Key Product Details
Species Reactivity
Human, Mouse, Rat
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG1 Clone # OTI3H3
Loading...
Product Specifications
Immunogen
Human recombinant protein fragment corresponding to amino acids 1-110 of human CHCHD5(NP_115685) produced in E.coli.
Reactivity Notes
Please note that this antibody is reactive to Mouse and derived from the same host, Mouse. Mouse-On-Mouse blocking reagent may be needed for IHC and ICC experiments to reduce high background signal. You can find these reagents under catalog numbers PK-2200-NB and MP-2400-NB. Please contact Technical Support if you have any questions.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG1
Theoretical MW
12.2 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for CHCHD5 Antibody (OTI3H3)
![Western Blot: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Western-Blot-NBP2-03608-img0002.jpg "Western Blot: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Western Blot: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Western Blot: CHCHD5 Antibody (3H3) [NBP2-03608] - HEK293T cells were transfected with the pCMV6-ENTRY control (Left lane) or pCMV6-ENTRY CHCHD5 (Right lane) cDNA for 48 hrs and lysed. Equivalent amounts of cell lysates (5 ug per lane) were separated by SDS-PAGE and immunoblotted with anti-CHCHD5.
Immunocytochemistry/Immunofluorescence: CHCHD5 Antibody (3H3) [NBP2-03608] Staining of COS7 cells transiently transfected by pCMV6-ENTRY CHCHD5.
![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0008.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Human tonsil using anti-CHCHD5 mouse monoclonal antibody.![Flow Cytometry: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Flow-Cytometry-NBP2-03608-img0001.jpg "Flow Cytometry: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Flow Cytometry: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Flow Cytometry: CHCHD5 Antibody (3H3) [NBP2-03608] - HEK293T cells transfected with either overexpression plasmid (Red) or empty vector control plasmid (Blue) were immunostained by anti-CHCHD5 antibody, and then analyzed by flow cytometry.![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0003.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Carcinoma of Human bladder tissue using anti-CHCHD5 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0004.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Carcinoma of Human liver tissue using anti-CHCHD5 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0005.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Human endometrium tissue using anti-CHCHD5 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0006.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Human Kidney tissue using anti-CHCHD5 mouse monoclonal antibody.![Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]](https://resources.rndsystems.com/images/products/CHCHD5-Antibody-3H3-Immunohistochemistry-Paraffin-NBP2-03608-img0007.jpg "Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]")
Immunohistochemistry-Paraffin: CHCHD5 Antibody (OTI3H3) [NBP2-03608]
Immunohistochemistry-Paraffin: CHCHD5 Antibody (3H3) [NBP2-03608] - Staining of paraffin-embedded Human lymphoma tissue using anti-CHCHD5 mouse monoclonal antibody.Applications for CHCHD5 Antibody (OTI3H3)
Application
Recommended Usage
Flow Cytometry
1:100
Immunocytochemistry/ Immunofluorescence
1:100
Immunohistochemistry
1:150
Immunohistochemistry-Paraffin
1:150
Western Blot
1:200
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Formulation
PBS (pH 7.3), 1.0% BSA and 50% Glycerol
Preservative
0.02% Sodium Azide
Concentration
0.35 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Background: CHCHD5
Alternate Names
C2orf9, chromosome 2 open reading frame 9, coiled-coil-helix-coiled-coil-helix domain containing 5, coiled-coil-helix-coiled-coil-helix domain-containing protein 5, FLJ39671, MGC11104
Entrez Gene IDs
84269 (Human)
Gene Symbol
CHCHD5
Additional CHCHD5 Products
Product Documents for CHCHD5 Antibody (OTI3H3)
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for CHCHD5 Antibody (OTI3H3)
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Customer Reviews for CHCHD5 Antibody (OTI3H3)
There are currently no reviews for this product. Be the first to review CHCHD5 Antibody (OTI3H3) and earn rewards!
Have you used CHCHD5 Antibody (OTI3H3)?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
