• Assay Type
    Solid Phase Sandwich ELISA
  • Format
    96-well strip plate
  • Assay Length
    3.5 hours or 4.5 hours
  • Sample Type & Volume Required Per Well
    Cell Culture Supernates (100 uL), Serum (100 uL), EDTA Plasma (100 uL), Heparin Plasma (100 uL), Citrate Plasma (100 uL), Urine (100 uL)
  • Sensitivity
    7 pg/mL
  • Assay Range
    15.6 - 1,000 pg/mL (Cell Culture Supernates, Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma, Urine)
  • Specificity
    Natural and recombinant human PlGF
  • Cross-reactivity
    Cross-reactivity observed with 1 or more available related molecules.Cross-species reactivity not tested.
  • Interference
    Interference observed with 1 or more available related molecules.
Control Available
Product Summary
The Quantikine Human PlGF Immunoassay is a 3.5 or 4.5 hour solid phase ELISA designed to measure human PlGF in cell culture supernates, serum, plasma, and urine. The immunoassay kit contains E. coli-expressed recombinant human PlGF and antibodies raised against the recombinant factor. This immunoassay has been shown to quantitate recombinant human PlGF accurately. Results obtained using natural human PlGF showed dose curves that were parallel to the standard curves obtained using the recombinant Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values for natural human PlGF.

Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision.
Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision.
Cell Culture Supernates
Intra-Assay Precision Inter-Assay Precision
Standard Deviation2.47.338.26.413.532.9

Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma, Urine
Intra-Assay Precision Inter-Assay Precision
Standard Deviation3.86.336.96.520.378.9


The recovery of PlGF spiked to three different levels throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=5) 97 82-107
Citrate Plasma (n=5) 99 93-120
EDTA Plasma (n=5) 102 92-117
Heparin Plasma (n=5) 94 81-113
Serum (n=5) 96 88-118
Urine (n=4) 97 85-112
To assess the linearity of the assay, five samples were spiked with high concentrations of PlGF in various matrices and diluted with the appropriate Calibrator Diluent to produce samples with values within the dynamic range of the assay.
Human PlGF Quantikine ELISA Kit
Preparation and Storage
  • Storage
    Store the unopened product at 2 - 8 °C. Do not use past expiration date.
Background: PlGF
PlGF (placenta growth factor) is a homodimeric growth factor that competes with VEGF for binding to VEGF R1/Flt-1. It therefore increases the availability of VEGF to bind to VEGF R2/KDR/Flk-1 and trigger angiogenesis. It can form heterodimers with some forms of VEGF and decrease the angiogenic effect of VEGF on VEGF R2. Circulating PlGF levels increase during pregnancy, reaching a peak in mid-gestation; this increase is attenuated in preeclampsia. PlGF induces monocyte activation and migration as well as production of inflammatory cytokines and VEGF. These activities facilitate wound, bone fracture, and cardiac repair, but also contribute to inflammation in active sickle cell disease and atherosclerosis. PlGF can also inhibit TIMP3 expression in the spleen, leading to immune triggering of hypertension.
    • Long Name
      Placenta Growth Factor
    • Entrez Gene IDs
      5228 (Human); 18654 (Mouse);
    • Alternate Names
      D12S1900; PGF; PGFL; placenta growth factor; placental growth factor; placental growth factor, vascular endothelial growth factor-related protein; PlGF; PlGF-2; PLGFplacental growth factor-like; SHGC-10760;
    Related Research Areas
    Assay Procedure
    Refer to the product for complete assay procedure.

    Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
    1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
    2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.

    3. 100 µL Assay Diluent
    4.   Add 100 µL of Assay Diluent to each well.

    5. 100 µL Standard, Control, or Sample
    6.   Add 100 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours.
    7.   Aspirate each well and wash, repeating the process 3 times for a total of 4 washes.

    8. 200 µL Conjugate
    9.   Add 200 µL of Conjugate to each well.
    10.   For Serum, Plasma, & Urine Samples: Cover with a new plate sealer, and incubate at room temperature for 2 hours.
      For Cell Culture Supernate Samples: Cover with a new plate sealer, and incubate at room temperature for 1 hour.
    11.   Aspirate and wash 4 times.

    12. 200 µL Substrate Solution
    13.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 30 minutes. PROTECT FROM LIGHT.

    14. 50 µL Stop Solution
    15. Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
