Key Product Details
Species Reactivity
Human, Mouse, Rat, Canine, Monkey, Primate
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG2A Clone # OTI8E9
Loading...
Product Specifications
Immunogen
Full length human recombinant protein of human BIN3 (NP_061158) produced in HEK293T cell.
Reactivity Notes
Please note that this antibody is reactive to Mouse and derived from the same host, Mouse. Mouse-On-Mouse blocking reagent may be needed for IHC and ICC experiments to reduce high background signal. You can find these reagents under catalog numbers PK-2200-NB and MP-2400-NB. Please contact Technical Support if you have any questions.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG2A
Theoretical MW
29.5 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for BIN3 Antibody (OTI8E9)
Western Blot: BIN3 Antibody (8E9) [NBP2-03389] Analysis of extracts (35ug) from 9 different cell lines by using anti-BIN3 monoclonal antibody.
![Immunocytochemistry/ Immunofluorescence: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Immunocytochemistry-Immunofluorescence-NBP2-03389-img0007.jpg "Immunocytochemistry/ Immunofluorescence: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Immunocytochemistry/ Immunofluorescence: BIN3 Antibody (OTI8E9) [NBP2-03389]
Immunocytochemistry/Immunofluorescence: BIN3 Antibody (8E9) [NBP2-03389] - Staining of COS7 cells transiently transfected by pCMV6-ENTRY BIN3.![Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Immunohistochemistry-Paraffin-NBP2-03389-img0006.jpg "Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]
Immunohistochemistry-Paraffin: BIN3 Antibody (8E9) [NBP2-03389] - Staining of paraffin-embedded Human thyroid tissue using anti-BIN3 mouse monoclonal antibody.![Flow Cytometry: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Flow-Cytometry-NBP2-03389-img0001.jpg "Flow Cytometry: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Flow Cytometry: BIN3 Antibody (OTI8E9) [NBP2-03389]
Flow Cytometry: BIN3 Antibody (8E9) [NBP2-03389] - HEK293T cells transfected with either overexpression plasmid (Red) or empty vector control plasmid (Blue) were immunostained by anti-BIN3 antibody, and then analyzed by flow cytometry.![Western Blot: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Western-Blot-NBP2-03389-img0002.jpg "Western Blot: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Western Blot: BIN3 Antibody (OTI8E9) [NBP2-03389]
Western Blot: BIN3 Antibody (8E9) [NBP2-03389] - HEK293T cells were transfected with the pCMV6-ENTRY control (Left lane) or pCMV6-ENTRY BIN3 (Right lane) cDNA for 48 hrs and lysed. Equivalent amounts of cell lysates (5 ug per lane) were separated by SDS-PAGE and immunoblotted with anti-BIN3.![Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Immunohistochemistry-Paraffin-NBP2-03389-img0003.jpg "Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]
Immunohistochemistry-Paraffin: BIN3 Antibody (8E9) [NBP2-03389] - Staining of paraffin-embedded Carcinoma of Human bladder tissue using anti-BIN3 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Immunohistochemistry-Paraffin-NBP2-03389-img0004.jpg "Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]
Immunohistochemistry-Paraffin: BIN3 Antibody (8E9) [NBP2-03389] - Staining of paraffin-embedded Carcinoma of Human kidney tissue using anti-BIN3 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]](https://resources.rndsystems.com/images/products/BIN3-Antibody-8E9-Immunohistochemistry-Paraffin-NBP2-03389-img0005.jpg "Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]")
Immunohistochemistry-Paraffin: BIN3 Antibody (OTI8E9) [NBP2-03389]
Immunohistochemistry-Paraffin: BIN3 Antibody (8E9) [NBP2-03389] - Staining of paraffin-embedded Human prostate tissue using anti-BIN3 mouse monoclonal antibody.Applications for BIN3 Antibody (OTI8E9)
Application
Recommended Usage
Flow Cytometry
1:100
Immunocytochemistry/ Immunofluorescence
1:100
Immunohistochemistry
1:150
Immunohistochemistry-Paraffin
1:150
Western Blot
1:500-2000
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Formulation
PBS (pH 7.3), 1.0% BSA and 50% Glycerol
Preservative
0.02% Sodium Azide
Concentration
0.69 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Background: BIN3
Additional BIN3 Products
Product Documents for BIN3 Antibody (OTI8E9)
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for BIN3 Antibody (OTI8E9)
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
