Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
Novus Biologicals | Catalog # NBP2-36490
Key Product Details
Species Reactivity
Validated:
Human
Predicted:
Primate (100%). Backed by our 100% Guarantee.
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG2b Kappa Clone # 3A7.1B8
Format
BSA Free
Loading...
Product Specifications
Immunogen
Partial recombinant protein from human Cyr61/CCN1 protein (between residues 100-300). [Swiss-Prot O00622]
Reactivity Notes
Immunogen's sequence similarity with other species: Rat (81%), Mouse (79%), Camel (88%), Naked Mole Rat (87%), Porcine (80%), Bovine / Sheep / Horse (82%), Chicken (63%)
Localization
Secreted (Cytoplasmic/Extracellular)
Clonality
Monoclonal
Host
Mouse
Isotype
IgG2b Kappa
Description
Novus Biologicals Mouse Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free (NBP2-36490) is a monoclonal antibody validated for use in IHC and WB. All Novus Biologicals antibodies are covered by our 100% guarantee.
Scientific Data Images for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
Western Blot: Cyr61/CCN1 Antibody (3A7.1B8)BSA Free [NBP2-36490]
Western Blot: Cyr61/CCN1 Antibody (3A7.1B8) [NBP2-36490] - WB analysis of (A) 12kDa Partial Recombinant Cyr61/CCN1 protein and (B) Human Liver lysate using Cyr61/CCN1 antibody (clone 3A7.1B8) at 4ug/ml concentration.Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free [NBP2-36490]
Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) [NBP2-36490] - IHC analysis of formalin-fixed paraffin-embedded tissue section of human liver using Cyr61/CCN1 antibody (clone 3A7.1B8) at 5 ug/ml concentration. The hepatocytes generated a specific cytoplasmic staining with no signal in the cellular nuclei or the sinusoids.Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free [NBP2-36490]
Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) [NBP2-36490] - IHC analysis of formalin-fixed paraffin-embedded tissue section of human hepatocellular carcinoma using Cyr61/CCN1 antibody (clone 3A7.1B8) at 5 ug/ml concentration. The cancer cells generated a specific cytoplasmic staining with some staining in the inter-cellular spaces but no signal in the cellular nuclei, tumor stroma or the RBCs.Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free [NBP2-36490]
Immunohistochemistry-Paraffin: Cyr61/CCN1 Antibody (3A7.1B8) [NBP2-36490] - IHC analysis of formalin-fixed paraffin-embedded tissue section of human Renal Cell Carcinoma using Cyr61/CCN1 antibody (clone 3A7.1B8) at 5 ug/ml concentration. The cancer cells generated a specific cytoplasmic staining with some staining in the inter-cellular spaces but no signal in the cellular nuclei, tumor stroma or the RBCs.Applications for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
Application
Recommended Usage
Immunohistochemistry
5 ug/ml
Immunohistochemistry-Paraffin
5 ug/ml
Western Blot
4 ug/ml
Application Notes
Protein CYR61 is a secreted protein and its expected immunolocalization would be cytoplasmic as well as the extracellular spaces.
Formulation, Preparation, and Storage
Purification
Protein G purified
Formulation
PBS
Format
BSA Free
Preservative
0.02% Sodium Azide
Concentration
1.0 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
Background: Cyr61/CCN1
Long Name
Cysteine-Rich, Angiogenic Inducer 61
Alternate Names
CCN1, GIG1, IGFBP-10
Gene Symbol
CCN1
UniProt
Additional Cyr61/CCN1 Products
Product Documents for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
Product Specific Notices for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Related Research Areas
Customer Reviews for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free
There are currently no reviews for this product. Be the first to review Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free and earn rewards!
Have you used Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
Protocols
View specific protocols for Cyr61/CCN1 Antibody (3A7.1B8) - BSA Free (NBP2-36490):
Cyr61/CCN1 Antibody (3A7.1B8):
1. Deparaffinize the tissue sections by immersing the slides in Xylene with two changes for 10 min each. Sections should not get dried at any stage from this point.
2. Rehydrate the tissue sections by immersing the slides in decreasing grades of ethanol as follows:
a. Immerse in 100% ethanol with 2 changes for 5 minutes each
b. Immerse in 95% ethanol with 2 changes for 5 minutes each
c. Immerse in 90% ethanol for 5 minutes
d. Immerse in 70% ethanol for 5 minutes
e. Immerse in 50% ethanol for 5 minutes
f. Immerse in distilled water for 5 minutes
3. Antigen Retrieval (Microwave Method):
a. Immerse the slides in a microwave compatible tray containing 10 mM Sodium Citrate buffer (pH 6.0) with 0.05% Tween 20.
b. Boil the slides and maintain the sub-boiling temperature for 5 minutes in the microwave. Thereafter, take out the tray very carefully and cool it at room temperature (RT) for about 30 minutes.
c. Wash the slides 3 times, 3 minutes each by immersing them in TBST (Tris Buffered Saline having 0.05% Tween 20).
4. Quenching of Endogenous Peroxidase:
a. Incubate the slides in 3% hydrogen peroxide prepared in methanol for 15 minutes (at RT, in dark conditions).
b. Wash the slides in TBST 3 times, 3 minutes each.
5. Protein Blocking:
a. Incubate the sections with background sniper solution at RT for 15 minutes (Biocare Medicals, USA).
b. Wash the sections 3 times, 3 min each by immersing the slides in TBST.
6. Primary Antibody:
a. Dilute the primary antibody at 5ug/ml concentration using PBS as a diluent.
b. Incubate the sections with diluted primary antibody for 90 minutes at RT in a humidified chamber.
c. Thereafter, wash the slides 4 times, 5 minutes each with TBST.
7. Probe (Secondary Reagent):
a. Incubate with MACH 1 Mouse probe for 15 minutes at RT.
b. Incubate for 30 min at room temperature with HRP-Polymer (Biocare Medical, USA).
c. Wash the slides with TBST 4 times, 5 minutes each
8. Chromogen:
a. Mix 32ul of DAB Chromogen with 1 ml of DAB substrate buffer (Biocare Medical, USA).
b. Apply 200ul DAB mixture/section and incubate at RT in dark conditions (few seconds - 5 minutes).
c. As soon as an appropriate color develops, rinse the slides with deionized water (2-3 brief rinses).
9. Counter stain:
a. Counter stain with Hematoxylin for 30 seconds (Vector Labs, USA).
b. Wash in deionized water for 1-2 minutes to clear the extra stain.
c. Incubate the slides in bluing solution or Scott's water twice for 2 minutes each time.
10. Dehydrate the sections in increasing grades of alcohols:
a. 50% alcohol for 1 minute
b. 70% for 1 minute
c. 90% for 1 minute
d. 95% for 1 minute
e. 100% for 1 minute
f. Xylene with 2 changes for 2 minutes each
11. Mount with DPX mount and cover-slip glass (Fisher Scientific, USA), carefully not allowing any air bubbles to enter.
NOTE:- This protocol is provided as a reference tool only. Depending upon the type of tissues /tissue processing and reagents employed, the end user will need to optimize the final conditions for achieving an expected staining.
1. Deparaffinize the tissue sections by immersing the slides in Xylene with two changes for 10 min each. Sections should not get dried at any stage from this point.
2. Rehydrate the tissue sections by immersing the slides in decreasing grades of ethanol as follows:
a. Immerse in 100% ethanol with 2 changes for 5 minutes each
b. Immerse in 95% ethanol with 2 changes for 5 minutes each
c. Immerse in 90% ethanol for 5 minutes
d. Immerse in 70% ethanol for 5 minutes
e. Immerse in 50% ethanol for 5 minutes
f. Immerse in distilled water for 5 minutes
3. Antigen Retrieval (Microwave Method):
a. Immerse the slides in a microwave compatible tray containing 10 mM Sodium Citrate buffer (pH 6.0) with 0.05% Tween 20.
b. Boil the slides and maintain the sub-boiling temperature for 5 minutes in the microwave. Thereafter, take out the tray very carefully and cool it at room temperature (RT) for about 30 minutes.
c. Wash the slides 3 times, 3 minutes each by immersing them in TBST (Tris Buffered Saline having 0.05% Tween 20).
4. Quenching of Endogenous Peroxidase:
a. Incubate the slides in 3% hydrogen peroxide prepared in methanol for 15 minutes (at RT, in dark conditions).
b. Wash the slides in TBST 3 times, 3 minutes each.
5. Protein Blocking:
a. Incubate the sections with background sniper solution at RT for 15 minutes (Biocare Medicals, USA).
b. Wash the sections 3 times, 3 min each by immersing the slides in TBST.
6. Primary Antibody:
a. Dilute the primary antibody at 5ug/ml concentration using PBS as a diluent.
b. Incubate the sections with diluted primary antibody for 90 minutes at RT in a humidified chamber.
c. Thereafter, wash the slides 4 times, 5 minutes each with TBST.
7. Probe (Secondary Reagent):
a. Incubate with MACH 1 Mouse probe for 15 minutes at RT.
b. Incubate for 30 min at room temperature with HRP-Polymer (Biocare Medical, USA).
c. Wash the slides with TBST 4 times, 5 minutes each
8. Chromogen:
a. Mix 32ul of DAB Chromogen with 1 ml of DAB substrate buffer (Biocare Medical, USA).
b. Apply 200ul DAB mixture/section and incubate at RT in dark conditions (few seconds - 5 minutes).
c. As soon as an appropriate color develops, rinse the slides with deionized water (2-3 brief rinses).
9. Counter stain:
a. Counter stain with Hematoxylin for 30 seconds (Vector Labs, USA).
b. Wash in deionized water for 1-2 minutes to clear the extra stain.
c. Incubate the slides in bluing solution or Scott's water twice for 2 minutes each time.
10. Dehydrate the sections in increasing grades of alcohols:
a. 50% alcohol for 1 minute
b. 70% for 1 minute
c. 90% for 1 minute
d. 95% for 1 minute
e. 100% for 1 minute
f. Xylene with 2 changes for 2 minutes each
11. Mount with DPX mount and cover-slip glass (Fisher Scientific, USA), carefully not allowing any air bubbles to enter.
NOTE:- This protocol is provided as a reference tool only. Depending upon the type of tissues /tissue processing and reagents employed, the end user will need to optimize the final conditions for achieving an expected staining.
Cyr61/CCN1 Antibody (3A7.1B8):
Western Blot Protocol
1. Perform SDS-PAGE on samples to be analyzed, loading 25 ug of total protein per lane.
2. Transfer proteins to membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain according to standard Ponceau S procedure (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot.
5. Block the membrane using standard blocking buffer for at least 1 hour.
6. Wash the membrane in wash buffer three times for 10 minutes each.
7. Dilute anti-Cyr61/CCN1 (3A7.1B8) primary antibody in blocking buffer and incubate 1 hour at room temperature.
8. Wash the membrane in wash buffer three times for 10 minutes each.
9. Apply the diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturers instructions) and incubate 1 hour at room temperature.
10. Wash the blot in wash buffer three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
Note: Tween-20 can be added to the blocking or antibody dilution buffer at a final concentration of 0.05-0.2%.
Western Blot Protocol
1. Perform SDS-PAGE on samples to be analyzed, loading 25 ug of total protein per lane.
2. Transfer proteins to membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain according to standard Ponceau S procedure (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot.
5. Block the membrane using standard blocking buffer for at least 1 hour.
6. Wash the membrane in wash buffer three times for 10 minutes each.
7. Dilute anti-Cyr61/CCN1 (3A7.1B8) primary antibody in blocking buffer and incubate 1 hour at room temperature.
8. Wash the membrane in wash buffer three times for 10 minutes each.
9. Apply the diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturers instructions) and incubate 1 hour at room temperature.
10. Wash the blot in wash buffer three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
Note: Tween-20 can be added to the blocking or antibody dilution buffer at a final concentration of 0.05-0.2%.
