MUC1 Antibody (SN06-80)

Novus Biologicals | Catalog # NBP2-67650

Recombinant Monoclonal Antibody
Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Biological Validation

Species Reactivity

Human, Mouse, Rat

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # SN06-80 expressed in HEK293
View all MUC-1 Primary Antibodies »

Product Specifications

Immunogen

Synthetic peptide within Human MUC1 aa 1,206-1,255 / 1,255. (SwissProt: P15941 Human; SwissProt: Q02496 Mouse)

Localization

Apical cell membrane, Secreted, Cell membrane, Cytoplasm, Nucleus.

Specificity

specific to MUC1 beta subunit

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for MUC1 Antibody (SN06-80)

Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650]

Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650]

Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650] - Western blot analysis of MUC1 on different lysates. Proteins were transferred to a PVDF membrane and blocked with 5% BSA in PBS for 1 hour at room temperature. The primary antibody (1/500) was used in 5% BSA at room temperature for 2 hours. Goat Anti-Rabb
Immunocytochemistry/ Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunocytochemistry/ Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunocytochemistry/Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650] - Staining MUC1 in B16-F1 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650] - Immunohistochemical analysis of paraffin-embedded human kidney tissue using anti-MUC1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes. The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Flow Cytometry: MUC1 Antibody (SN06-80) [NBP2-67650]

Flow Cytometry: MUC1 Antibody (SN06-80) [NBP2-67650]

Flow Cytometry: MUC1 Antibody (SN06-80) [NBP2-67650] - Analysis of MCF-7 cells with MUC1 antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti rabbit IgG was used as the secondary antibody.
Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650]

Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650]

Western Blot: MUC1 Antibody (SN06-80) [NBP2-67650] - Analysis of MUC1 on Hela cells lysates using anti-MUC1 antibody at 1/1,000 dilution.
Immunocytochemistry/ Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunocytochemistry/ Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunocytochemistry/Immunofluorescence: MUC1 Antibody (SN06-80) [NBP2-67650] - Staining MUC1 in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650] - Analysis of paraffin-embedded human breast carcinoma tissue using anti-MUC1 antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650] - Analysis of paraffin-embedded human breast tissue using anti-MUC1 antibody. Counter stained with hematoxylin.
Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650]

Immunohistochemistry-Paraffin: MUC1 Antibody (SN06-80) [NBP2-67650] - Analysis of paraffin-embedded human kidney tissue using anti-MUC1 antibody. Counter stained with hematoxylin.

Applications for MUC1 Antibody (SN06-80)

Application
Recommended Usage

Flow Cytometry

1:50-1:100

Immunocytochemistry/ Immunofluorescence

1:50-1:200

Immunohistochemistry-Paraffin

1:50-1:1000

Western Blot

1:1000-1:2000

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

TBS (pH7.4), 0.05% BSA, 40% Glycerol

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: MUC-1

Mucin 1 (MUC1), also known as episialin, EMA (epithelial membrane antigen), PEM (polymorphic epithelial mucin), and CA-15-3 antigen, is a membrane-bound type I transmembrane glycoprotein (1,2). MUC1 is typically expressed in the luminal or glandular epithelial cells of the gastrointestinal tract, breast, lungs, and more, and is often overexpressed in epithelial cancers, but also serves a protective role against infection and helps regulate inflammatory response (2,3). Human MUC1 is 1255 amino acids (aa) in length with a theoretical molecular weight of 122 kDa; however, depending on the amount of glycosylation can weigh between 250 - 500 kDa (2,4). Structurally, MUC1 consists of a N-terminal domain which contains a signal peptide, a variable number tandem repeat region (VNTR), and a SEA domain, as well a C-terminal domain which has the extracellular domain (ECD), transmembrane domain (TMD), and cytoplasmic tail (CT) (2,3). The VNTR is comprised of between 25 - 125 repeats of a 20 aa conserved sequence (3). MUC1 is heavily O-glycosylated in the VNTR and has moderate N-glycosylation sites following the VNTR and in the ECD (2). Glycosylation contributes to MUC1's functional properties (2). The MUC1 gene contains seven exons, giving rise to several MUC1 isoforms as a result of alternative splicing (2).

Overexpression of mucins, including MUC1, is a feature of many epithelial cancers (1,3,5,6). The presence of truncated glycan structures called tumor-associated carbohydrate antigens (TACAs) on MUC1 play a role in cancer progression and a loss of apical-basal polarity (5). Carbohydrate-binding partners called lectins are the primary binding partners of TACAs that give rise to the pro-tumor microenvironment and metastasis (5). Given this unique feature, TACAs are a potential target for cancer immunotherapies (5). There are a number of vaccines, drugs, and antibodies targeting MUC1 for treatment of a variety of cancers including breast, lung, and prostate (6). In addition to a role in cancer progression, MUC1, and specifically the CT portion, has been shown to have a positive, anti-inflammatory role in a variety of lung and airway infections (7).

References

1. Khodabakhsh, F., Merikhian, P., Eisavand, M. R., & Farahmand, L. (2021). Crosstalk between MUC1 and VEGF in angiogenesis and metastasis: a review highlighting roles of the MUC1 with an emphasis on metastatic and angiogenic signaling. Cancer cell international. https://doi.org/10.1186/s12935-021-01899-8

2. Nath, S., & Mukherjee, P. (2014). MUC1: a multifaceted oncoprotein with a key role in cancer progression. Trends in molecular medicine. https://doi.org/10.1016/j.molmed.2014.02.007

3. Dhar, P., & McAuley, J. (2019). The Role of the Cell Surface Mucin MUC1 as a Barrier to Infection and Regulator of Inflammation. Frontiers in cellular and infection microbiology. https://doi.org/10.3389/fcimb.2019.00117

4. Uniprot (P15941)

5. Beckwith, D. M., & Cudic, M. (2020). Tumor-associated O-glycans of MUC1: Carriers of the glyco-code and targets for cancer vaccine design. Seminars in immunology. https://doi.org/10.1016/j.smim.2020.101389

6. Almasmoum H. (2021). The Roles of Transmembrane Mucins Located on Chromosome 7q22.1 in Colorectal Cancer. Cancer management and research. https://doi.org/10.2147/CMAR.S299089

7. Ballester, B., Milara, J., & Cortijo, J. (2021). The role of mucin 1 in respiratory diseases. European respiratory review : an official journal of the European Respiratory Society. https://doi.org/10.1183/16000617.0149-2020

Long Name

Mucin 1, Cell Surface-associated

Alternate Names

CD227, Episialin, H23AG, KL-6, Mucin-1, PEM, PEMT

Gene Symbol

MUC1

Additional MUC-1 Products

Product Documents for MUC1 Antibody (SN06-80)

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for MUC1 Antibody (SN06-80)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Customer Reviews for MUC1 Antibody (SN06-80)

There are currently no reviews for this product. Be the first to review MUC1 Antibody (SN06-80) and earn rewards!

Have you used MUC1 Antibody (SN06-80)?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs for MUC1 Antibody (SN06-80)

Showing  1 - 1 of 1 FAQ Showing All

  • Q: I would like to perform a sandwich assay for the determination of MUC1 protein. May you suggest me some antibodies that can be used together? In particular, if possible, I should need antibodies product in mouse or rabbit.

    A:

    Unfortunately we are not aware of a pair of antibodies that have been used in sandwich ELISA in particular. If you are interested in trying two you may find our Innovators Reward Program to be helpful.

Showing  1 - 1 of 1 FAQ Showing All
View all FAQs for Antibodies
