Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF

Catalog # Availability Size / Price Qty
7268-CT-100
Recombinant Human CTLA-4 Fc Chimera (CHO-expressed) Bioactivity
1 Image
Product Details
Citations (2)
FAQs
Supplemental Products
Reviews (3)

Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF Summary

Product Specifications

Purity
>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining.
Endotoxin Level
<0.01 EU per 1 μg of the protein by the LAL method.
Activity
Measured by its ability to inhibit IL-2 secretion by stimulated Jurkat human acute T cell leukemia cells. Linsley, P.S. et al. (1991) J. Exp. Med. 174:561. The ED50 for this effect is 0.03-0.15 μg/mL when stimulated with 1 μg/mL Recombinant Human B7‑1/CD80 Fc Chimera (Catalog # 140-B1).
Source
Chinese Hamster Ovary cell line, CHO-derived human CTLA-4 protein
Human CTLA-4
(Ala37-Phe162)
Accession # P16410
IEGRMD Human IgG1
(Pro100-Lys330)
N-terminus C-terminus
Accession #
N-terminal Sequence
Analysis
Ala37 & Met38
Structure / Form
Disulfide-linked homodimer
Predicted Molecular Mass
40.1 kDa (monomer)
SDS-PAGE
53-58 kDa, reducing conditions

Product Datasheets

Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.

7268-CT

Formulation Lyophilized from a 0.2 μm filtered solution in PBS.
Reconstitution Reconstitute at 100 μg/mL in PBS.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.

Data Image

Bioactivity Recombinant Human CTLA-4 Fc Chimera (CHO-expressed) Bioactivity View Larger

Recombinant Human CTLA-4 Fc Chimera (Catalog # 7268-CT) inhibits IL-2 secretion by stimulated Jurkat human acute T cell leukemia cells. The ED50 for this effect is 0.03-0.15 µg/mL when stimulated with 1 µg/mL Recombinant Human B7-1/CD80 Fc Chimera (Catalog # 140-B1).

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: CTLA-4

CTLA-4 (cytotoxic T-lymphocyte associated protein‑4, designated CD152), is a type I transmembrane T cell inhibitory molecule that is a member of the Ig superfamily (1, 2). Human or mouse CTLA-4 cDNA encodes 223 amino acids (aa) including a 35 aa signal sequence, a 126 aa extracellular domain (ECD) with one Ig-like V-type domain, a 21 aa transmembrane (TM) sequence, and a 41 aa cytoplasmic sequence. It is found as a covalent homodimer of 41-43 kDa (2) Within the ECD, human CTLA-4 shares 68%, 71% and 83‑86% aa sequence identity with mouse, rat and porcine/bovine/rabbit/feline/canine CTLA-4, respectively. A 174 aa form that lacks TM and cytoplasmic sequences (sCTLA-4) is possibly secreted (3-5). Isoforms of 56-79 aa that mainly contain parts of the cytoplasmic domain are reported. In mouse, an isoform lacking the Ig-like domain has ligand-independent inhibitory activity and is termed liCTLA-4 (6). CD28, which is structurally related to CTLA-4, is constitutively expressed on naïve T cells and promotes T cell activation when engaged by B7-2 on antigen-presenting cells (APC) within the immunological synapse (IS) (1, 7, 8). In contrast, CTLA-4 is recruited from intracellular vesicles to the IS beginning 1-2 days after T cell activation (2, 7, 8). It forms a linear lattice with B7-1 on APC, inducing negative regulatory signals and ending T cell activation (9). Abatacept, a therapeutic human CTLA-4-Ig fusion protein (trade name Orencia), competes with CD28 for B7-1 and B7-2 binding and has been used to antagonize T cell activation in autoimmune conditions and to enhance transplant survival (10). Mice deleted for CTLA-4 show no abnormalities until after birth, but then develop lethal autoimmune reactions due to continued T cell activation and poor control by regulatory T cells, which constitutively express CTLA-4 in wild-type mice and humans (11-13).

References
  1. Harper, K. et al. (1991) J. Immunol. 147:1037.
  2. Teft, W.A. et al. (2006) Annu. Rev. Immunol. 24:65.
  3. Magistrelli, G. et al. (1999) Eur. J. Immunol. 29:3596.
  4. Tector, M. et al. (2009) BMC Immunol. 10:51.
  5. Oaks, M.K. and K.M. Hallett (2000) J. Immunol. 164:5015.
  6. Vijayakrishnan, L. et al. (2004) Immunity 20:563.
  7. Pentcheva-Hoang, T. et al. (2004) Immunity 21:401.
  8. Jansson, A. et al. (2005) J. Immunol 175:1575.
  9. Darlington, P.J. et al. (2005) J. Immunol. 175:996.
  10. Platt, A.M. et al. (2010) J. Immunol. 185:1558.
  11. Wing, K. et al. (2008) Science 322:271.
  12. Friedline, R.H. et al. (2009) J. Exp. Med. 206:421.
  13. Jain, N. et al. (2010) Proc. Natl. Acad. Sci. USA 107:1524.
Long Name
Cytotoxic T-lymphocyte-associated Molecule 4
Entrez Gene IDs
1493 (Human); 12477 (Mouse); 403696 (Canine); 102115124 (Cynomolgus Monkey)
Alternate Names
CD; CD152 antigen; CD152; CD152IDDM12; CD28; celiac disease 3; CELIAC3; CTLA4; CTLA-4; cytotoxic T-lymphocyte antigen 4; cytotoxic T-lymphocyte protein 4; Cytotoxic T-lymphocyte-associated antigen 4; cytotoxic T-lymphocyte-associated protein 4; cytotoxic T-lymphocyte-associated serine esterase-4; GRD4; GSE; ICOS; ligand and transmembrane spliced cytotoxic T lymphocyte associated antigen 4

Citations for Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

2 Citations: Showing 1 - 2
Filter your results:

Filter by:

  1. ICOS agonism by JTX-2011 (vopratelimab) requires initial T cell priming and Fc cross-linking for optimal T cell activation and anti-tumor immunity in preclinical models
    Authors: A Hanson, K Elpek, E Duong, L Shallberg, M Fan, C Johnson, M Wallace, GR Mabry, S Sazinsky, L Pepper, CJ Shu, S Sathyanara, S Zuerndorfe, T Simpson, M Gostissa, M Briskin, D Law, J Michaelson, CJ Harvey
    PLoS ONE, 2020;15(9):e0239595.
    Species: Human
    Sample Types: Whole Cells
    Applications: Bioassay
  2. Structural basis for cancer immunotherapy by the first-in-class checkpoint inhibitor ipilimumab
    Authors: UA Ramagopal, W Liu, SC Garrett-Th, JB Bonanno, Q Yan, M Srinivasan, SC Wong, A Bell, S Mankikar, VS Rangan, S Deshpande, AJ Korman, SC Almo
    Proc. Natl. Acad. Sci. U.S.A., 2017;0(0):.
    Species: N/A
    Sample Types: Protein
    Applications: Bioassay

FAQs

No product specific FAQs exist for this product, however you may

View all Proteins and Enzyme FAQs

Reconstitution Buffers

Reviews for Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF

Average Rating: 4.7 (Based on 3 Reviews)

5 Star
66.67%
4 Star
33.33%
3 Star
0%
2 Star
0%
1 Star
0%

Have you used Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF?

Submit a review and receive an Amazon gift card.

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:


Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF
By Anonymous on 03/06/2019
Application: Binding assay/Protein-protein interaction

Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF
By Anonymous on 11/06/2017
Application: Binding assay/Protein-protein interaction

Recombinant Human CTLA-4 Fc Chimera (CHO-expressed), CF
By Anonymous on 10/20/2017
Application: Binding assay/Protein-protein interaction
Reason for Rating: Worked as expected. Shipping was on-time and we would order this again.
