The SH2 domain-containing phosphatases, SHP-1 and SHP-2, are well-studied cytosolic tyrosine phosphatases that share many structural and regulatory features. They both have two tandem SH2 domains at the N-terminus, followed by a catalytic domain, and an inhibitory C-terminus. Despite their structural similarity, the enzymes appear to have different physiological roles and exhibit different expression patterns. SHP-1 is highly expressed in hematopoietic tissues, and in general has a negative impact on lymphocyte signaling. In contrast, SHP-2 is widely expressed, and in general promotes signaling pathways that lead to differentiation, cell growth, or migration.
SHP-1 Antibody (7I1K3)
Novus Biologicals | Catalog # NBP3-15669
Recombinant Monoclonal Antibody
Loading...
Key Product Details
Species Reactivity
Human, Mouse, Rat
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Recombinant Monoclonal Rabbit IgG Clone # 7I1K3 expressed in HEK293
Loading...
Product Specifications
Immunogen
A synthetic peptide corresponding to a sequence within amino acids 496-595 of human SHP-1 (P29350). SGMVQTEAQYKFIYVAIAQFIETTKKKLEVLQSQKGQESEYGNITYPPAMKNAHAKASRTSSKHKEDVYENLHTKNKREEKVKKQRSADKEKSKGSLKRK
Clonality
Monoclonal
Host
Rabbit
Isotype
IgG
Scientific Data Images for SHP-1 Antibody (7I1K3)
Western Blot: SHP-1 Antibody (7I1K3) [NBP3-15669]
Western Blot: SHP-1 Antibody (7I1K3) [NBP3-15669] - Western blot analysis of extracts of Raji cells, using SHP-1 antibody (NBP3-15669) at 1:1000 dilution. Secondary antibody: HRP Goat Anti-Rabbit IgG (H+L) at 1:10000 dilution. Lysates/proteins: 25ug per lane. Blocking buffer: 3% nonfat dry milk in TBST. Detection: ECL Basic Kit. Exposure time: 10s.Western Blot: SHP-1 Antibody (7I1K3) [NBP3-15669]
Western Blot: SHP-1 Antibody (7I1K3) [NBP3-15669] - Western blot analysis of extracts of various cell lines, using SHP-1 antibody (NBP3-15669) at 1:1000 dilution. Secondary antibody: HRP Goat Anti-Rabbit IgG (H+L) at 1:10000 dilution. Lysates/proteins: 25ug per lane. Blocking buffer: 3% nonfat dry milk in TBST. Detection: ECL Basic Kit. Exposure time: 3min.Immunohistochemistry: SHP-1 Antibody (7I1K3) [NBP3-15669]
Immunohistochemistry: SHP-1 Antibody (7I1K3) [NBP3-15669] - Immunofluorescence analysis of rat spleen using SHP-1 Rabbit mAb (NBP3-15669) at dilution of 1:100 (40x lens). Blue: DAPI for nuclear staining.Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] -
Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] - Immunohistochemistry analysis of paraffin-embedded Human tonsil tissue using SHP-1 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] -
Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] - Immunohistochemistry analysis of paraffin-embedded Human spleen tissue using SHP-1 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] -
Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] - Immunohistochemistry analysis of paraffin-embedded Rat spleen tissue using SHP-1 Rabbit mAb at a dilution of 1:800 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.Immunocytochemistry/ Immunofluorescence: SHP-1 Antibody (7I1K3) [SHP-1] -
Immunocytochemistry/ Immunofluorescence: SHP-1 Antibody (7I1K3) [SHP-1] - Immunofluorescence analysis of paraffin-embedded mouse spleen using SHP-1 Rabbit mAb at dilution of 1:100 (40x lens). Secondary antibody: Cy3-conjugated Goat anti-Rabbit IgG (H+L) at 1:500 dilution. Blue: DAPI for nuclear staining.Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] -
Immunohistochemistry: SHP-1 Antibody (7I1K3) [SHP-1] - Immunohistochemistry analysis of paraffin-embedded Mouse spleen tissue using SHP-1 Rabbit mAb at a dilution of 1:800 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.Applications for SHP-1 Antibody (7I1K3)
Application
Recommended Usage
Immunocytochemistry/ Immunofluorescence
1:50 - 1:200
Immunohistochemistry
1:50 - 1:200
Western Blot
1:500 - 1:2000
Formulation, Preparation, and Storage
Purification
Affinity purified
Formulation
PBS (pH 7.3), 50% glycerol, 0.05% BSA
Preservative
0.02% Sodium Azide
Concentration
Please see the vial label for concentration. If unlisted please contact technical services.
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Background: SHP-1
Long Name
Src Homology Region 2 Domain Phosphatase 1
Alternate Names
HCPH, PTP1C, PTPN6, SHP1
Gene Symbol
PTPN6
