STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free

Novus Biologicals | Catalog # NBP2-74402

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Human

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2A Clone # OTI4H1

Format

Azide and BSA Free
View all STING/TMEM173 Primary Antibodies »

Product Specifications

Immunogen

This STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free was developed against full length human recombinant protein of human STING/TMEM173 (NP_938023) produced in HEK293T cell.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2A

Theoretical MW

42 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free

Western Blot: STING/TMEM173 Antibody (OTI4H1)Azide and BSA Free [NBP2-74402]

Western Blot: STING/TMEM173 Antibody (OTI4H1)Azide and BSA Free [NBP2-74402]

Western Blot: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of HEK293T cells were transfected with the pCMV6-ENTRY control (Left lane) or pCMV6-ENTRY TMEM173.
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Human prostate tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Western Blot: STING/TMEM173 Antibody (OTI4H1)Azide and BSA Free [NBP2-74402]

Western Blot: STING/TMEM173 Antibody (OTI4H1)Azide and BSA Free [NBP2-74402]

Western Blot: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of extracts (35ug) from 9 different cell lines (HepG2: human; HeLa: human; SVT2: mouse; A549: human; COS7: monkey; Jurkat: human; MDCK: canine; PC12: rat; MCF7: human).
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Adenocarcinoma of Human breast tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Adenocarcinoma of Human colon tissue STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Adenocarcinoma of Human ovary tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Carcinoma of Human bladder tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Carcinoma of Human lung tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Carcinoma of Human pancreas tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Carcinoma of Human prostate tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Carcinoma of Human thyroid tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Human pancreas tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)
Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402]

Immunohistochemistry: STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free [NBP2-74402] - Analysis of Human thyroid tissue using STING/TMEM173 Antibody (OTI4H1). (Heat-induced epitope retrieval by 10mM citric buffer, pH6.0, 120C for 3min)

Applications for STING/TMEM173 Antibody (OTI4H1) - Azide and BSA Free

Application
Recommended Usage

Immunohistochemistry

1:100

Immunohistochemistry-Paraffin

1:100

Western Blot

1:2000

Formulation, Preparation, and Storage

Purification

Immunogen affinity purified

Reconstitution

we recommend adding 100uL distilled water to a final antibody concentration of about 1 mg/mL. To use this carrier-free antibody for conjugation experiment, we strongly recommend performing another round of desalting process.

Formulation

Lyophilized from PBS (pH 7.3) with 8% Trehalose

Format

Azide and BSA Free

Preservative

No Preservative

Concentration

LYOPH mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at -20C. Avoid freeze-thaw cycles.

Calculators

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: STING/TMEM173

STING (stimulator of interferon genes) is encoded by the TMEM173 gene and is an adaptor molecule involved in the activation of innate immune responses to PAMPS (pathogen-associated molecular patterns) and DAMPS (damage-associated molecular patterns). STING specifically recognizes cytosolic DNA products derived from pathogens (e.g., cytomegalovirus, vaccinia virus, Listeria monocytogenes) or dead cells (1, 2). In the STING pathway, dsDNA derived from pathogens or damaged cells serves as a substrate for the enzyme cGAS (cyclic GMP-AMP synthase) which produces the second messenger cyclic GMP-AMP (cGAMP) from ATP and GTP (3, 4). Under steady-state conditions STING (theoretical molecular weight 42 kDa), a protein localizes to the ER membrane. Upon activation by dsDNA derived second messenger (cGAMP), STING translocates to the Golgi apparatus as a homodimer. Once STING has trafficked to the perinuclear region, it activates TANK binding kinase 1 (TBK1), interferon regulatory factor 3 (IRF3) and NF-kB leading to the production of cytokines (e.g., type I interferon) (2, 4). Mutations in the TMEM173 gene affecting STING expression are associated with the development of the auto-inflammatory disease SAVI (STING-associated vasculopathy with onset in infancy) (2). A novel SAVI dominant mutation in the TMEM173 human gene (V155M) leads to increased localization of STING to the Golgi and perinuclear region, indicative of an activated state (1). Hallmarks of SAVI, a rare inflammatory disease, include severe vasculitis in extremities and lung inflammation (7).

References

1. Patel, S., & Jin, L. (2019). TMEM173 variants and potential importance to human biology and disease. Genes and Immunity. https://doi.org/10.1038/s41435-018-0029-9

2. Jounai, N., Kobiyama, K., Takeshita, F., & Ishii, K. J. (2013). Recognition of damage-associated molecular patterns related to nucleic acids during inflammation and vaccination. Frontiers in Cellular and Infection Microbiology. https://doi.org/10.3389/fcimb.2012.00168

3. Xiao, T. S., & Fitzgerald, K. A. (2013). The cGAS-STING Pathway for DNA Sensing. Molecular Cell. https://doi.org/10.1016/j.molcel.2013.07.004

4. Kato, K., Omura, H., Ishitani, R., & Nureki, O. (2017). Cyclic GMP-AMP as an Endogenous Second Messenger in Innate Immune Signaling by Cytosolic DNA. Annual Review of Biochemistry. https://doi.org/10.1146/annurev-biochem-061516-044813

5. Crowl, J. T., Gray, E. E., Pestal, K., Volkman, H. E., & Stetson, D. B. (2017). Intracellular Nucleic Acid Detection in Autoimmunity. Annual Review of Immunology. https://doi.org/10.1146/annurev-immunol-051116-052331

Long Name

Stimulator of Interferon Genes Protein/Transmembrane protein 173

Alternate Names

ERIS, MITA, MPYS, NET23, TMEM173

Gene Symbol

STING1
