Human IL-12/IL-23 p40 Quantikine ELISA Kit

(21 citations)
  • Assay Type
    Solid Phase Sandwich ELISA
  • Format
    96-well strip plate
  • Assay Length
    3.5 hours or 4.5 hours
  • Sample Type & Volume Required Per Well
    Cell Culture Supernates (100 uL), Serum (100 uL), EDTA Plasma (100 uL), Heparin Plasma (100 uL), Citrate Plasma (100 uL)
  • Sensitivity
    15 pg/mL
  • Assay Range
    31.2 - 2,000 pg/mL (Cell Culture Supernates, Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma)
  • Specificity
    Natural and recombinant human IL-12 p40
  • Cross-reactivity
    Cross-reactivity observed with 1 or more available related molecules.< 50% cross-species reactivity observed with species tested.
  • Interference
    No significant interference observed with available related molecules.
Control Available
Product Summary
The Quantikine Human IL-12 p40 Immunoassay is a 3.5 or 4.5 hour solid phase ELISA designed to measure IL-12 p40 in cell culture supernates, serum, and plasma. It contains recombinant human IL-12 p40 and antibodies raised against the recombinant factor. This immunoassay has been shown to accurately quantitate recombinant human IL-12 p40. Results obtained using natural human IL-12 p40 showed dose-response curves that were parallel to the standard curves obtained using the recombinant Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values for natural human IL-12 p40.

Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision.
Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision.
Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma
Intra-Assay Precision Inter-Assay Precision
Standard Deviation9.927.262.31122.363

Cell Culture Supernates
Intra-Assay Precision Inter-Assay Precision
Standard Deviation5.111.435.511.819.860.6


The recovery of IL-12 p40 spiked to three different levels throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=5) 96 85-105
Citrate Plasma (n=5) 100 85-112
EDTA Plasma (n=5) 101 92-113
Heparin Plasma (n=5) 96 89-106
Serum (n=5) 98 86-112
To assess the linearity of the assay, five samples were spiked with high concentrations of IL-12 p40 in various matrices and diluted with the appropriate Calibrator Diluent to produce samples with values within the dynamic range of the assay.
Human IL-12/IL-23 p40 Quantikine ELISA Kit
Preparation and Storage
  • Storage
    Store the unopened product at 2 - 8 °C. Do not use past expiration date.
Background: IL-12/IL-23 p40

Interleukin 12 (IL-12), also known as natural killer cell stimulatory factor (NKSF) or cytotoxic lymphocyte maturation factor (CLMF), is a heterodimeric pleiotropic cytokine made up of a 40 kDa (p40) subunit and a 35 kDa (p35) subunit. The IL-12 p40 subunit is shared by IL-23, another heterodimeric cytokine that has biological activities similar to, as well as distinct from, IL-12. IL-12 is produced by macrophages and B cells and has been shown to have multiple effects on T cells and natural killer (NK) cells. While mouse IL-12 is active on both human and mouse cells, human IL-12 is not active on mouse cells.

    • Long Name
      Interleukin 12/Interleukin 23 p40
    • Entrez Gene IDs
      3593 (Human); 16160 (Mouse); 64546 (Rat); 403976 (Canine); 493741 (Feline);
    • Alternate Names
      CLMF2; IL12 p40; IL12B; IL-12B; NKSF2;
    Related Research Areas
    Assay Procedure
    Refer to the product for complete assay procedure.

    Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
    1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
    2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.

    3. 100 µL Assay Diluent
    4.   Add 100 µL of Assay Diluent to each well.

    5. 100 µL Standard, Control, or Sample
    6.   Add 100 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours.
    7.   Aspirate each well and wash, repeating the process 3 times for a total of 4 washes.

    8. 200 µL Conjugate
    9.   Add 200 µL of Conjugate to each well.
    10.   For Serum & Plasma Samples: Cover with a new plate sealer, and incubate at room temperature for 2 hours.
      For Cell Culture Supernate Samples: Cover with a new plate sealer, and incubate at room temperature for 1 hour.
    11.   Aspirate and wash 4 times.

    12. 200 µL Substrate Solution
    13.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 30 minutes. PROTECT FROM LIGHT.

    14. 50 µL Stop Solution
    15. Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
