Reviews (1)

Human CCL4/MIP-1 beta Quantikine ELISA Kit Summary

Assay Type
Solid Phase Sandwich ELISA
Format
96-well strip plate
Assay Length
3.0 hours or 4.5 hours
Sample Type & Volume Required Per Well
Cell Culture Supernates (10 uL), Serum (150 uL), EDTA Plasma (150 uL), Heparin Plasma (150 uL), Citrate Plasma (150 uL)
Sensitivity
11 pg/mL
Assay Range
15.6 - 1,000 pg/mL (Cell Culture Supernates), 31.2 - 2,000 pg/mL (Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma)
Specificity
Natural and recombinant human MIP-1 beta
Cross-reactivity
< 0.5% cross-reactivity observed with available related molecules.< 50% cross-species reactivity observed with species tested.
Interference
No significant interference observed with available related molecules.

Product Summary

The Quantikine Human MIP-1 beta Immunoassay is a 3.0 or 4.5 hour solid phase ELISA designed to measure MIP-1 beta in cell culture supernates, serum, and plasma. It contains E. coli-expressed recombinant human MIP-1 beta (Act-2 variant) and antibodies raised against the recombinant factor. This immunoassay has been shown to accurately quantitate the recombinant human MIP-1 beta. Results obtained using natural human MIP-1 beta showed linear curves that were parallel to the standard curves obtained using the Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values for natural human MIP-1 beta.

Precision

Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision
Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision

Cell Culture Supernates

Intra-Assay Precision Inter-Assay Precision
Sample 1 2 3 1 2 3
n 20 20 20 40 40 40
Mean 23.3 98.8 428 31.4 118 476
Standard Deviation 1.1 3.8 17.3 3.7 9.9 28
CV% 4.7 3.8 4 11.8 8.4 5.9

Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma

Intra-Assay Precision Inter-Assay Precision
Sample 1 2 3 1 2 3
n 20 20 20 40 40 40
Mean 51.3 208 932 58.8 220 949
Standard Deviation 4.6 7.5 30.2 5.7 15.6 70.5
CV% 9 3.6 3.2 9.7 7.1 7.4

Recovery

The recovery of MIP-1 beta spiked to three levels in samples throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=5) 107 81-117
Citrate Plasma (n=5) 99 87-116
EDTA Plasma (n=5) 100 84-112
Heparin Plasma (n=5) 99 90-112
Serum (n=5) 99 88-113

Linearity

To assess the linearity of the assay, five samples were spiked with high concentrations of MIP-1 beta in various matrices and diluted with the appropriate Calibrator Diluent to produce samples with values within the dynamic range of the assay.
Human CCL4/MIP-1 beta ELISA Linearity

Data Examples

Human CCL4/MIP-1 beta ELISA Cell Culture Supernate Standard Curve

Human CCL4/MIP-1 beta ELISA Serum/Plasma Standard Curve

Product Datasheets

Preparation and Storage

Storage
Store the unopened product at 2 - 8 °C. Do not use past expiration date.

Background: CCL4/MIP-1 beta

CCL4/MIP-1 beta is a beta chemokine that is secreted at sites of inflammation by activated leukocytes, lymphocytes, vascular endothelial cells, and pulmonary smooth muscle cells. It attracts a variety of immune cells to sites of microbial infection as well as to other pathologic inflammation such as allergic asthma and ischemic myocardium. CCL4 is secreted from activated monocytes as a heterodimer with CCL3/MIP-1 alpha. It signals through CCR5, and an N-terminally trimmed form additionally interacts with CCR1 and CCR2. In humans, the ability of CCL4 to bind CCR5 inhibits the cellular entry of M-tropic HIV-1 which utilizes CCR5 as a coreceptor.

Entrez Gene IDs:
6351 (Human); 20303 (Mouse); 116637 (Rat); 448786 (Canine)
Alternate Names:
ACT2; ACT-2; AT744.1; C-C motif chemokine 4; CCL4; chemokine (C-C motif) ligand 4; Exodus-3; G-26 T-lymphocyte-secreted protein; G-26; HC21; LAG1; LAG-1; Lymphocyte activation gene 1 protein; Macrophage inflammatory protein 1-beta; MIP1 beta; MIP-1 beta; MIP1B; MIP1B1; MIP-1-beta; MIP-1-beta(1-69); PAT 744; Protein H400; SCYA2; SCYA4; secreted protein G-26; SIS-gamma; small inducible cytokine A4 (homologous to mouse Mip-1b); Small-inducible cytokine A4; T-cell activation protein 2
⚠ WARNING: This product can expose you to chemicals including N,N-Dimethylforamide, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

Assay Procedure

Refer to the product for complete assay procedure.

Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
  1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
  2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.

  3. Add Assay Diluent
  4.   For Serum & Plasma Samples: Add 100 µL of Assay Diluent to each well.
    For Cell Culture Supernate Samples: Add 50 µL Assay Diluent to each well.

  5. Add Standard, Control, or Sample
  6.   For Serum & Plasma Samples: Add 150 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours.
    For Cell Culture Supernate Samples: Add 200 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 1.25 hours.
  7.   Aspirate each well and wash, repeating the process twice for a total of 3 washes.

  8. 200 µL Conjugate
  9.   Add 200 µL of Conjugate to each well.
  10.   For Serum & Plasma Samples: Cover with a new plate sealer, and incubate at room temperature for 2 hours.
    For Cell Culture Supernate Samples: Cover with a new plate sealer, and incubate at room temperature for 1.25 hours.
  11.   Aspirate and wash 3 times.

  12. 200 µL Substrate Solution
  13.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 20 minutes. PROTECT FROM LIGHT.

  14. 50 µL Stop Solution
  15. Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
