Human LILRB2/CD85d/ILT4 PE-conjugated Antibody

(4 citations)
  • Species Reactivity
  • Specificity
    Detects human ILT4 in direct ELISAs and Western blots. In direct ELISAs and Western blots, no cross-reactivity with recombinant human (rh) ILT1, rhILT2, rhILT3, rhILT6, rhILT7, rhILT11, rhLIR6 or rhLIR8 is observed.
  • Source
    Monoclonal Mouse IgG2A Clone # 287219
  • Purification
    Protein A or G purified from hybridoma culture supernatant
  • Immunogen
    Mouse myeloma cell line NS0-derived recombinant human ILT4
    Accession # ACT64556
  • Formulation
    Supplied in a saline solution containing BSA and Sodium Azide.
  • Label
  • Flow Cytometry
    10 µL/106 cells
    See below
Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.
Data Examples
Detection of LILRB2/CD85d/ILT4 in Human PBMCs by Flow Cytometry. Human peripheral blood mononuclear cells (PBMCs) were stained with Mouse Anti-Human CD14 APC‑conjugated Monoclonal Antibody (Catalog # FAB3832A) and either (A) Mouse Anti-Human LILRB2/CD85d/ILT4 PE‑conjugated Monoclonal Antibody (Catalog # FAB2078P) or (B) Mouse IgG2A Phycoerythrin Isotype Control (Catalog # IC003P). View our protocol for Staining Membrane-associated Proteins.
Preparation and Storage
  • Shipping
    The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
  • Stability & Storage
    Protect from light. Do not freeze.
    • 12 months from date of receipt, 2 to 8 °C as supplied.
Background: LILRB2/CD85d/ILT4

The immunoglobulin-like transcript (ILT) comprise a family of activating and inhibitory type immunoreceptors whose genes are located in the same locus that encodes killer cell Ig-like receptors (KIR) (1‑3). ILT4, also known as LIR-2 and LILRB2, is a type I transmembrane protein expressed primarily on monocytes and dendritic cells (DC) (4). Human ILT4 is produced as a 598 amino acid (aa) precursor including a 21 aa signal sequence, a 440 aa extracellular domain (ECD), a 21 aa transmembrane segment, and a 116 aa cytoplasmic domain. The ECD contains four Ig-like domains, and the cytoplasmic domain contains three immunoreceptor tyrosine-based inhibitory motifs (ITIM) (5). The ECD of human ILT4 shares 76% aa identity with chimpanzee ILT4 and 74%, 81%, 33%, 52%, 77%, 61%, and 64 % aa identity with human ILT1, 2, 3, 5, 6, 7, and 8, respectively. ILT4 binds to classical MHC I proteins as well as the non-classical HLA-G1 and HLA-F molecules (5‑9). It competes with CD8 alpha for MHC I binding but does not compete with KIR2DL1 (7). Ligation of ILT4 induces Tyr phosphorylation within its cytoplasmic ITIMs, a requirement for association with SHP-1 (4, 6). Activation of ILT4 inhibits signaling through Fc gamma RI (4) and Fc epsilon RI (6) and causes DC to become tolerogenic by downregulation of costimulatory molecules (10, 11). ILT4 mediates tolerogenic DC-induced CD4+ T cell energy in vitro and in vivo (10‑12).

  • References:
    1. Suciu-Foca, N. et al. (2005) Int. Immunopharmacol. 5:7.
    2. Hofmeister, V. and E.H. Weiss (2003) Semin. Canc. Biol. 13:317.
    3. Hunt, J.S. et al. (2005) FASEB J. 19:681.
    4. Finger, N.A. et al. (1998) Eur. J. Immunol. 28:3423.
    5. Borges, L. et al. (1997) J. Immunol. 159:5192.
    6. Colonna, M. et al. (1998) J. Immunol. 160:3096.
    7. Shiroishi, M. et al. (2003) Proc. Natl. Acad. Sci. 100:8856.
    8. Lepin, E.J.M. et al. (2000) Eur. J. Immunol. 30:3552.
    9. Allen, R.L. et al. (2001) J. Immunol. 167:5543.
    10. Chang, C.C. et al. (2002) Nat. Immunol. 3:237.
    11. Ristich, V. et al. (2005) Eur. J. Immunol. 35:1133.
    12. Manavalan, J.S. et al. (2003) Transpl. Immunol. 11:245.
  • Long Name:
    Leukocyte Immunoglobulin-like Receptor, Subfamily B (with TM and ITIM Domains), Member 5
  • Entrez Gene IDs:
    10288 (Human)
  • Alternate Names:
    CD85 antigen-like family member D; CD85d antigen; CD85d; Ig-like transcript 4; ILT4; ILT-4; ILT4CD85d; Immunoglobulin-like transcript 4; Leukocyte immunoglobulin-like receptor 2; leukocyte immunoglobulin-like receptor subfamily B member 2 soluble isoform; leukocyte immunoglobulin-like receptor subfamily B member 2; leukocyte immunoglobulin-like receptor, subfamily B (with TM and ITIM domains); LIR2; LIR2CD85D; LIR-2subfamily A (with TM domain), member 6; member 2; MIR10; MIR10LILRA6; Monocyte/macrophage immunoglobulin-like receptor 10
Related Research Areas

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

Showing Results 1 - 4 of 4
Filter your results:

Sample Type
  1. Immune suppression and resistance mediated by constitutive activation of Wnt/beta-catenin signaling in human melanoma cells.
    J. Immunol., 2012;189(5):2110-7.
    Species: Human
    Sample Type: Whole Cells
    Application: Flow
  2. Identification of a New Phenotype of Tolerogenic Human Dendritic Cells Induced by Fungal Proteases from Aspergillus oryzae.
    Authors: Zimmer A, Luce S, Gaignier F, Nony E, Naveau M, Biola-Vidamment A, Pallardy M, Van Overtvelt L, Mascarell L, Moingeon P
    J. Immunol., 2011;186(7):3966-76.
    Species: Human
    Sample Type: Whole Cells
    Application: Flow
  3. Phenotypic and functional markers for 1alpha,25-dihydroxyvitamin D(3)-modified regulatory dendritic cells.
    Authors: Pedersen AW, Holmstrom K, Jensen SS, Fuchs D, Rasmussen S, Kvistborg P, Claesson MH, Zocca MB
    Clin. Exp. Immunol., 2010;157(1):48-59.
    Species: Human
    Sample Type: Whole Cells
    Application: Flow
  4. Soluble HLA-G molecules impair natural killer/dendritic cell crosstalk via inhibition of dendritic cells.
    Authors: Gros F, Cabillic F, Toutirais O, Maux AL, Sebti Y, Amiot L
    Eur. J. Immunol., 2008;38(3):742-9.
    Species: Human
    Sample Type: Whole Cells
    Application: ICC
