Human Cyr61/CCN1 Quantikine ELISA Kit

  • Assay Type
    Solid Phase Sandwich ELISA
  • Format
    96-well strip plate
  • Assay Length
    4.5 hours
  • Sample Type & Volume Required Per Well
    Cell Culture Supernates (50 uL), Serum (50 uL), EDTA Plasma (50 uL), Saliva (50 uL), Human Milk (10 uL)
  • Sensitivity
    3.8 pg/mL
  • Assay Range
    39.1 - 2,500 pg/mL (Cell Culture Supernates, Serum, EDTA Plasma, Saliva, Human Milk)
  • Specificity
    Natural and recombinant human Cyr61
  • Cross-reactivity
    < 0.5% cross-reactivity observed with available related molecules.< 50% cross-species reactivity observed with species tested.
  • Interference
    No significant interference observed with available related molecules.
Control Available
Product Summary
The Quantikine Human Cyr61/CCN1 Immunoassay is a 4.5 hour solid-phase ELISA designed to measure human Cyr61 in cell culture supernates, serum, plasma, saliva, and human milk. It contains CHO cell-expressed recombinant human Cyr61 and has been shown to accurately quantitate the recombinant factor. Results obtained using natural human Cyr61 showed linear curves that were parallel to the standard curves obtained using the Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values for naturally occurring Cyr61.

Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision.
Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision.
Cell Culture Supernates, Serum, EDTA Plasma, Saliva, Human Milk
Intra-Assay Precision Inter-Assay Precision
Standard Deviation5.9414.233.515.93573.3


The recovery of Cyr61 spiked to levels throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=4) 107 98-117
EDTA Plasma (n=4) 98 91-104
Serum (n=4) 101 95-113
To assess the linearity of the assay, samples containing and/or spiked with high concentrations of Cyr61 were diluted with Calibrator Diluent to produce samples with values within the dynamic range of the assay.
Human Cyr61/CCN1 Quantikine ELISA Kit
Preparation and Storage
  • Storage
    Store the unopened product at 2 - 8 °C. Do not use past expiration date.
Background: Cyr61/CCN1

Cyr61, also known as IGFBP-10 and CCN1, is a 50 kDa matricellular glycoprotein that regulates the growth and adhesion of vascular endothelial cells, fibroblasts, and monocytes. Cyr61 induces VEGF upregulation, angiogenesis, and tumorigenesis through interactions with integrins alpha V beta 3, alpha V beta 5, alpha M beta 2, and alpha 6 beta 1. Cyr61 is cleaved by plasmin within its VWF domain which generates an N-terminal fragment that is not associated with the matrix but retains the ability to induce endothelial cell migration.

    • Long Name
      Cysteine-Rich, Angiogenic Inducer 61
    • Entrez Gene IDs
      3491 (Human); 16007 (Mouse); 83476 (Rat);
    • Alternate Names
      CCN family member 1; CCN1; CCN1IGF-binding protein 10; Cysteine-rich angiogenic inducer 61; cysteine-rich, angiogenic inducer, 61; GIG1; GIG1cysteine-rich heparin-binding protein 61; IBP-10; IGFBP-10; IGFBP10cysteine-rich, anigogenic inducer, 61; Insulin-like growth factor-binding protein 10; protein CYR61; Protein GIG1;
    Related Research Areas
    Assay Procedure
    Refer to the product for complete assay procedure.

    Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
    1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
    2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.

    3. 100 µL Assay Diluent
    4.   Add 100 µL of Assay Diluent to each well.

    5. 50 µL Standard, Control, or Sample
    6.   Add 50 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours on a horizontal orbital microplate shaker.
    7.   Aspirate each well and wash, repeating the process 3 times for a total of 4 washes.

    8. 200 µL Conjugate
    9.   Add 200 µL of Conjugate to each well. Cover with a new plate sealer, and incubate at room temperature for 2 hours on the shaker.
    10.   Aspirate and wash 4 times.

    11. 200 µL Substrate Solution
    12.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 30 minutes on the benchtop. PROTECT FROM LIGHT.

    13. 50 µL Stop Solution
    14.   Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
