gp96/HSP90B1/GRP94 Antibody (CL2647) - BSA Free

Novus Biologicals | Catalog # NBP2-42379

Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Knockout/Knockdown, Orthogonal Validation

Species Reactivity

Validated:

Human

Cited:

Human

Predicted:

Mouse (90%). Backed by our 100% Guarantee.

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence, Knockdown Validated

Cited:

Western Blot, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2B Clone # CL2647

Format

BSA Free
View all gp96/HSP90B1 Primary Antibodies »

Product Specifications

Immunogen

This antibody was developed using a recombinant protein derived from P14625, with the exact immunogen sequence remaining proprietary.

Reactivity Notes

Expected species cross reactivity based on sequence identity: Rat (87%). Please note that this antibody is reactive to Mouse and derived from the same host, Mouse. Mouse-On-Mouse blocking reagent may be needed for IHC and ICC experiments to reduce high background signal. You can find these reagents under catalog numbers PK-2200-NB and MP-2400-NB. Please contact Technical Support if you have any questions

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2B

Scientific Data Images for gp96/HSP90B1/GRP94 Antibody (CL2647) - BSA Free

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining in human prostate and skeletal muscle tissues using NBP2-42379 antibody. Corresponding HSP90B1 RNA-seq data are presented for the same tissues.
Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Analysis in U-251MG cells transfected with control siRNA, target specific siRNA probe #1 and #2, using Anti-HSP90B1 antibody. Remaining relative intensity is presented. Loading control: Anti-PPIB.
Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining in U251 cell line showing specific staining of endoplasmic reticulum in green. Microtubule-staining and nuclear probes are visualized in red and blue respectively (where available). Antibody staining is shown in green. Antibody staining is shown in green.
Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Western Blot: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Analysis in human cell line HeLa, human cell line HEK 293, human cell line A-431 and human cell line HepG2.
Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining in HeLa cell line showing specific staining of endoplasmic reticulum in green. Microtubule-staining and nuclear probes are visualized in red and blue respectively (where available). Antibody staining is shown in green. Antibody staining is shown in green.
Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining of human cell line A431 showing specific staining of endoplasmic reticulum in green. Microtubule-staining and nuclear probes are visualized in red and blue respectively (where available). Antibody staining is shown in green. Antibody staining is shown in green.
Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining in MCF7 cell line showing specific staining of endoplasmic reticulum in green. Microtubule-staining and nuclear probes are visualized in red and blue respectively (where available). Antibody staining is shown in green. Antibody staining is shown in green.
Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/ Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunocytochemistry/Immunofluorescence: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining in U2OS cell line with Anti-HSP90B1 monoclonal antibody, showing specific staining of endoplasmic reticulum in green. Microtubule-staining and nuclear probes are visualized in red and blue respectively (where available). Antibody staining is shown in green. Antibody staining is shown in green.
Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining of human cerebral cortex shows strong cytoplasmic positivity in neurons.
Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining of human placenta shows strong cytoplasmic positivity in trophoblastic cells.
Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining of human prostate shows strong cytoplasmic positivity in glandular cells.
Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379]

Immunohistochemistry-Paraffin: gp96/HSP90B1/GRP94 Antibody (CL2647) [NBP2-42379] - Staining of human skeletal muscle shows very weak cytoplasmic positivity in myocytes.
gp96/HSP90B1/GRP94 Antibody (CL2647) - BSA Free

gp96/HSP90B1/GRP94 (CL2647) in A431 Human Cell Line.

gp96/HSP90B1/GRP94 (CL2647) was detected in immersion fixed A431 human skin carcinoma cell line using Mouse anti-gp96/HSP90B1/GRP94 (CL2647) Protein A Purified Monoclonal Antibody conjugated to Alexa Fluor® 647 (Catalog # NBP2-42379) (light blue) at 2 µg/mL overnight at 4C. Cells were counterstained with DAPI (blue). Cells were imaged using a 100X objective and digitally deconvolved.

Applications for gp96/HSP90B1/GRP94 Antibody (CL2647) - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

2-10 ug/ml

Immunohistochemistry

1:5000 - 1:10000

Immunohistochemistry-Paraffin

1:5000 - 1:10000

Western Blot

1 ug/ml
Application Notes
For IHC-Paraffin, HIER pH 6 retrieval is recommended. ICC/IF Fixation Permeabilization: Use PFA/Triton X-100.

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

PBS (pH 7.2) and 40% Glycerol

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: gp96/HSP90B1

Glucose-regulated protein 94, also known as Grp94 or gp96, is an abundant resident endoplasmic reticulum (ER) lumenal stress protein which together with cytosolic Hsp90 belongs to the Hsp90 family of molecular chaperones. Grp94 and other resident soluble proteins of the ER such as members of the Ca(2+) binding protein subfamily (CaBP), CaBPI and CaBP2 as well as calreticulin, possess the COOH-terminal tetrapeptide Lys-Asp-Glu-Leu (KDEL) which is a sorting signal that is thought to lead to the retention of these proteins in the pre-Golgi compartments (1). Grp94 expression is upregulated by stress conditions such as lucose starvation and heat shock, which promote protein misfolding or unfolding (2). In addition to a homeostatic role in protein folding and assembly, Grp94 can function in the intracellular trafficking of peptides from the extracellular space to the MHC class I antigen processing pathway of antigen presentation cells (3,4). Grp94 and Hsp90 share high sequence identity and presumably identical adenosine nucleotide-dependent modes of regulation. Earlier data suggests that Hsp90 and Grp94 may differ in their nucleotide binding properties. The N-terminal domain of eukaryotic Hsp90 proteins contains a conserved adenosine nucleotide binding pocket which also serves as the inding site for the Hsp90 inhibitors geldanamycin and radicicol. However, the molecular basis for adenosine nucleotide-dependent regulation of Grp94remains to be established. Recent data has entified a ligand dependent regulation of Grp94 function and suggest a model whereby Grp94 function is regulated through a ligand-dependent conversion of Grp94 from an inactive to an active conformation (5, 6).

Long Name

Heat Shock Protein 90 beta 1

Alternate Names

ECGP, Endoplasmin, Grp94, HSP90B1

Gene Symbol

HSP90B1
