Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF

Catalog # Availability Size / Price Qty
R&D Systems Recombinant Proteins and Enzymes
1 Image
Product Details
Citations (2)
Supplemental Products
Reviews (2)

Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF Summary

Product Specifications

>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining.
Endotoxin Level
<0.10 EU per 1 μg of the protein by the LAL method.
Measured by its binding ability in a functional ELISA. When Recombinant Human TGF-beta  RII Fc Chimera (Catalog # 341-BR) is immobilized at 1 μg/mL (100 μL/well), it binds Recombinant Human (rh) TGF-beta RI/ALK-5 Fc Chimera in the presence of rhTGF-beta 1. The concentration of rhTGF-beta RI Fc Chimera that produces 50% of the optimal binding response is approximately 0.05-0.4 μg/mL.
Mouse myeloma cell line, NS0-derived human TGF-beta RI/ALK-5 protein
Human TGF-beta RI/ALK-5
Accession # P36897
N-terminus C-terminus
Accession #
N-terminal Sequence
Ala25 & Leu34
Structure / Form
Disulfide-linked homodimer
Predicted Molecular Mass
37 kDa (monomer)
40-60 kDa, reducing conditions

Complete Your Experiment

Product Datasheets

You must select a language.



Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.


Formulation Lyophilized from a 0.2 μm filtered solution in PBS.
Reconstitution Reconstitute at 250 μg/mL in PBS.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Background: TGF-beta RI/ALK-5

TGF-beta RI, also called ALK-5, is an approximately 55 kDa type I transmembrane serine/threonine receptor kinase (1, 2). It contains a cysteine-rich extracellular domain (ECD), a transmembrane helix, and a C-terminal cytoplasmic kinase domain (3). Within the cytoplasmic domain there is also a short, conserved regulatory sequence known as the GS region that is N-terminal to the kinase domain (1). Within the ECD, human TGF-beta RI shares 90% and 88% aa sequence identity with mouse and rat TGF-beta RI, respectively. In the presence of TGF-beta, TGF-beta RI forms a complex with, and is phosphorylated by, TGF-beta RII (1). Phosphorylated TGF-beta RI can then transiently bind and phosphorylate Smad2 and Smad3 (2, 4-6). These phosphorylated Smads form heteromeric complexes with Smad4, translocate to the nucleus, and regulate target gene transcription (2, 4-6). TGF-beta RI is likely important during development, since mice deficient for TGF-beta RI die at midgestation with severe defects in vascular development of the yolk sac and placenta, and an absence of circulating red blood cells (7). Furthermore, TGF-beta RI appears to be involved in proper lymphatic network development (8). Mutations in TGF-beta RI have been identified in pancreatic, colorectal, ovarian, and head and neck cancers (9).

  1. Wrana, J.L. et al. (1994) Nature 370:341.
  2. Massagué, J. (2012) Nat. Rev. Mol. Cell Biol. 13:616.
  3. Huse, M. et al. (1999) Cell 96:425.
  4. Marcías-Silva, M. et al. (1996) Cell 87:1215.
  5. Zhang, Y. et al. (1996) Nature 383:168.
  6. Huse, M. et al. (2001) Mol. Cell 8:671.
  7. Larsson, J. et al. (2001) EMBO J. 20:1663.
  8. James, J.M. et al. (2013) Development 140:3903.
  9. Sheen, Y.Y. et al. (2013) Biomol. Ther. (Seoul) 21:323.
Long Name
Transforming Growth Factor beta Receptor I
Entrez Gene IDs
7046 (Human); 21812 (Mouse); 29591 (Rat)
Alternate Names
AAT5; activin A receptor type II-like kinase, 53kD; activin A receptor type II-like kinase, 53kDa; Activin receptor-like kinase 5; ACVRLK4; ALK-5; ALK-5ALK5; EC 2.7.11; EC; LDS1A; LDS2A; Serine/threonine-protein kinase receptor R4; SKR4; tbetaR-I; TGFB1R1; TGF-beta receptor type I; TGF-beta receptor type-1; TGF-beta RI; TGF-beta type I receptor; TGFbetaRI; TGFBR1; TGF-bRI; TGFR-1; transforming growth factor beta receptor I; transforming growth factor, beta receptor 1; transforming growth factor, beta receptor I (activin A receptor type II-likekinase, 53kD); Transforming growth factor-beta receptor type I

Citations for Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

2 Citations: Showing 1 - 2
Filter your results:

Filter by:

  1. Structural basis for potency differences between GDF8 and GDF11
    Authors: RG Walker, M Czepnik, EJ Goebel, JC McCoy, A Vujic, M Cho, J Oh, S Aykul, KL Walton, G Schang, DJ Bernard, AP Hinck, CA Harrison, E Martinez-H, AJ Wagers, RT Lee, TB Thompson
    BMC Biol, 2017;15(1):19.
    Species: Bacteria - Staphylococcus aureus
    Sample Types: Recombinant Protein
    Applications: Bioassay
  2. TGF-? contamination of purified recombinant GDF15
    Authors: OE Olsen, A Skjærvik, BF Størdal, A Sundan, T Holien
    PLoS ONE, 2017;12(11):e0187349.
    Species: Human
    Sample Types: Whole Cells
    Applications: Bioassay


No product specific FAQs exist for this product, however you may

View all Proteins and Enzyme FAQs

Reconstitution Buffers

Reviews for Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF

Average Rating: 4.5 (Based on 2 Reviews)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF?

Submit a review and receive an Amazon gift card.

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF
By Anonymous on 12/21/2020
Application: Binding assay/Protein-protein interaction
Reason for Rating: ELISA assay. TGFb3 binds to immobilize TBRII, followed by different doses of TBRI. Recruitment of TBRI was seen when TGFbeta and TBRII are complexed.

Recombinant Human TGF-beta RI/ALK-5 Fc Chimera Protein, CF
By Jenna Nguyen on 07/09/2019
Application: Enzymatic activity in vitro
