Nav1.7 Antibody (N68/6) - BSA Free
Novus Biologicals | Catalog # NBP2-12904
![Western Blot: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Western-Blot-NBP2-12904-img0013.jpg "Western Blot: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Key Product Details
Species Reactivity
Validated:
Human, Mouse, Rat, Hamster
Cited:
Mouse
Applications
Validated:
Immunohistochemistry, Immunohistochemistry-Paraffin, Immunohistochemistry-Frozen, Western Blot, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation, Microarray
Cited:
Western Blot
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG1 Clone # N68/6
Format
BSA Free
Loading...
Product Specifications
Immunogen
Fusion protein amino acids 1751-1946 (C-terminus) of human Nav1.7
Localization
Membrane, Synapse
Specificity
Detects approx 230kDa. No cross-reactivity against other Nav channels.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG1
Scientific Data Images for Nav1.7 Antibody (N68/6) - BSA Free
Western Blot: Nav1.7 Antibody (N68/6) [NBP2-12904]
Western Blot: Nav1.7 Antibody (N68/6) [NBP2-12904] - Western Blot analysis of Hamster CHO cells showing detection of Nav1.7 Sodium Channel protein using Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody, Clone N68/6 (NBP2-12904). Load: 15 ug. Block: 1.5% BSA for 30 minutes at RT. Primary Antibody: Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody (NBP2-12904) at 1:1000 for 2 hours at RT. Secondary Antibody: Sheep Anti-Mouse IgG: HRP for 1 hour at RT.![Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Immunocytochemistry-Immunofluorescence-NBP2-12904-img0017.jpg "Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]
Immunocytochemistry/Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904] - Immunocytochemistry/Immunofluorescence analysis using Mouse Anti-Nav1.7 Monoclonal Antibody, Clone N68/6 (NBP2-12904). Tissue: Neuroblastoma cells (SH-SY5Y). Species: Human. Fixation: 4% PFA for 15 min. Primary Antibody: Mouse Anti-Nav1.7 Monoclonal Antibody (NBP2-12904) at 1:100 for overnight at 4C with slow rocking. Secondary Antibody: AlexaFluor 488 at 1:1000 for 1 hour at RT. Counterstain: Phalloidin-iFluor 647 (red) F-Actin stain; Hoechst (blue) nuclear stain at 1:800, 1.6mM for 20 min at RT. (A) Hoechst (blue) nuclear stain. (B) Phalloidin-iFluor 647 (red) F-Actin stain. (C) Nav1.7 Antibody (D) Composite.![Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Immunohistochemistry-NBP2-12904-img0016.jpg "Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904] - Immunohistochemistry analysis using Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody, Clone N68/6 (NBP2-12904). Tissue: backskin. Species: Mouse. Fixation: Bouin's Fixative and paraffin-embedded. Primary Antibody: Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody (NBP2-12904) at 1:100 for 1 hour at RT. Secondary Antibody: FITC Goat Anti-Mouse (green) at 1:50 for 1 hour at RT.![Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Immunocytochemistry-Immunofluorescence-NBP2-12904-img0007.jpg "Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Immunocytochemistry/ Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904]
Immunocytochemistry/Immunofluorescence: Nav1.7 Antibody (N68/6) [NBP2-12904] - Human hippocampal sections using this antibody.![Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Immunohistochemistry-NBP2-12904-img0014.jpg "Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904] - Immunohistochemistry analysis using Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody, Clone N68/6 (NBP2-12904). Tissue: Brain Slice. Species: Mouse. Fixation: Frozen sections. Primary Antibody: Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody (NBP2-12904) at 1:1000. Secondary Antibody: HRP/DAB Detection System: Biotinylated Goat Anti-Mouse, Streptavidin Peroxidase, DAB Chromogen (brown). Counterstain: Mayer Hematoxylin (purple/blue) nuclear stain.![Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]](https://resources.rndsystems.com/images/products/Nav1-7-Antibody-N68-6-Immunohistochemistry-NBP2-12904-img0015.jpg "Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]")
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904]
Immunohistochemistry: Nav1.7 Antibody (N68/6) [NBP2-12904] - Immunohistochemistry analysis using Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody, Clone N68/6 (NBP2-12904). Tissue: hippocampus. Species: Human. Fixation: Bouin's Fixative and paraffin-embedded. Primary Antibody: Mouse Anti-Nav1.7 Sodium Channel Monoclonal Antibody (NBP2-12904) at 1:1000 for 1 hour at RT. Secondary Antibody: FITC Goat Anti-Mouse (green) at 1:50 for 1 hour at RT.Applications for Nav1.7 Antibody (N68/6) - BSA Free
Application
Recommended Usage
Immunocytochemistry/ Immunofluorescence
1:100
Immunohistochemistry
1:1000
Immunohistochemistry-Paraffin
1:1000
Western Blot
1:1000
Application Notes
1 ug/ml of Nav1.7 Antibody was sufficient for detection of Nav1.7 in 10 ug of HEK-293 cell lysate transiently expressing Nav1.7 by colorimetric immunoblot analysis using Goat anti-mouse IgG:HRP as the secondary Antibody.
Formulation, Preparation, and Storage
Purification
Protein G purified
Formulation
PBS (pH 7.4), 50% Glycerol
Format
BSA Free
Preservative
0.09% Sodium Azide
Concentration
1 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
Background: Nav1.7
Long Name
Sodium channel protein type 9 subunit alpha
Alternate Names
hNE-Na, Ne-Na, NENA, PN1, SCN9A
Gene Symbol
SCN9A
Additional Nav1.7 Products
Product Documents for Nav1.7 Antibody (N68/6) - BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for Nav1.7 Antibody (N68/6) - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Citations for Nav1.7 Antibody (N68/6) - BSA Free
Powered by Bioz
Customer Reviews for Nav1.7 Antibody (N68/6) - BSA Free
There are currently no reviews for this product. Be the first to review Nav1.7 Antibody (N68/6) - BSA Free and earn rewards!
Have you used Nav1.7 Antibody (N68/6) - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
