SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

R&D Systems | Catalog # LMAB10869

Recombinant Monoclonal Antibody. His-tagged VHH domain.
R&D Systems
100% Guarantee

Key Product Details

Species Reactivity

SARS-CoV-2

Applications

Immunohistochemistry, Blockade of Receptor-ligand Interaction

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Llama VHH domain Clone # L009.1.32N
View all Spike RBD Primary Antibodies »

Product Specifications

Immunogen

Human embryonic kidney cell HEK293-derived SARS-CoV-2 Spike RBD
Arg319-Phe541
Accession # YP_009724390.1

Specificity

Detects SARS-CoV-2 Spike RBD in direct ELISAs.

Clonality

Monoclonal

Host

Llama

Isotype

VHH domain

Scientific Data Images for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

SARS-Cov-2 Spike 1 protein binding to ACE-2-transfected Human Cell Line is Blocked by SARS-Cov-2 Spike RBD Antibody.

In a functional flow cytometry test, Recombinant SARS-Cov-2 Spike 1 Fc-tagged protein (10622-CV) binds to HEK293 human embryonic kidney cell line transfected with recombinant human ACE-2 and eGFP. (A) Binding is completely blocked by 50 µg/mL of SARS-Cov-2 Spike RBD Llamabody VHH His-tag Monoclonal Antibody (Catalog # LMAB10869) but not by (B) Llama IgG1 Control. Protein binding was detected with Mouse Anti-Human IgG Fc APC-conjugated Monoclonal Antibody (FAB110A). Staining was performed using our Staining Membrane-Associated Proteins protocol.

Detection of Spike RBD in Human lung infected with SARS delta variant.

Spike RBD was detected in immersion fixed paraffin-embedded sections of Human lung infected with SARS delta variant using Llama Anti-SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Monoclonal Antibody (Catalog # LMAB10869) at 1 µg/mL overnight at 4 °C. Tissue was stained using anti-Llama secondaries with HRP and counterstained with hematoxylin (blue). Specific staining was localized to cytoplasm in bronchial epithelial cells. View our protocol for IHC Staining with VisUCyte HRP Polymer Detection Reagents.

Applications for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

Application
Recommended Usage

Blockade of Receptor-ligand Interaction

In a functional flow cytometry test, 50 μg/mL of SARS-Cov-2 Spike RBD Llamabody (Catalog # LMAB10869) will block the binding of Recombinant SARS-Cov-2 Spike 1 Fc-tagged protein (Catalog # 10622-CV) to HEK293 human embryonic kidney cell line transfected with recombinant human ACE-2.

Immunohistochemistry

1-15 µg/mL
Sample: Immersion fixed paraffin-embedded sections of Human lung infected with SARS delta variant

Formulation, Preparation, and Storage

Purification

His-tag purified from cell culture supernatant

Reconstitution

Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Calculators

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: Spike RBD

SARS-CoV-2, which causes the global pandemic coronavirus disease 2019 (Covid-19), belongs to a family of viruses known as coronaviruses that are commonly comprised of four structural proteins: Spike protein(S), Envelope protein (E), Membrane protein (M), and Nucleocapsid protein (N) (1). SARS-CoV-2 Spike Protein (S Protein) is a glycoprotein that mediates membrane fusion and viral entry. The S protein is homotrimeric, with each ~180-kDa monomer consisting of two subunits, S1 and S2 (2). In SARS-CoV-2, as with most coronaviruses, proteolytic cleavage of the S protein into two distinct peptides, S1 and S2 subunits, is required for activation. The S1 subunit is focused on attachment of the protein to the host receptor while the S2 subunit is involved with cell fusion (3-5). Based on structural biology studies, the receptor binding domain (RBD), located in the C-terminal region of S1, can be oriented either in the up/standing or down/lying state (6). The standing state is associated with higher pathogenicity and both SARS-CoV-1 and MERS can access this state due to the flexibility in their respective RBDs. A similar two-state structure and flexibility is found in the SARS-CoV-2 RBD (7). Based on amino acid (aa) sequence homology, the SARS-CoV-2 S1 subunit RBD has 73% identity with the RBD of the SARS-CoV-1 S1 RBD, but only 22% homology with the MERS S1 RBD. The low aa sequence homology is consistent with the finding that SARS and MERS bind different cellular receptors (8). The S Protein of the SARS-CoV-2 virus, like the SARS-CoV-1 counterpart, binds Angiotensin-Converting Enzyme 2 (ACE2), but with much higher affinity and faster binding kinetics (9). Before binding to the ACE2 receptor, structural analysis of the S1 trimer shows that only one of the three RBD domains in the trimeric structure is in the "up" conformation. This is an unstable and transient state that passes between trimeric subunits but is nevertheless an exposed state to be targeted for neutralizing antibody therapy (10). Polyclonal antibodies to the RBD of the SARS-CoV-2 protein have been shown to inhibit interaction with the ACE2 receptor, confirming RBD as an attractive target for vaccinations or antiviral therapy (11). There is also promising work showing that the RBD may be used to detect presence of neutralizing antibodies present in a patient's bloodstream, consistent with developed immunity after exposure to the SARS-CoV-2 virus (12). Lastly, it has been demonstrated the S Protein can invade host cells through the CD147/EMMPRIN receptor and mediate membrane fusion (13, 14).

References

  1. Wu, F. et al. (2020) Nature 579:265.
  2. Tortorici, M.A. and D. Veesler (2019). Adv. Virus Res. 105:93.
  3. Bosch, B.J. et al. (2003). J. Virol. 77:8801.
  4. Belouzard, S. et al. (2009) Proc. Natl. Acad. Sci. 106:5871.
  5. Millet, J.K. and G. R. Whittaker (2015) Virus Res. 202:120.
  6. Yuan, Y. et al. (2017) Nat. Commun. 8:15092.
  7. Walls, A.C. et al. (2010) Cell 180:281.
  8. Jiang, S. et al. (2020) Trends. Immunol. https://doi.org/10.1016/j.it.2020.03.007.
  9. Ortega, J.T. et al. (2020) EXCLI J. 19:410.
  10. Wrapp, D. et al. (2020) Science 367:1260.
  11. Tai, W. et al. (2020) Cell. Mol. Immunol. https://doi.org/10.1016/j.it.2020.03.007.
  12. Okba, N. M. A. et al. (2020). Emerg. Infect. Dis. https://doi.org/10.3201/eid2607.200841.
  13. Wang, X. et al. (2020) https://doi.org/10.1038/s41423-020-0424-9.
  14. Wang, K. et al. (2020) bioRxiv https://www.biorxiv.org/content/10.1101/2020.03.14.988345v1.

Long Name

Spike Receptor Binding Domain

Entrez Gene IDs

3200426 (HCoV-HKU1); 14254594 (MERS-CoV); 1489668 (SARS-CoV); 43740568 (SARS-CoV-2)

Gene Symbol

S

UniProt

YP_009724390.1

Additional Spike RBD Products

Product Documents for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Note: Certificate of Analysis not available for kit components.

Download SDS

Product Specific Notices for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

For research use only

Related Research Areas

Infectious Diseases

Citations for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

Customer Reviews

There are currently no reviews for this product. Be the first to review SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody and earn rewards!

Have you used SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs for SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody

Showing  1 - 1 of 1 FAQ Showing All

  • Q: What is the moelcular weight of SARS-CoV-2 Spike RBD LlamabodyTM VHH His-tag Antibody (Catalog # LMAB10869)?

    A: The molecular weight of monovalent VHH antibodies is approximately 15 kDa.
