ATP5F1 Antibody - BSA Free

Novus Biologicals | Catalog # NBP2-49255

Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Orthogonal Validation, Independent Antibodies

Species Reactivity

Validated:

Human

Predicted:

Mouse (90%). Backed by our 100% Guarantee.

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Polyclonal Rabbit IgG

Format

BSA Free
View all ATP5F1 Primary Antibodies »

Product Specifications

Immunogen

This antibody was developed against a recombinant protein corresponding to amino acids: LDYHISVQNMMRRKEQEHMINWVEKHVVQSISTQQEKETIAKCIADLKLLAKKAQAQPVM

Reactivity Notes

Rat (88%)

Clonality

Polyclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for ATP5F1 Antibody - BSA Free

Western Blot: ATP5F1 Antibody [NBP2-49255]

Western Blot: ATP5F1 Antibody [NBP2-49255]

Western Blot: ATP5F1 Antibody [NBP2-49255] - Analysis using Anti-ATP5F1 antibody NBP2-49255 (A) shows similar pattern to independent antibody NBP1-91689 (B).
Immunocytochemistry/ Immunofluorescence: ATP5F1 Antibody [NBP2-49255]

Immunocytochemistry/ Immunofluorescence: ATP5F1 Antibody [NBP2-49255]

Immunocytochemistry/Immunofluorescence: ATP5F1 Antibody [NBP2-49255] - Staining of human cell line U-2 OS shows localization to mitochondria. Antibody staining is shown in green.
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining of human heart muscle.
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining of human kidney shows high expression.
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining of human pancreas shows low expression as expected.
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining in human kidney and pancreas tissues using anti-ATP5F1 antibody. Corresponding ATP5F1 RNA-seq data are presented for the same tissues.
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining of human cerebral cortex, heart muscle, kidney and pancreas using Anti-ATP5F1 antibody NBP2-49255 (A) shows similar protein distribution across tissues to independent antibody NBP1-91689 (B).
Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255]

Immunohistochemistry-Paraffin: ATP5F1 Antibody [NBP2-49255] - Staining of human cerebral cortex.

Applications for ATP5F1 Antibody - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

0.25-2 ug/ml

Immunohistochemistry

1:500 - 1:1000

Immunohistochemistry-Paraffin

1:500 - 1:1000

Western Blot

0.04-0.4 ug/ml
Application Notes
For IHC-Paraffin, HIER pH 6 retrieval is recommended. ICC/IF Fixation Permeabilization: Use PFA/Triton X-100.

Formulation, Preparation, and Storage

Purification

Affinity purified

Formulation

PBS (pH 7.2) and 40% Glycerol

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

Concentrations vary lot to lot. See vial label for concentration. If unlisted please contact technical services.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: ATP5F1

ATP5F1 encodes a subunit of mitochondrial ATP synthase. Mitochondrial ATP synthase catalyzes ATP synthesis, utilizing an electrochemical gradient of protons across the inner membrane during oxidative phosphorylation. ATP synthase is composed of two linked multi-subunit complexes: the soluble catalytic core, F1, and the membrane-spanning component, Fo, comprising the proton channel. The catalytic portion of mitochondrial ATP synthase consists of 5 different subunits (alpha, beta, gamma, delta, and epsilon) assembled with a stoichiometry of 3 alpha, 3 beta, and a single representative of the other 3. The proton channel seems to have nine subunits (a, b, c, d, e, f, g, F6 and 8). This gene encodes the b subunit of the proton channel. [provided by RefSeq]

Alternate Names

ATP synthase B chain, mitochondrial, ATP synthase subunit b, mitochondrial, ATP synthase, H+ transporting, mitochondrial F0 complex, subunit b, ATP synthase, H+ transporting, mitochondrial F0 complex, subunit b, isoform 1, ATP synthase, H+ transporting, mitochondrial F0 complex, subunit B1, ATP synthase, H+ transporting, mitochondrial Fo complex, subunit B1, ATPase subunit b, cell proliferation-inducing protein 47, H+-ATP synthase subunit b, MGC24431, PIG47

Gene Symbol

ATP5PB
