure.

Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
  1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
  2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.
    3. 100 µL Assay Diluent
  3.   Add 100 µL of Assay Diluent to each well.
    4. 50 µL Standard, Control, or Sample
  4.   Add 50 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours.
  5.   Aspirate each well and wash, repeating the process 3 times for a total of 4 washes.
    6. 200 µL Conjugate
  6.   Add 200 µL of Conjugate to each well. Cover with a new plate sealer, and incubate at room temperature for 2 hours.
  7.   Aspirate and wash 4 times.
    8. 200 µL Substrate Solution
  8.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 30 minutes. PROTECT FROM LIGHT.
    9. 50 µL Stop Solution
  9.   Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
