PDE6D Antibody - BSA Free

Novus Biologicals | Catalog # NBP3-35202

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Human, Mouse, Rat

Applications

Western Blot, ELISA, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Polyclonal Rabbit IgG

Format

BSA Free
View all PDE6D Primary Antibodies »

Product Specifications

Immunogen

Recombinant fusion protein containing a sequence corresponding to amino acids 1-150 of human PDE6D (NP_002592.1).

Sequence:
MSAKDERAREILRGFKLNWMNLRDAETGKILWQGTEDLSVPGVEHEARVPKKILKCKAVSRELNFSSTEQMEKFRLEQKVYFKGQCLEEWFFEFGFVIPNSTNTWQSLIEAAPESQMMPASVLTGNVIIETKFFDDDLLVSTSRVRLFYV

Clonality

Polyclonal

Host

Rabbit

Isotype

IgG

Theoretical MW

17 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for PDE6D Antibody - BSA Free

PDE6D Antibody

Western Blot: PDE6D Antibody [NBP3-35202] -

Western Blot: PDE6D Antibody [NBP3-35202] - Western blot analysis of various lysates using PDE6D Rabbit pAb at 1:1000 dilution.
Secondary antibody: HRP-conjugated Goat anti-Rabbit IgG (H+L) at 1:10000 dilution.
Lysates/proteins: 25ug per lane.
Blocking buffer: 3% nonfat dry milk in TBST.
Detection: ECL Basic Kit.
Exposure time: 10s.
PDE6D Antibody

Immunocytochemistry/ Immunofluorescence: PDE6D Antibody [NBP3-35202] -

Immunocytochemistry/ Immunofluorescence: PDE6D Antibody [NBP3-35202] - Immunofluorescence analysis of L929 cells using PDE6D Rabbit pAb at dilution of 1:100 (40x lens). Secondary antibody: Cy3-conjugated Goat anti-Rabbit IgG (H+L) at 1:500 dilution. Blue: DAPI for nuclear staining.
PDE6D Antibody

Immunocytochemistry/ Immunofluorescence: PDE6D Antibody [NBP3-35202] -

Immunocytochemistry/ Immunofluorescence: PDE6D Antibody [NBP3-35202] - Immunofluorescence analysis of U-2 OS cells using PDE6D Rabbit pAb at dilution of 1:100 (40x lens). Secondary antibody: Cy3-conjugated Goat anti-Rabbit IgG (H+L) at 1:500 dilution. Blue: DAPI for nuclear staining.

Applications for PDE6D Antibody - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:50 - 1:100

Western Blot

1:500 - 1:2000

Formulation, Preparation, and Storage

Purification

Affinity purified

Formulation

PBS (pH 7.3), 50% glycerol

Format

BSA Free

Preservative

0.01% Thimerosal

Concentration

Please see the vial label for concentration. If unlisted please contact technical services.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at -20C. Avoid freeze-thaw cycles.

Background: PDE6D

PDE6D is the effector enzyme in the G protein-mediated signal transduction cascade in the visual system. The second messengers cAMP and cGMP are key regulatory molecules that are involved in a wide variety of signal transduction pathways, such as insulin secretion, platelet aggregation, smooth muscle relaxation, olfaction, and vision. Levels of cAMP and cGMP are regulated by their rate of synthesis by nucleotide cyclases and by their rate of hydrolysis by cyclic nucleotide phosphodiesterases (PDEs). PDEs form a superfamily of enzymes that catalyze the conversion of 3-prime, 5-prime-cyclic nucleotides to the corresponding nucleoside 5-prime-monophosphates. While mammalian PDEs are divided into major families based on their substrate specificities, kinetic properties, allosteric regulators, inhibitor sensitivities, and amino acid sequences, each family and even members within a family display distinct tissue, cell, and subcellular expression patters. This suggests that individual PDE family members are involved in discrete signal transduction pathways. There are five different subunits consisting of rod and cone specific catalytic subunits: alpha® (Cone), alpha (Rod), and beta (Rod), the inhibitory subunit gamma, and subunit delta of unknown function (which likely interacts with many other proteins besides the PDE6 family). The catalytic core of the PDE6 system is comprised of alpha®/alpha® homodimers in the cone and alpha/beta heterodimers in the rod. The C-terminus of both the catalytic and inhibitory subunits is modified by methylation, myristyolation and prenylation which have been shown to be critical for proper complex assembly and membrane association.

Long Name

Retinal rod rhodopsin-sensitive cGMP 3',5'-cyclic phosphodiesterase subunit delta

Alternate Names

GMP-PDE delta, PDED, Protein p17

Gene Symbol

PDE6D
