Recombinant SARS-CoV-2 NSP16/NSP10-His Complex, CF

Catalog # Availability Size / Price Qty
10634-CV-100
Recombinant SARS-CoV-2 NSP16/NSP10-His Complex SDS-PAGE.
1 Image
Product Details
FAQs
Reviews

Recombinant SARS-CoV-2 NSP16/NSP10-His Complex, CF Summary

Product Specifications

Purity
>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining.
Endotoxin Level
<1.0 EU per 1 μg of the protein by the LAL method.
Source
E. coli-derived sars-cov-2 NSP16/NSP10 protein
SARS-CoV-2 NSP16
(Ser1-Asn298)
Accession # YP_009725311.1
SARS-CoV-2 NSP10
(Ala1-Gln139)
Accession # YP_009725306.1
6-His tag
N-terminusC-terminus
N-terminal Sequence
Analysis
Ser1 (NSP16) & Ala1 (NSP10)
Predicted Molecular Mass
33 kDa (NSP16) & 16 kDa (NSP10)
SDS-PAGE
34 kDa (NSP16) & 17 kDa (NSP10), under reducing conditions

Product Datasheets

Carrier Free

What does CF mean?

CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.

What formulation is right for me?

In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.

10634-CV

Formulation Supplied as a 0.2 μm filtered solution in Tris, NaCl, TCEP and Glycerol.
Shipping The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 6 months from date of receipt, -20 to -70 °C as supplied.
  • 3 months, -20 to -70 °C under sterile conditions after opening.

Data Image

SDS-PAGE Recombinant SARS-CoV-2 NSP16/NSP10-His Complex SDS-PAGE. View Larger

2 μg/lane of Recombinant SARS-CoV-2 NSP16/NSP10-His Complex (Catalog # 10634-CV) was resolved with SDS-PAGE under reducing (R) and non-reducing (NR) conditions and visualized by Coomassie® Blue staining, showing bands at 34 kDa and 17 kDa under reducing conditions.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: NSP16/NSP10

Non-structural protein 16 (NSP16) and NSP10 are two of several functional proteins released by ORF1a-encoded protease cleavage of the pp1a and pp1ab replicase polyproteins expressed from the coronavirus (CoV) genome (1). The NSPs are involved in the replication and transcription of the viral RNA and not incorporated within the virion particles. Coronaviruses include various highly pathogenic strains such as SARS-CoV, MERS-CoV and SARS-CoV2 that have had significant impact on humans as well as strains that have negatively impacted livestock. NSP16 is a small monomeric 298 amino acid protein with a characteristic fold of the class I methyltransferase (MTase) family with a seven-stranded B-sheet surrounded by alpha-helices and loops that bind the cap and form a cap-binding groove and S-adenosylmethionine (SAM) cleft (2,3). NSP10 is a small 139 amino acid protein capable of forming independent dodecameric structures composed of four identical trimers where each monomer is capable of binding two zinc ions (4,5). Both the NSP16 and NSP10 SARS-CoV2 sequences are highly conserved across coronaviruses (3). NSP16 catalyzes 2'-O-MTase activity specifically on capped N7-methylated RNA through methylation of the 2'-hydroxy group of adenine using SAM as a methyl donor (6). The viral RNA cap structure protects it from degradation, promotes mRNA translation, and prevents the viral RNA from being recognized by innate immune mechanisms (7). NSP16 was shown to interact strongly with NSP10 (8) in a monomeric form via hydrophic interactions and hydrogen bonds in the interface (3). The MTase activity of NSP16 requires interaction with NSP10 (2,7). NSP10 interaction extends and narrows the RNA-binding groove that accommodates the substrate and stabilizes NSP16 (2,3,9). The dimerization interface between NSP16 and NSP10 is critical and can be used as a target to effectively reduce replication and pathogenesis (10,11).

References
  1. Snijder, E.J. et al. (2016) Adv. Virus Res 96:59.
  2. Chen, Y. et al. (2011) PLoS Pathog. 7:e1002294.
  3. Rosas-Lemus, M. et al. (2020) bioRxiv In press.
  4. Matthes, N. et al. (2006) FEBS Lett. 580:4143.
  5. Su, D. et al. (2006) J. Virol. 80:7902.
  6. Bouvet, M. et al. (2012) Proc. Natl. Acad. Sci. U.S.A. 109:9372.
  7. Decroly, E. et al. (2011) PLoS Pathog. 7:e1002059.
  8. Pan, J. et al. (2008) PLoS One 3:e3299.
  9. Bouvet, M. et al. (2014) J. Biol. Chem. 289:25783.
  10. Ma, Y. et al. (2015) Proc. Natl. Acad. Sci. 112:9436.
  11. Wang, Y. et al. (2015) J. Virol 89:8416.
Long Name
NSP16/NSP10
Alternate Names
NSP16/NSP10
