Tenascin R (TNR) is an extracellular matrix glycoprotein belonging to the tenascin family of adhesion proteins (1-3). TNR is expressed in the central nervous system by oligodendrocytes and selected inhibitory interneurons. It shows highest expression during the postnatal period of active myelination and promotes neurite outgrowth and synaptic functions (1, 2). It is essential for formation of perineuronal nets, the mesh-like network of extracellular matrix (ECM) molecules that surrounds some neurons (4). The 180 kDa, 1327 amino acid (aa) form of human TNR contains a signal sequence, three heptad repeats that mediate coiled-coil trimer formation, five EGF-like repeats, nine fibronectin type III repeats (FN), and a C-terminal Ca2+-binding fibrinogen-related domain. TNR isoform 2 (160 kDa) lacks a portion of FN#6 (aa 773-862) (3). Mature human TNR isoform 1 shows 94%, 94%, 93%, 93%, and 76% aa identity with bovine, mouse, rat, canine, and chicken TNR, respectively. Experiments using recombinant TNR fragments indicate that EGF-like domains are counteradhesive for neurons and microglia and contribute to their migration (1, 5-7). This region interacts with immunoglobulin superfamily molecules including contactin, phosphacan and voltage-gated sodium channel beta subunits. However, the fibronectin domains are adhesive for the lectican family of chondroitin sulfate proteoglycans (brevican, aggrican, versican and neurocan; FN 3-5), contactin (FN 2-3) and sodium channel beta subunits (FN 6-8) (6-9). These adhesive interactions can compete with each other, but can also contribute to crosslinking of lecticans and contactin with other ECM molecules to form perineuronal nets (9, 10). Post-translational modification of TNR can differ with time and location (11). Notably, glycosylation may include GalNAc-4-SO4, O-linked sialylated glycans, “brain-type” neutral N-glycans and the HNK-1 carbohydrate epitope that is thought to be involved in regulation of synaptic plasticity (11, 12).
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Product Specifications
Immunogen
Glu34-Phe1358
Accession # Q92752
Specificity
Clonality
Host
Isotype
Scientific Data Images for Human Tenascin R Antibody
Tenascin R in Human Brainstem.
Tenascin R was detected in immersion fixed paraffin-embedded sections of human brainstem (medulla) using 1.7 µg/mL Goat Anti-Human Tenascin R Antigen Affinity-purified Polyclonal Antibody (Catalog # AF3865) overnight at 4 °C. Tissue was stained with the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.Detection of Tenascin R by Immunohistochemistry
CAQK and tenascins in EAE lesions. (A–D) Confocal images identify FAM-CAQK peptide (A,E,I, green) at DAPI+ lesion clusters (B,F,J, blue) in the lumbar spinal cord of mice with EAE. The peptide does not associate with damaged myelin stained for MBP (C, magenta; merge in D) and largely complements staining for tenascin-R (G, magenta; merge in H). Some overlap is detected between FAM-CAQK and fibrous tenascin-C deposition (K, magenta) as indicated by the white signal in the merged image (L, arrowheads). Note that the majority of the lesion site covered by the peptide is negative for either tenascin (H,L). Scale bars: 20 μm. Image collected and cropped by CiteAb from the following open publication (https://pubmed.ncbi.nlm.nih.gov/36072569), licensed under a CC-BY license. Not internally tested by R&D Systems.Detection of Tenascin R by Immunohistochemistry
Marginal CAQK peptide association with tenascins in the cuprizone model. Confocal images from the demyelinating corpus callosum of mice on a 6-week cuprizone diet show FAM-CAQK peptide (A,C, green) in complementary distribution with tenascin-R (B, magenta); merged images in (C). FAM-CAQK peptide (D) shows marginal association (white puncta pointed out by arrows in F) with tenascin-C (E magenta). DAPI-staining (blue) indicates cell nuclei in (C,F). D, dorsal; V, ventral; L, lateral; M, medial. Scale bar = 50 μm. Image collected and cropped by CiteAb from the following open publication (https://pubmed.ncbi.nlm.nih.gov/36072569), licensed under a CC-BY license. Not internally tested by R&D Systems.Applications for Human Tenascin R Antibody
Immunohistochemistry
Sample: Immersion fixed paraffin-embedded sections of human brainstem (medulla)
Western Blot
Sample: Recombinant Human Tenascin R (Catalog # 3865-TR)
Reviewed Applications
Read 1 review rated 5 using AF3865 in the following applications:
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: Tenascin R
References
- Jones, F.S. and P.L. Jones (2000) Dev. Dyn. 218:235.
- Dityatev, A. and M. Schachner (2006) Cell Tissue Res. 326:647.
- Carnemolla, B. et al. (1996) J. Biol. Chem. 271: 8157.
- Weber, P. et al. (1999) J. Neurosci. 19:4245.
- Xiao, Z.C. et al. (1997) J. Neurosci. Res. 49:698.
- Xiao, Z.C. et al. (1999) J. Biol. Chem. 274:26511.
- Liao, H. et al. (2005) J. Biol. Chem. 280:8316.
- Aspberg, A. et al. (1997) Proc. Natl. Acad. Sci. USA 94:10116.
- Lundell, A. et al. (2004) Structure 12:1495.
- Zacharias, U. and U. Rauch (2006) J. Cell Sci. 119:3456.
- Woodworth, A. et al. (2004) J. Biol. Chem. 279:10413.
- Zamze, S. et al. (1999) Glycobiology 9:823.
Alternate Names
Gene Symbol
UniProt
Additional Tenascin R Products
Product Documents for Human Tenascin R Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Human Tenascin R Antibody
For research use only
Related Research Areas
Citations for Human Tenascin R Antibody
Customer Reviews for Human Tenascin R Antibody (1)
Have you used Human Tenascin R Antibody?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 for a review with an image
$10/€7/£6/$10CAN/¥1110 for a review without an image
Submit a review
-
Application: Immunohistochemistry-ParaffinSample Tested: See PMID 24269935Species: OtherVerified Customer | Posted 01/08/2015
There are no reviews that match your criteria.
