Human WISP-1/CCN4 Antibody

Catalog # Availability Size / Price Qty
Human WISP-1/CCN4 Antibody in Data
1 Image
Product Details
Citations (1)
Supplemental Products

Human WISP-1/CCN4 Antibody Summary

Species Reactivity
Detects human WISP‑1/CCN4 in direct ELISAs and Western blots. In direct ELISAs and Western blots, approximately 50% cross-reactivity with recombinant mouse WISP-1 is observed and less than 1% cross-reactivity with recombiant human (rh) CTGF and rhNOV is observed.
Polyclonal Goat IgG
Antigen Affinity-purified
Mouse myeloma cell line NS0-derived recombinant human WISP‑1/CCN4
Accession # O95388
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.


Recommended Concentration
Western Blot
0.1 µg/mL
Recombinant Human WISP‑1/CCN4 (Catalog # 1627-WS)
5-15 µg/mL
See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Data Example

Immunohistochemistry WISP‑1/CCN4 antibody in Human Breast Cancer Tissue by Immunohistochemistry (IHC-P). View Larger

WISP‑1/CCN4 in Human Breast Cancer Tissue. WISP‑1/CCN4 was detected in immersion fixed paraffin-embedded sections of human breast cancer tissue using 15 µg/mL Goat Anti-Human WISP‑1/CCN4 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1627) overnight at 4 °C. Tissue was stained with the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Preparation and Storage

Reconstitute at 0.2 mg/mL in sterile PBS.
Reconstitution Buffer Available
Reconstitution Buffer 1 (PBS)
Catalog #
Size / Price
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: WISP-1/CCN4

Human WISP-1 (Wnt-induced secreted protein-1; also CNN4) is a 40 kDa, secreted, heparin-binding glycoprotein that is a member of the CCN (or CTGF/Cyr61/Nov) cysteine-rich protein family (1‑5). It is synthesized as a 367 aa precursor that contains a series of structural homology modules. Following a 22 amino acid (aa) signal sequence, there is a 68 aa IGFBP-like domain (aa 53‑120), a 57 aa von Willebrand factor type C (VWC) module (aa 126‑182), a 40 aa TSP type I domain (aa 220‑259) and a 75 aa, C-terminal cysteine knot motif (aa 273‑347). The VWC module is associated with protein-protein interaction, the TSP domain binds sulfated glycoconjugates, and the cysteine knot mediates dimerization and receptor binding (4). It is likely that WISP-1 normally circulates as an 80 kDa homodimer (2). At least five alternative splice forms are known for WISP-1. One is 30 kDa in size, 258 aa in length, and shows a substitution of a His for aa 95‑182. This removes the VWC domain (2, 6). A second isoform is 155 aa in length and shows a frameshift at Arg 117 with a unique 38 aa C‑terminal extension. A third is 195 aa in length and shows a 31 aa substitution for the first 203 aa of the full length precursor (6). This retains the VWC and cysteine knot domains. A fourth shows a 43 aa substitution for aa 117‑367 for a total length of 163 aa. This effectively removes everything but the IGFBP-like domain (7). The last splice form contains a deletion of aa 25‑269 for a total length of 122 aa. Thus, only the signal sequence and cysteine knot motifs are retained (8). This leaves only the IGFBP-like domain (9). Full-length mature human WISP-1 is 85% aa identical to both mouse and rat WISP-1. WISP-1 is expressed by osteoblasts and may contribute to fracture healing by promoting bone cell formation (10, 11).

  1. Pennica, D. et al. (1998) Proc. Natl. Acad. Sci. USA 95:14717.
  2. Tanada, S. et al. (2001) Oncogene 20:5525.
  3. Brigstock, D.R. et al. (2003) J. Clin. Pathol. Mol. Pathol. 56:127.
  4. Desnoyers, L. (2004) Curr. Pharm. Des. 10:3913.
  5. Brigstock, D.R. (2003) J. Endocrinol. 178:169.
  6. Li, Z. (2005) GenBank Accession # AAP43925.
  7. Li, Z. (2005) GenBank Accession # AAP43926.
  8. Li, Z. (2005) GenBank Accession # AAP43924.
  9. Cervello, M. et al. (2004) Ann. N.Y. Acad. Sci. 1028:432.
  10. French, D.M. et al. (2004), Am. J. Pathol. 165:855.
  11. Parisi, M.S. et al. (2006) Bone 38:671.
Long Name
Wnt-1 Induced Secreted Protein 1
Entrez Gene IDs
8840 (Human); 22402 (Mouse); 102125044 (Cynomolgus Monkey)
Alternate Names
CCN family member 4; CCN4; CCN4WISP1tc; WISP1; WISP-1; WISP1c; WISP1i; WNT1 induced secreted protein 1; WNT1 inducible signaling pathway protein 1; Wnt-1 inducible signaling pathway protein 1; wnt-1 signaling pathway protein 1; Wnt-1-induced secreted protein; WNT1-inducible-signaling pathway protein 1

Product Datasheets

Citation for Human WISP-1/CCN4 Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

1 Citation: Showing 1 - 1

  1. Macrophage-derived IL-10 mediates mucosal repair by epithelial WISP-1 signaling
    Authors: M Quiros, H Nishio, PA Neumann, D Siuda, JC Brazil, V Azcutia, R Hilgarth, MN O'Leary, V Garcia-Her, G Leoni, M Feng, G Bernal, H Williams, PH Dedhia, C Gerner-Smi, J Spence, CA Parkos, TL Denning, A Nusrat
    J. Clin. Invest., 2017;0(0):.
    Species: Mouse
    Sample Types: In Vivo
    Applications: Neutralization
