StemXVivo Chondrogenic Base Media

R&D Systems | Catalog # CCM005

R&D Systems
Loading...

Key Product Details

Species

Human, Mouse, Rat

Product Summary for StemXVivo Chondrogenic Base Media

Kit Summary

Base media for the differentiation of MSCs into chondrocytes. For use with Human/Mouse and Rat StemXVivo® Chondrogenic Supplements.

Key Benefits

  • Defined formulation that reduces experimental variation
  • Supports induction of chondrogenesis in MSCs
  • Developed and optimized using MSCs

Why Induce Chondrogenesis in MSCs with Defined Media?

Despite the well-characterized factors and protocols used to differentiate mesenchymal stem/stromal cells (MSCs) into chondrocytes, differentiation efficiencies can vary depending on the quality of the MSC starting population and the reagents used to expand and differentiate MSCs.

StemXVivo® Chondrogenic Base Media:

  • Is defined to support reproducible MSC chondrogenesis.
  • Offers flexibility to evaluate novel cytokine and growth factor combinations to induce chondrogenesis.
  • Has been developed and optimized using MSCs.
  • Can be used with StemXVivo® Human/Mouse or Rat Chondrogenic Supplements to reduce variation during chondrogenesis.

Mesenchymal Stromal Cells or Mesenchymal Stem Cells?

The term ‘mesenchymal stromal cells’ is commonly used to describe a heterogeneous population of cultured cells that are adherent to plastic, have a distinct morphology, and express a specific set of marker proteins. Within this heterogeneous population are cells referred to as ‘mesenchymal stem cells.’

Mesenchymal stem cells are multipotent, self-renewing cells that have the ability to differentiate into adipocytes, chondrocytes, and osteoblasts when cultured in vitro. Read More about MSC Nomenclature

Human/Mouse/Rat StemXVivo® Chondrogenic Base Media

Supplied in a 50 mL volume, this media contains high quality factors to drive MSC differentiation into chondrocytes when used with additional differentiation factors.

  • Supplemented with sodium bicarbonate but does not contain antibiotics.

*This medium requires supplements (not included), such as Human/Mouse StemXVivo® Chondrogenic Supplement (Catalog # CCM006), or user-defined cytokines and growth factors to induce chondrogenesis.

Precautions

This product contains human transferrin. The transferrin was purified from donor plasma and tested at the donor level using an FDA licensed method and found to be non-reactive for anti-HIV-1/2 and Hepatitis B surface antigen.

2006 Proposed Change to MSC Nomenclature

Although mesenchymal stromal cells were once referred to as ‘mesenchymal stem cells’, a change to ‘mesenchymal stromal cells’ was proposed by the International Society for Cellular Therapy in 2006.1

The change in nomenclature originates from two important factors:

  • Methods used to isolate mesenchymal stem cells yield a heterogeneous population of cells with only a fraction of these cells demonstrating multipotency.
  • The absence of direct evidence that mesenchymal stem cells can self-renew and differentiate in vivo.

Use of Mesenchymal Stem and Stromal Cell Terminology

Data supporting MSC self-renewal and multipotency have been obtained using in vitro conditions, which does not adequately reflect the in vivo environment. The lack of in vivo data has led some researchers to question the validity of the term ‘mesenchymal stem cell’ providing further support for the use of ‘mesenchymal stromal cells’ to describe MSCs.2 While ‘mesenchymal stromal cells’ may be the more scientifically accurate term for MSCs, the two terms are often used interchangeably in the literature. R&D Systems recognizes the use of both mesenchymal stem cells and mesenchymal stromal cells and uses ‘MSC’ to indicate mesenchymal stem/stromal cells to account for both designations.

Definitions of Mesenchymal Stromal Cells and Mesenchymal Stem Cells

  • Mesenchymal Stromal Cells – A heterogeneous population of cultured cells with similar characteristics such as the ability to adhere to plastic and the expression of specific marker proteins.
  • Mesenchymal Stem Cells – A subpopulation of mesenchymal stromal cells that have the capacity to self-renew and differentiate into mesodermal lineages when cultured in vitro. The capacity to self-renew and differentiate in vivo has yet to be clearly demonstrated for mesenchymal stem cells.

References

  • Dominici, M. et al. (2006) Cytotherapy 8:315.
  • Keating, A. (2012) Cell Stem Cell 10:709.
Loading...

Scientific Data Images for StemXVivo Chondrogenic Base Media

Detection of Aggrecan in a Human MSC-differentiated Chondrogenic Pellet Section.

Detection of Aggrecan in a Human MSC-differentiated Chondrogenic Pellet Section.

Human MSCs were cultured with StemXVivo®Chondrogenic Base Media (Catalog # CCM005) and StemXVivo®Chondrogenic Supplement (Catalog # CCM006) and the resulting chondrogenic pellet was cryosectioned. Chondrocyte differentiation was verified using a Goat Anti-Human Aggrecan Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1220). The cells were stained using a NorthernLights557-conjugated Donkey Anti-Goat Secondary Antibody (Catalog # NL001; red) and the nuclei were counterstained with DAPI (blue).

MSCs Differentiated into Chondrocytes form Characteristic Cell Pellets.

MSCs Differentiated into Chondrocytes form Characteristic Cell Pellets.

MSCs Differentiated into Chondrocytes form Characteristic Cell Pellets.Human MSCs cultured with StemXVivo Chondrogenic Base Media (Catalog # CCM005) and StemXVivo Chondrogenic Supplement (Catalog # CCM006) formed a chondrogenic pellet (ball) imaged here at day 21 of culture.

Detection of Collagen II in a Mouse MSC-differentiated Chondrogenic Pellet Section.

Detection of Collagen II in a Mouse MSC-differentiated Chondrogenic Pellet Section.

Mouse MSCs were cultured for 21 days using the Human/Mouse StemXVivo®Chondrogenic Base Media (Catalog # ;CCM005) and Human/Mouse StemXVivo®Chondrogenic Supplement (Catalog # CCM006) and the resulting chondrogenic pellet was cryosectioned. Chondrocyte differentiation was verified using a Sheep Anti-Mouse Collagen II Antigen Affinity-purified Polyclonal Antibody (Catalog # AF3615). The cells were stained using a NorthernLights557-conjugated Donkey Anti-Sheep Secondary Antibody (Catalog # NL010; red) and the nuclei were counterstained with DAPI (blue).

Detection of Aggrecan in a Rat MSC-differentiated Chondrogenic Pellet Section.

Detection of Aggrecan in a Rat MSC-differentiated Chondrogenic Pellet Section.

Rat MSCs were cultured for 21 days using the Human/Mouse StemXVivo®Chondrogenic Base Media (Catalog # CCM005) and Rat StemXVivo®Chondrogenic Supplement (Catalog # CCM020) and the resulting chondrogenic pellet was cryosectioned. Chondrocyte differentiation was verified using a Goat Anti-Human Aggrecan Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1220). The cells were stained using a NorthernLights557-conjugated Donkey Anti-Goat Secondary Antibody (Catalog # NL001; red) and the nuclei were counterstained with DAPI (blue).

Formulation, Preparation, and Storage

Shipping

The product is shipped with dry ice or equivalent. Upon receipt, store it immediately at the temperature recommended below.

Storage

Store the unopened product at -20 to -70 °C. Use a manual defrost freezer and avoid repeated freeze-thaw cycles. Do not use past expiration date.

Background: Mesenchymal Stem Cells

The term 'mesenchymal stem cells' (MSCs) is most commonly used to describe multipotent self-renewing cells that can be differentiated in vitro to generate adipocytes, chondrocytes, and osteoblasts. However, because these biological properties and hierarchical relationships remain to be clearly demonstrated in vivo, the term 'multipotent mesenchymal stromal cells' is often used to distinguish cultured cells from their in vivo precursors. Originally discovered in mouse bone marrow, multipotent mesenchymal stromal cells cultured from a variety of species and tissue types, have been shown to differentiate into progeny of additional lineages including, cardiomyocytes, endothelial cells, hepatocytes, and neural cells. Again, the physiological relevance of these findings remains to be determined.

Alternate Names

AEG1, LYRIC, LYRIC/3D3, metadherin

Additional Mesenchymal Stem Cells Products

Product Documents for StemXVivo Chondrogenic Base Media

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for StemXVivo Chondrogenic Base Media

For research use only

Citations for StemXVivo Chondrogenic Base Media

Customer Reviews for StemXVivo Chondrogenic Base Media

There are currently no reviews for this product. Be the first to review StemXVivo Chondrogenic Base Media and earn rewards!

Have you used StemXVivo Chondrogenic Base Media?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for StemXVivo Chondrogenic Base Media (CCM005):

Refer to the product datasheet for complete product details.

Briefly, human, mouse, or rat MSCs are differentiated into chondrocytes using the following in vitro differentiation procedure:

  • Culture multipotent cells of interest
  • Induce chondrogenic differentiation using a media supplement
  • Evaluate differentiation using a mature phenotype marker antibody and fluorescent ICC

For use with Human/Mouse StemXVivo® Chondrogenic Supplement (Catalog # CCM006).
View Graphic Procedure




Reagents Provided

Reagents supplied in the Human/Mouse/Rat Chondrogenic Base Media (Catalog # CCM005):

  • 50 mL of StemXVivo® Chondrogenic Base Media

Other Supplies Required

Reagents

  • Human/Mouse StemXVivo® Chondrogenic Supplement (Catalog # CCM006
  • Penicillin-Streptomycin-Glutamate (100X)

Materials

  • MSCs
  • 15 mL centrifuge tubes
  • Pipettes and pipette tips
  • Serological pipettes

Equipment

  • 37 °C and 5% CO2 incubator
  • Centrifuge
  • Hemocytometer
  • Inverted microscope
  • 2 °C to 8 °C refrigerator
  • 37 °C water bath



Procedure Overview

This protocol has been tested using bone marrow- and/or adipose tissue-derived MSCs. If using a different tissue source or cell line, the protocol below may need to be optimized.

  1. Transfer 2.5 x 105 MSCs to a 15 mL conical tube.
  2. Centrifuge and resuspend the cells in Chondrogenic Differentiation Medium.
  3. Centrifuge the cells but do not remove the medium.
  4. Every 2-3 days, replace with fresh Chondrogenic Differentiation Medium.
  5. After 14-21 days, the chondrogenic pellet can be harvested and analyzed.

FAQs for StemXVivo Chondrogenic Base Media

Showing  1 - 1 of 1 FAQ Showing All
  • Q: Are there any experimental tips/hints for successful chondrogenic differentiation of mesenchymal stem cells?

    A: The following tips/hints are useful for chondrogenic differentiation: a) The mesenchymal stem cells (MSCs) should not be from a late passage (passage 8 or less), b) if using the Human Mesenchymal Stem Cell Functional Identification Kit (Catalog # SC006) or the StemXVivo® Chondrogenic Supplement (Catalog # CCM006), use the starting MSC cell number that is indicated in the protocol, c) Early during chondrogenic differentiation a pellet should form. As differentiation progresses, the pellet will grow and take up a ball-like appearance. d) The pellet should not attach to the tube, therefore care should be taken to not dislodge it while changing media.
