MAP2 Antibody (5B7) - BSA Free

Novus Biologicals | Catalog # NBP2-37734

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Human

Applications

Western Blot, ELISA, Flow Cytometry, CyTOF-ready

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG1 Clone # 5B7

Format

BSA Free
View all MAP2 Primary Antibodies »

Product Specifications

Immunogen

Purified recombinant fragment of human MAP2 (AA: 24-123) expressed in E. Coli.

Localization

Cytoskeleton

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1

Theoretical MW

199 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Description

Novus Biologicals Mouse MAP2 Antibody (5B7) - BSA Free (NBP2-37734) is a monoclonal antibody validated for use in WB, ELISA and Flow. All Novus Biologicals antibodies are covered by our 100% guarantee.

Scientific Data Images for MAP2 Antibody (5B7) - BSA Free

Western Blot: MAP2 Antibody (5B7)BSA Free [NBP2-37734]

Western Blot: MAP2 Antibody (5B7)BSA Free [NBP2-37734]

Western Blot: MAP2 Antibody (5B7) [NBP2-37734] - Western blot analysis using MAP2 mAb against human MAP2 recombinant protein. (Observed MW is 36.1 kDa)
Flow Cytometry: MAP2 Antibody (5B7) - BSA Free [NBP2-37734]

Flow Cytometry: MAP2 Antibody (5B7) - BSA Free [NBP2-37734]

Flow Cytometry: MAP2 Antibody (5B7) [NBP2-37734] - Flow cytometric analysis of HeLa cells using MAP2 Antibody (5B7) (green) and negative control (red).
ELISA: MAP2 Antibody (5B7) - BSA Free [NBP2-37734]

ELISA: MAP2 Antibody (5B7) - BSA Free [NBP2-37734]

ELISA: MAP2 Antibody (5B7) [NBP2-37734] - Red: Control Antigen (100ng); Purple: Antigen (10ng); Green: Antigen (50ng); Blue: Antigen (100ng);

Applications for MAP2 Antibody (5B7) - BSA Free

Application
Recommended Usage

ELISA

1:10000

Flow Cytometry

1:200 - 1:400

Western Blot

1:500 - 1:2000
Application Notes
This antibody is Cytof ready.

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: MAP2

Microtubule-associated protein 2 also known as MAP2 (theoretical molecular weight 280 kDa) belongs to the MAP2/Tau family which in addition to the two neuronal forms MAP2 and Tau also includes MAP4 (1). For MAP2, four different isoforms have been identified which are produced through alternative splicing including MAP2a, MAP2b, MAP2c and MAP2d (1). MAP2 isoforms contain multiple microtubule-binding domains located near the carboxy terminal, a variably sized amino-terminal projection domain, and a conserved protein kinase A binding domain. MAP2c and MAP2d isoforms have a shorter amino-terminal projection domain, lower molecular weight and are identifiable at ~70 kDa in SDS-PAGE analysis (2,3). MAP2's carboxy terminal domain supports interactions with microtubules, actin, and intermediate filaments (2).

MAP2 isoforms are developmentally regulated and differentially expressed in neurons and some glia. MAP2c is predominantly expressed in the developing brain while the other isoforms are expressed in the adult brain. The distribution of MAP2 isoforms also varies, with MAP2a and MAP2b predominantly localized to dendrites, while MAP2c is also found in axons. Lastly, the expression of MAP2d is not limited to neurons and may be found in glia, specifically oligodendrocytes (1, 2). MAP2 isoforms associate with microtubules and mediate their interaction with actin filaments thereby playing a critical role in organizing the microtubule-actin network. In neurons, MAP2 isoforms are implicated in different processes including neurite initiation, elongation and stabilization as well as axon and dendrite formation (2). Knockout of MAP expression in animal models results in a variety of functional and structural brain defects according to the isoform affected (e.g., reduced LTP and LTD, reduced myelination, absence of corpus collosum, motor system malfunction, abnormal hippocampal dendritic morphology, abnormal synaptic plasticity) (4).

References

1. Dehmelt, L., & Halpain, S. (2005). The MAP2/Tau family of microtubule-associated proteins. Genome Biology. https://doi.org/10.1186/gb-2004-6-1-204

2. Mohan, R., & John, A. (2015). Microtubule-associated proteins as direct crosslinkers of actin filaments and microtubules. IUBMB Life. https://doi.org/10.1002/iub.1384

3. Shafit-Zagardo, B., & Kalcheva, N. (1998). Making sense of the multiple MAP-2 transcripts and their role in the neuron. Molecular Neurobiology. https://doi.org/10.1007/BF02740642

4. Tortosa, E., Kapitein, L. C., & Hoogenraad, C. C. (2016). Microtubule organization and microtubule-associated proteins (MAPs). In Dendrites: Development and Disease. https://doi.org/10.1007/978-4-431-56050-0_3

Long Name

Microtubule-associated Protein 2

Alternate Names

DKFZp686I2148, MAP-2, MAP2A, MAP2B, MAP2C, Microtubule Associated Protein 2, microtubule-associated protein 2, MTAP2

Gene Symbol

MAP2
