CD45 Antibody (OX-1) - BSA Free

Novus Biologicals | Catalog # NB100-64895

Novus Biologicals

Key Product Details

Species Reactivity

Validated:

Rat

Cited:

Human, Rat, Nematode - Caenorhabditis elegans

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Frozen, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, CyTOF-ready

Cited:

Immunohistochemistry-Paraffin, Immunohistochemistry-Frozen, Western Blot, Flow Cytometry, IF/IHC

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG1 Clone # OX-1

Format

BSA Free
View all CD45 Primary Antibodies »

Product Specifications

Immunogen

This CD45 Antibody (OX-1) was prepared from A 100kD thymocyte glycoprotein fraction enriched for the rat leukocyte common antigen (L-CA).

Localization

Type I membrane protein.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1

Theoretical MW

143 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Description

Novus Biologicals Mouse CD45 Antibody (OX-1) - BSA Free (NB100-64895) is a monoclonal antibody validated for use in IHC, WB, Flow and ICC/IF. Anti-CD45 Antibody: Cited in 22 publications. All Novus Biologicals antibodies are covered by our 100% guarantee.

Scientific Data Images for CD45 Antibody (OX-1) - BSA Free

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) [NB100-64895] - Analysis using Alexa Fluor (R) 488 conjugate of CD45 antibody (OX-1). Rat Splenocytes were stained with CD45 antibody (OX-1) [NB100-64895] (blue) and a matched isotype control [NBP2-27287] (orange). Cells were incubated in an antibody dilution of 1 ug/mL for 20 minutes at room temperature. Both antibodies were conjugated to Alexa Fluor 488.
Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) [NB100-64895] - Analysis using the FITC conjugate of CD45 antibody (OX-1). Staining of rat spleen cells.
Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) - BSA Free [NB100-64895]

Flow Cytometry: CD45 Antibody (OX-1) [NB100-64895] - Staining of rat peripheral blood lymphocytes with mouse anti-rat CD45 antibody (OX-1) [NB100-64895].

Applications for CD45 Antibody (OX-1) - BSA Free

Application
Recommended Usage

Flow Cytometry

1:100

Immunocytochemistry/ Immunofluorescence

1:10-1:500

Immunohistochemistry

1:10-1:500

Immunohistochemistry-Frozen

1:10-1:500
Application Notes
The antibody is directed against L-CA (leukocyte common antigen), the rat equivalent of CD45 which has a molecular weight 180-240kDa, and is present on all rat leukocytes, but not erythroid cells or cells of other tissues. This antibody is CyTOF ready.

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: CD45

CD45, also known as leukocyte common antigen (LCA), T200, or Ly5, is a member C of the class 1 receptor-like protein tyrosine phosphatase (PTPRC) family (1, 2). It is a transmembrane glycoprotein which, due to alternative splicing, has a multiple isoforms with a theoretical molecular weight ranging from 180 - 220 kDa (1, 3-5). Human CD45 is synthesized as a 1281 amino acid sequence consisting of an alternatively spliced extracellular receptor-like region, a cysteine-rich domain, fibronectin-like III repeats, a transmembrane segment, and a cytoplasmic region with tandem protein tyrosine phosphatase (PTP) domains: the membrane proximal domain (D1) and the membrane distal domain (D2) (3, 5). CD45 is expressed on all nucleated hematopoietic cells and their precursors, except mature red blood cells, and is one of the most abundantly-expressed cell-surface glycoproteins, comprising approximately 10% of surface proteins in lymphocytes (3). Functionally, CD45 is essential for development and activation of T-cells and B-cells (1-5). More specifically, CD45 positively regulates antigen receptor signaling and Src-family member kinase activity (1, 3). There are many ways to regulate CD45 phosphatase activity including ligand binding, dimerization, protein interactions, cellular localization, and covalent modifications (3, 6). Ligands for CD45 include pUL11, a transmembrane protein of the cytomegalovirus RL11 (CMV RL11) family, and placental protein 14 (PP14), both of which exclusively bind CD45, and various lectins including CD22, galectin-1, galectin-3, macrophage mannose receptor (MR), and macrophage galactose-type lectin (MGL) (6).

Given its role in immune cell development and activation, CD45 has also been linked to a variety of diseases. The importance of CD45 in immunity has been revealed in human and mouse studies where CD45-deficiency leads to a severe-combined immunodeficiency (SCID) phenotype (2, 3, 6). A CD45-knockout mice study revealed inhibited thymocyte production and poor B-cell response, whereas CD45 activation in mice causes lymphoproliferation and autoantibody production (3). CD45 variants have been associated with altered immune function and autoimmune disorders including multiple sclerosis, systemic lupus erythematosus (SLE), and rheumatoid arthritis (6). Furthermore, altered CD45 expression has been implicated in oncological conditions including chronic lymphatic leukemia, acute lymphatic leukemia, Hodgkin lymphoma, multiple myeloma, and diffuse large B-cell lymphoma (6). Considering its role in autoimmune disorders, immunodeficiency and cancer, CD45 is an ideal therapeutic target (3, 6). The main approaches to control CD45 function is through either selective inhibitors or anti-CD45 antibodies (3).

Alternative names for CD45 includes B220, CD antigen: CD45, CD45 antigen, CD45R, EC 3.1.3.48, GP180, LCA, Leukocyte common antigen, LY5, protein tyrosine phosphatase receptor type c polypeptide, PTPRC, receptor-type tyrosine-protein phosphatase C, T200 Glycoprotein, and T200.

References

1. Trowbridge, I. S., & Thomas, M. L. (1994). CD45: an emerging role as a protein tyrosine phosphatase required for lymphocyte activation and development. Annual review of immunology. https://doi.org/10.1146/annurev.iy.12.040194.000505

2. Andersen, J. N., Jansen, P. G., Echwald, S. M., Mortensen, O. H., Fukada, T., Del Vecchio, R., Tonks, N. K., & Moller, N. P. (2004). A genomic perspective on protein tyrosine phosphatases: gene structure, pseudogenes, and genetic disease linkage. FASEB journal : official publication of the Federation of American Societies for Experimental Biology.

3. Hermiston, M. L., Xu, Z., & Weiss, A. (2003). CD45: a critical regulator of signaling thresholds in immune cells. Annual review of immunology. https://doi.org/10.1146/annurev.immunol.21.120601.140946

4. Tonks, N. K., Diltz, C. D., & Fischer, E. H. (1990). CD45, an integral membrane protein tyrosine phosphatase. Characterization of enzyme activity. The Journal of biological chemistry.

5. Nam, H. J., Poy, F., Saito, H., & Frederick, C. A. (2005). Structural basis for the function and regulation of the receptor protein tyrosine phosphatase CD45. The Journal of experimental medicine. https://doi.org/10.1084/jem.20041890

6. Rheinlander, A., Schraven, B., & Bommhardt, U. (2018). CD45 in human physiology and clinical medicine. Immunology letters. https://doi.org/10.1016/j.imlet.2018.01.009

Long Name

Cluster of Differentiation 45

Alternate Names

CD45, LCA, PTPRC, T200 Glycoprotein

Entrez Gene IDs

24699 (Rat)

Gene Symbol

PTPRC

UniProt

P04157 (Rat)

Additional CD45 Products

Product Documents for CD45 Antibody (OX-1) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for CD45 Antibody (OX-1) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for CD45 Antibody (OX-1) - BSA Free

Customer Reviews for CD45 Antibody (OX-1) - BSA Free

There are currently no reviews for this product. Be the first to review CD45 Antibody (OX-1) - BSA Free and earn rewards!

Have you used CD45 Antibody (OX-1) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs for CD45 Antibody (OX-1) - BSA Free

Showing  1 - 5 of 5 FAQs Showing All

    • Q: For use in Western Blot with CD45 antibodies, what molecular weight of the band should I expect to see?
      A: The theoretical molecular weight for most of our CD45 antibodies is 147 kDa based off the first isoform. Any variation on 147 is due to the immunogen being from a different species and the protein being a slightly different size. CD45 is a family of single chain transmembraneous glycoproteins consisting of at least four isoforms (220, 205, 190, 180 kDa) which share a common large intracellular domain. Their extracellular domains are heavily glycosylated.

    • Q: I have a question about 2 of your products namely, NB100-65361 and NB100-64895, both antibodies against CD45 in rat. We would like to identify CD45 cells in paraffin fixated tissue slides, however in both datasheets of both antibodies it states that the antibodies can be used for immunohistochemistry and immunohistochemistry-Frozen. What exactly do you mean with the first immunohistochemistry? Do these antibodies also work on paraffin sections? If so, what exactly is the difference between the 2 antibodies and which one would you suggest for our purpose?
      A: I am sorry for the confusion on our datasheet with the listing of IHC and IHC-Fr. These two products have only been validated in frozen tissue samples. We list IHC as well to enable easy searching on our website of antibodies that have been testing in this type of experiment. As neither of these products have been tested in paraffin-embedded tissue samples, you would qualify for our Innovator's Reward program. In exchange for a review using one of these products in your experiment, we would issue you a credit for the purchase price of the antibody. The main difference between the two antibodies is that they are made to different monoclonal clones. NB100-65361 is sold as 1.0ml of unpurified mouse tissue culture supernatant. NB100-64895 is 0.25mg of protein G purified mouse monoclonal antibody.

    • Q: If this product is used in an application or species as a part of a customer review, will that validate this product in the application/species?
      A: If any of our primary antibodes are used in an untested application or species and it is shown to work through images from customer reviews or through publications, this validates the application/species for this product, allowing the tested application/species to fall under our 100% guarantee. Please check out our Innovator's Reward Program if you decide to test a primary antibody with a species or application that is not currently listed. Please note that the Innovator's Reward Program only applies to our primary antibodies.

    • A: Yes, here are the approved research areas we have listed for our CD45 products: Adaptive Immunity, Cell Biology, Cellular Markers, Cytokine Research, Glia Markers, Hematopoietic Stem Cell Markers, Immunology, Innate Immunity, Mast Cell Markers, Mesenchymal Stem Cell Markers, Microglia Markers, Myeloid Cell Markers, Myeloid-derived Suppressor, Neurodegeneration, Neuroscience, Signal Transduction, Stem Cell Markers, Growth and Development.

    • Q: We would like to order a CD45 antibody to stain immune cells that were isolated from a ligated sciatic nerve of mice with double immunofluorescence (using PFA-fixed tissue on slides). Which of the following rat monoclonal CD45 antibodies would you recommend: 30-F11, IBL-3/16 or 5C16?
      A: I would recommend clone 30-F11. As clone IBL-3/16 has not yet been validated for IHC-P application, we would not be able to guarantee its workability on PFA-fixed tissue. Although both other clones i.e. 30-F11 and 5C16, would be good for your samples, CD45 30-F11 # NB100-77417 is a well known clone that offers more flexibility around protocol because of availability of its conjugated forms. It would be advantageous to use a conjugated primary as you are planning for double-immunostaining procedure.
