ATF4 Antibody (SD20-92)

Novus Biologicals | Catalog # NBP2-67766

Recombinant Monoclonal Antibody
Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Biological Validation

Species Reactivity

Validated:

Human, Mouse, Rat

Cited:

Mouse

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation

Cited:

Immunohistochemistry-Frozen, IF/IHC

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # SD20-92 expressed in HEK293
View all ATF4 Primary Antibodies »

Product Specifications

Immunogen

Recombinant protein within Human ATF4 aa 1-220 / 351. (SwissProt: P18848 Human; SwissProt: Q06507 Mouse; SwissProt: Q9ES19 Rat)

Localization

Nucleus, Nucleus speckle, Cell membrane, Cytoplasm, Centrosome.

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for ATF4 Antibody (SD20-92)

Western Blot: ATF4 Antibody (SD20-92) [NBP2-67766]

Western Blot: ATF4 Antibody (SD20-92) [NBP2-67766]

Western Blot: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of ATF4 on different lysates. Proteins were transferred to a PVDF membrane and blocked with 5% BSA in PBS for 1 hour at room temperature. The primary antibody (1:500) was used in 5% BSA at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody at 1:5,000 dilution was used for 1 hour at room temperature. Positive control: Lane 1: HeLa cell lysateLane 2: PC-12 cell lysate Lane 3: HL-60 cell lysate Lane 4: K562 cell lysateLane 5: human lung carcinoma tissue lysate.
Immunocytochemistry/ Immunofluorescence: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunocytochemistry/ Immunofluorescence: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunocytochemistry/Immunofluorescence: ATF4 Antibody (SD20-92) [NBP2-67766] - Staining ATF4 in N2A cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X-100/PBS.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded mouse colon tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Flow Cytometry: ATF4 Antibody (SD20-92) [NBP2-67766]

Flow Cytometry: ATF4 Antibody (SD20-92) [NBP2-67766]

Flow Cytometry: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of Hela cells with ATF4 antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti rabbit IgG was used as the secondary antibody.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human liver carcinoma tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human prostate carcinoma tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human skin tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human breast carcinoma tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human stomach carcinoma tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human colon carcinoma tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1:50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human thyroid tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766]

Immunohistochemistry-Paraffin: ATF4 Antibody (SD20-92) [NBP2-67766] - Analysis of paraffin-embedded human small intestine tissue using anti-ATF4 antibody. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Applications for ATF4 Antibody (SD20-92)

Application
Recommended Usage

Flow Cytometry

1:50-1:100

Immunocytochemistry/ Immunofluorescence

1:50-1:200

Immunohistochemistry-Paraffin

1:50-1:200

Western Blot

1:500-1:2000

Reviewed Applications

Read 1 review rated 1 using NBP2-67766 in the following applications:

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

TBS (pH7.4), 0.05% BSA, 40% Glycerol

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: ATF4

ATF4 encodes a transcription factor that was originally identified as a widely expressed mammalian DNA binding protein that could bind a tax-responsive enhancer element in the LTR of HTLV-1. The encoded protein was also isolated and characterized as the cAMP-response element binding protein 2 (CREB-2). The protein encoded by this gene belongs to a family of DNA-binding proteins that includes the AP-1 family of transcription factors, cAMP-response element binding proteins (CREBs) and CREB-like proteins. These transcription factors share a leucine zipper region that is involved in protein-protein interactions, located C-terminal to a stretch of basic amino acids that functions as a DNA binding domain. Two alternative transcripts encoding the same protein have been described. Two pseudogenes are located on the X chromsome at q28 in a region containing a large inverted duplication.

Long Name

Activating Transcription Factor 4

Alternate Names

TAXREB67, TXREB

Gene Symbol

ATF4

Additional ATF4 Products

Product Documents for ATF4 Antibody (SD20-92)

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for ATF4 Antibody (SD20-92)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for ATF4 Antibody (SD20-92)

Customer Reviews for ATF4 Antibody (SD20-92) (1)

1 out of 5
1 Customer Rating
5 Stars
0%
4 Stars
0%
3 Stars
0%
2 Stars
0%
1 Stars
100%

Have you used ATF4 Antibody (SD20-92)?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Customer Images

Showing  1 - 1 of 1 review Showing All
Filter By:
Clear Filters X
  • ATF4 Antibody (SD20-92)
    Name: Anonymous
    Application: Immunocytochemistry
    Sample Tested: mouse brain sections and Brain sections of mice 40 µm
    Species: Mouse
    Verified Customer | Posted 05/17/2021
    Magnification x20, confocal laser scanning microscopy. Tyrosine hydroxylase chicken in red and ATF4 in green No specific signal for ATF4 at 1/50eme
    Mice have been deeply anesthetized and perfused with cold PBS and then PFA. Brains have been dissected and fixed in PFA 4% overnight at 4°C. Coronal sections of substantia nigra of 40 µm thickness have been cut using a cryostat. For immunostaining, free-floating sections have been incubated in TBS with bovine serum albumin, triton, goat serum during 1h. Then primary antibodies during 2h and we have used secondary antibodies Goat anti rabbit for ATF4 in 488 1h time incubation. We have test different dilutions of ATF4 : 1/50,1/100,1/200,1/400,1/600.
    ATF4 Antibody (SD20-92) NBP2-67766
    Bio-Techne Response
    Thank you for reviewing our product. We are sorry to that that this antibody did not perform as expected. We have been in touch with the customer to resolve this issue according to our Product Guarantee and to the customer’s satisfaction.

There are no reviews that match your criteria.

Showing  1 - 1 of 1 review Showing All

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs

No product specific FAQs exist for this product.

View all FAQs for Antibodies

Associated Pathways

TGF-beta Signaling Pathways TGF-beta Signaling Pathway Thumbnail
