CD3 zeta Antibody (BL-336-1B2)
Novus Biologicals | Catalog # NBP2-76399
Recombinant Monoclonal Antibody
Loading...
Key Product Details
Species Reactivity
Validated:
Human
Predicted:
Mouse (100%), Porcine (100%), Sheep (100%). Backed by our 100% Guarantee.
Applications
Multiplex Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Simple Western, Immunoprecipitation
Label
Unconjugated
Antibody Source
Recombinant Monoclonal Rabbit IgG Clone # BL-336-1B2
Loading...
Product Specifications
Immunogen
Immunogen sequence between amino acids 150-164 (C-Term)
Clonality
Monoclonal
Host
Rabbit
Isotype
IgG
Scientific Data Images for CD3 zeta Antibody (BL-336-1B2)
Simple Western: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] -
Simple Western: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Detection of human CD247/CD3Z by Simple Western. Samples: Whole cell lysate (2.0 mg/mL) from Jurkat cells prepared using NETN lysis buffer. Antibody: Rabbit anti-CD247/CD3Z recombinant monoclonal antibody [BL-336-1B2] (NBP2-76399) used at 1:10, 1:50, 1:250. Separation and Detection: SallySue ProteinSimple instrument with the 12-230 kDa separation module and anti-Rabbit detection module. Left Panel: Virtual Lane View. Right Panel: Electropherogram. Image validated internally.![Flow Cytometry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]](https://resources.rndsystems.com/images/products/CD3-zeta-Antibody-BL-336-1B2-Flow-Cytometry-NBP2-76399-img0007.jpg "Flow Cytometry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]")
Flow Cytometry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]
Flow Cytometry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Jurkat cells were fixed in 4% formaldehyde and permeabilized with 90% methanol. Antibody: 1E6 cells were incubated with 0.5 ul of rabbit anti-CD247/CD3Zrecombinant monoclonal antibody [BL-336-1B2] (red shaded) or isotype control(unshaded). Secondary: DyLight® 650-conjugated goat anti-rabbit IgG.![Immunohistochemistry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]](https://resources.rndsystems.com/images/products/CD3-zeta-Antibody-BL-336-1B2-Immunohistochemistry-NBP2-76399-img0006.jpg "Immunohistochemistry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]")
Immunohistochemistry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]
Immunohistochemistry: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Section of human tonsil. Antibody: Rabbit anti-CD247/CD3Z recombinantmonoclonal antibody [BL-336-1B2] used at 1:250. Secondary: HRP-conjugated goat anti-rabbit IgG. Substrate: Opal™. Counterstain: DAPI (blue).![Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]](https://resources.rndsystems.com/images/products/CD3-zeta-Antibody-BL-336-1B2-Immunohistochemistry-Paraffin-NBP2-76399-img0009.jpg "Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]")
Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]
Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Antibody: Rabbit anti-CD247/CD3Z recombinant monoclonal [BL-336-1B2].Secondary: HRP-conjugated goat anti-rabbit IgG. Substrate: DAB.![Immunoprecipitation: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]](https://resources.rndsystems.com/images/products/CD3-zeta-Antibody-BL-336-1B2-Immunoprecipitation-NBP2-76399-img0008.jpg "Immunoprecipitation: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]")
Immunoprecipitation: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399]
Immunoprecipitation: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Detection of human CD247/CD3Z by WB of immunoprecipitates from Jurkat lysate.Antibodies: Rabbit anti-CD247/CD3Z recombinant monoclonal antibody [BL-336-1B2] (NBP2-76399).
Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] -
Immunohistochemistry-Paraffin: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Rabbit antiCD247/CD3Z recombinant monoclonal antibody[BL-336-1B2]. (Secondary: HRPconjugated goat anti-rabbit IgG. Substrate:DAB.
Western Blot: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] -
Western Blot: CD3 zeta Antibody (BL-336-1B2) [NBP2-76399] - Whole cell lysate (10 ug) from Jurkat, U2OS, SR, HEK293T, and MOLT-4 cells prepared using NETN lysis buffer. Antibody: Rabbit anti-CD247/CD3Z recombinant monoclonal antibody [BL-336-1B2] used at 1:1000. Secondary: HRP-conjugated goat anti-rabbit IgG. Detection: Chemiluminescence with an exposure time of 75 seconds. Lower Panel: Rabbit antiCOPB2 antibody.Applications for CD3 zeta Antibody (BL-336-1B2)
Application
Recommended Usage
Flow Cytometry
0.5 ul per 1 - 10^6 cells
Immunocytochemistry/ Immunofluorescence
1:100 - 1:500
Immunohistochemistry
1:100 - 1:500
Immunohistochemistry-Paraffin
1:100 - 1:500
Immunoprecipitation
20 ul/mg lysate
Simple Western
1:10-1:250
Western Blot
1:1000
Application Notes
Epitope retrieval with citrate buffer pH6.0 is recommended for FFPE tissue sections.
See Simple Western Antibody Database for Simple Western validation: Tested in Jurkat [2.0 mg/mL], separated by Size, antibody dilution of 1:10, 1:50, 1:250, apparent MW was 23-24 kDa
See Simple Western Antibody Database for Simple Western validation: Tested in Jurkat [2.0 mg/mL], separated by Size, antibody dilution of 1:10, 1:50, 1:250, apparent MW was 23-24 kDa
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Formulation
Borate Buffered Saline (BBS) pH 8.2 with 0.1% BSA
Preservative
0.09% Sodium Azide
Concentration
Please see the vial label for concentration. If unlisted please contact technical services.
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 2 - 8 C / 1 year from date of receipt
Background: CD3 zeta/CD247
Long Name
T-cell Receptor zeta
Alternate Names
CD247, CD3H, CD3Q, CD3Z, IMD25, T3Z, TCR Zeta Chain
Gene Symbol
CD247
Additional CD3 zeta/CD247 Products
Product Documents for CD3 zeta Antibody (BL-336-1B2)
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for CD3 zeta Antibody (BL-336-1B2)
This Product sold under License from Bethyl Laboratories, Inc.
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
