Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF

Catalog # Availability Size / Price Qty
R&D Systems Recombinant Proteins and Enzymes
1 Image
Product Details
Supplemental Products
Reviews (2)

Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF Summary

Product Specifications

>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining.
Endotoxin Level
<0.10 EU per 1 μg of the protein by the LAL method.
Measured by its ability to inhibit neurite outgrowth of dissociated E13 chick embryonic dorsal root ganglia (DRG) neurons. When immobilized as a 3 µL droplet containing 200 ng on a nitrocellulose coated microplate, Recombinant Human MAG/Siglec‑4a Fc Chimera is able to significantly inhibit neurite outgrowth.
Human embryonic kidney cell, HEK293-derived human MAG/Siglec-4a protein
Human MAG
Accession # P20916
Accession #
N-terminal Sequence
Structure / Form
Disulfide-linked homodimer
Predicted Molecular Mass
81 kDa

Product Datasheets

You must select a language.



Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.


Formulation Lyophilized from a 0.2 μm filtered solution in PBS.
Reconstitution 500 µg/mL in PBS
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Background: MAG/Siglec-4a

Myelin-Associated Glycoprotein (MAG), also known as Siglec-4a, is a type I transmembrane glycoprotein belonging to the Siglec family, a subgroup of the Ig superfamily (1). It is composed of an extracellular segment containing five Ig-like domains, a single transmembrane segment, and a cytoplasmic domain. Mature MAG exists as two isoforms, termed S-MAG (short) and L-MAG (long), due to alternative splicing of the cytoplasmic domain (1, 2). S-MAG has a predicted molecular weight of 67 kDa while L-MAG has a predicted molecular weight of 71 kDa (1, 2). Additionally, proteolytic cleavage of the extracellular domain produces a soluble MAG (3). Within shared regions in the extracellular domain, human MAG shares 95% aa sequence identity with mouse and rat MAG. MAG functions as an adhesion molecule during neural development. It preferentially binds to alpha -2,3-linked sialic acid terminal structures found on cell surface molecules (1, 4, 5). MAG is selectively expressed by myelinating oligodendrocytes and Schwann cells and plays an important role in axon-myelin stability (1, 4). Specifically, L-MAG is involved in myelination in the central nervous system (CNS) while S-MAG is the predominate isoform expressed during myelination in the peripheral nervous system (1). MAG is also reported to regulate the axon cytoskeleton and support the distribution of axon molecules at the nodes of Ranvier (1, 4). In addition, it has been identified as a major inhibitor of neurite outgrowth (1, 4, 6). However, MAG has also been reported to protect neurons from excitotoxicity (1, 7). MAG is believed to utilize the gangliosides GD1a and GT1b, the Nogo receptors NgR1 and NgR2/NgRH1, Integrin beta 1/CD29, and PIR-B to mediate its effects (1, 4, 5, 8, 9). Soluble MAG, which is released from myelin in large quantities, has been identified in normal human tissues and in tissues from patients with neurological disorders (3). It is believed that this soluble MAG might contribute to the lack of CNS neuron regeneration after injury (3).

  1. Lopez, P.H. (2014) Adv. Neurobiol. 9:245.
  2. Salzer, J.L. et al. (1987) J. Cell Biol. 104:957.
  3. Tang, S. et al. (1997) Mol. Cell. Neurosci. 9:333.
  4. Schnaar, R.L. and P.H. Lopez (2009) J. Neurosci. Res. 87:3267.
  5. Schnaar, R.L. (2010) FEBS Lett. 584:1741.
  6. Akbik, F. et al. (2012) Exp. Neurol. 235:43.
  7. Lopez, P.H. et al. (2011) J. Neurochem. 116:900.
  8. Atwal, J.K. et al. (2008) Science 322:967.
  9. Goh, E.L. et al. (2008) Mol. Brain 1:10.
Long Name
Myelin-associated Glycoprotein
Entrez Gene IDs
4099 (Human); 17136 (Mouse); 29409 (Rat)
Alternate Names
GMAsialic acid binding Ig-like lectin 4A; MAG; myelin associated glycoprotein; myelin-associated glycoprotein; sialic acid-binding immunoglobulin-like lectin 4A; Siglec4a; Siglec-4a; S-MAG


No product specific FAQs exist for this product, however you may

View all Proteins and Enzyme FAQs

Reconstitution Buffers

Reviews for Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF

Average Rating: 3.5 (Based on 2 Reviews)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF?

Submit a review and receive an Amazon gift card.

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF
By Anonymous on 10/28/2021
Application: Binding assay/Protein-protein interaction

Recombinant Human MAG/Siglec-4a Fc Chimera Protein, CF
By Anonymous on 10/20/2021
Application: Binding assay/Protein-protein interaction
