Interleukin12 (IL-12) is a key mediator of cellular-immunity and induces the differentiation of Th1 cells from precursor T helper cells. The biological activities of IL-12 are mediated through the high-affinity receptor complex composed of two subunits designated IL-12 R beta 1 and IL-12 R beta 2. Individually, IL-12 R beta 1 and IL-12 R beta 2 bind IL‑12 with low affinity. Co-expression of both subunits confers high-affinity binding and is required for IL-12 activity. Both IL-12 receptor subunits are type I transmembrane proteins that share similarities with the gp130/G-CSF R subgroup in the cytokine receptor superfamily. IL-12 R beta 1 cDNA encodes a 662 amino acid (aa) protein with a putative 23 aa signal peptide that is cleaved to generate the mature protein with a 522 aa extracellular domain, a 25 aa transmembrane domain and a 92 aa cytoplasmic region. Expression of IL-12 R beta 1 is detected in activated T cells, NK cells and B cells. The expression of IL‑12 R beta 2 is more restricted and appears to be limited to Th2 cells.
Human IL‑12 R beta 1 APC‑conjugated Antibody
R&D Systems | Catalog # FAB839A
Key Product Details
Validated by
Species Reactivity
Applications
Label
Antibody Source
Product Specifications
Immunogen
Cys24-Glu540
Accession # P42701
Specificity
Clonality
Host
Isotype
Scientific Data Images for Human IL‑12 R beta 1 APC‑conjugated Antibody
Detection of IL‑12 R beta 1 in Daudi cells by Flow Cytometry.
Daudi cells were stained with Mouse Anti-Human IL‑12 R beta 1 APC‑conjugated Monoclonal Antibody (Catalog # FAB839A, filled histogram) or isotype control antibody (Catalog # IC002A, open histogram). View our protocol for Staining Membrane-associated Proteins.Detection of IL‑12 R beta 1 in PBMC cells by Flow Cytometry.
PBMC cells treated with 5ug/ml PHA (Sigma) for 48-72 hours were stained with Mouse Anti-Human CD3 epsilon PE‑conjugated Monoclonal Antibody (Catalog # FAB100P) and either (A) Mouse Anti-Human IL‑12 R beta 1 APC‑conjugated Monoclonal Antibody (Catalog # FAB839A) or (B) Mouse IgG1 Allophycocyanin Isotype Control (Catalog # IC002A). View our protocol for Staining Membrane-associated Proteins.Applications for Human IL‑12 R beta 1 APC‑conjugated Antibody
Flow Cytometry
Sample: PBMC treated with 5ug/ml PHA (Sigma) for 48-72 hours and Daudi cells.
Spectra Viewer
Plan Your Experiments
Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.
Spectra ViewerFlow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, 2 to 8 °C as supplied.
Background: IL-12 R beta 1
References
- Gately, M.K. et al. (1998) Annu. Rev. Immunol. 16:495.
Long Name
Alternate Names
Gene Symbol
UniProt
