Key Product Details

Species Reactivity

Human, Mouse, Rat

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation

Label

Unconjugated

Antibody Source

Polyclonal Rabbit IgG

Format

BSA Free
Loading...

Product Specifications

Immunogen

Sequence from the C-terminal region of PDE9A

Clonality

Polyclonal

Host

Rabbit

Isotype

IgG

Theoretical MW

68 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for PDE9A Antibody - BSA Free

Western Blot: PDE9A AntibodyBSA Free [NBP1-00641]

Western Blot: PDE9A AntibodyBSA Free [NBP1-00641]

Western Blot: PDE9A Antibody [NBP1-00641] - WB analysis of PDE9A in HeLa whole cell lysate.
Immunocytochemistry/ Immunofluorescence: PDE9A Antibody - BSA Free [NBP1-00641]

Immunocytochemistry/ Immunofluorescence: PDE9A Antibody - BSA Free [NBP1-00641]

Immunocytochemistry/Immunofluorescence: PDE9A Antibody [NBP1-00641] - PDE9A antibody was tested in NIH/3T3 cells with Dylight 488 (green). Nuclei were counterstained with DAPI (blue).
Immunohistochemistry: PDE9A Antibody - BSA Free [NBP1-00641]

Immunohistochemistry: PDE9A Antibody - BSA Free [NBP1-00641]

Immunohistochemistry: PDE9A Antibody [NBP1-00641] - PDE9A antibody was tested in mouse prostate using DAB with hematoxylin counterstain.

Applications for PDE9A Antibody - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:1000

Immunohistochemistry

1:400

Immunohistochemistry-Paraffin

1:400

Immunoprecipitation

1:1000

Western Blot

1:1000
Application Notes
In Western Blot, a band can be seen at ~68 kDa. In ICC/IF, cytoplasmic staining was observed in NIH-3T3 cells. The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Formulation, Preparation, and Storage

Purification

Immunogen affinity purified

Formulation

PBS and 30% Glycerol

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: PDE9A

Cyclic nucleotide phosphodiesterases (PDEs) are enzymes which catalyzes the hydrolysis of cyclic adenosine 30,50-monophosphate (cAMP) and/or cyclic guanosine 30,50-monophosphate (cGMP); and PDE9A (high affinity cGMP-specific 3',5'-cyclic phosphodiesterase 9A) is a PDE member which hydrolyzes the second messenger cGMP, an important regulator of several critical cellular physiological processes. PDE9A activity gets modulated by metal ions and it can bind 2 divalent metal cations per subunit - site 1 binds zinc ions, whereas, site 2 preferentially associates with magnesium and/or manganese ions. PDE9A is expressed in most of the solid tissues and because of its location as well as contribution to the regulation of steady-state cellular concentrations of cyclic nucleotides, PDE9A has been suggested as a potential candidate for diseases such as bipolar affective disorder and its overexpression has been linked to Down syndrome. Moreover, PDE9A deficient mice fed a high-fat diet have been reported to exhibit a reduced weight gain and fat mass compared with wild-type mice.

Long Name

High affinity cGMP-specific 3',5'-cyclic phosphodiesterase 9A

Alternate Names

CGMP-specific 3'-5'-cyclic phosphodiesterase type 9, CGMP-specific 3'-5'-cyclic phosphodiesterase type 9, EC 3.1.4.1710phosphodiesterase PDE9A21, EC 3.1.4.35, FLJ90181, high affinity cGMP-specific 3'-5'-cyclic phosphodiesterase 9A, HSPDE9A2, phosphodiesterase 9A

Entrez Gene IDs

5152 (Human); 18585 (Mouse); 191569 (Rat)

Gene Symbol

PDE9A

Additional PDE9A Products

Product Documents for PDE9A Antibody - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for PDE9A Antibody - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for PDE9A Antibody - BSA Free

Customer Reviews for PDE9A Antibody - BSA Free

There are currently no reviews for this product. Be the first to review PDE9A Antibody - BSA Free and earn rewards!

Have you used PDE9A Antibody - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for PDE9A Antibody - BSA Free (NBP1-00641):

PDE9A Antibody:
Immunocytochemistry Protocol

Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.

1. Remove culture medium and add 10% formalin to the dish. Fix at room temperature for 30 minutes.
2. Remove the formalin and add ice cold methanol. Incubate for 5-10 minutes.
3. Remove methanol and add washing solution (i.e. PBS). Be sure to not let the specimen dry out. Wash three times for 10 minutes.
4. To block nonspecific antibody binding incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
5. Add primary antibody at appropriate dilution and incubate at room temperature from 2 hours to overnight at room temperature.
6. Remove primary antibody and replace with washing solution. Wash three times for 10 minutes.
7. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
8. Remove antibody and replace with wash solution, then wash for 10 minutes. Add Hoechst 33258 to wash solution at 1:25,0000 and incubate for 10 minutes. Wash a third time for 10 minutes.
9. Cells can be viewed directly after washing. The plates can also be stored in PBS containing Azide covered in Parafilm (TM). Cells can also be cover-slipped using Fluoromount, with appropriate sealing.

*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.

PDE9A Antibody:
Immunohistochemistry-Paraffin Embedded Sections Protocol

Antigen Unmasking:
Bring slides to a boil in 10 mM sodium citrate buffer (pH 6.0) then maintain at a sub-boiling temperature for 10 minutes. Cool slides on bench-top for 30 minutes.

Staining:
1. Wash sections in deionized water three times for 5 minutes each.
2. Wash sections in wash buffer for 5 minutes.
3. Block each section with 100-400 ul blocking solution for 1 hour at room temperature.
4. Remove blocking solution and add 100-400 ul diluted primary antibody. Incubate overnight at 4 C.
5. Remove antibody solution and wash sections in wash buffer three times for 5 minutes each.
6. Add 100-400 ul biotinylated diluted secondary antibody. Incubate 30 minutes at room temperature.
7. Remove secondary antibody solution and wash sections three times with wash buffer for 5 minutes each.
8. Add 100-400 ul Streptavidin-HRP reagent to each section and incubate for 30 minutes at room temperature.
9. Wash sections three times in wash buffer for 5 minutes each.
10. Add 100-400 ul DAB substrate to each section and monitor staining closely.
11. As soon as the sections develop, immerse slides in deionized water.
12. Counterstain sections in hematoxylin.
13. Wash sections in deionized water two times for 5 minutes each.
14. Dehydrate sections.
15. Mount coverslips.

*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.

PDE9A Antibody:
Western Blot Protocol

1. Perform SDS-PAGE on samples to be analyzed, loading 40 ug of total protein per lane.
2. Transfer proteins to membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain according to standard Ponceau S procedure (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot.
5. Block the membrane using standard blocking buffer for at least 1 hour.
6. Wash the membrane in wash buffer three times for 10 minutes each.
7. Dilute primary antibody in blocking buffer and incubate 1 hour at room temperature.
8. Wash the membrane in wash buffer three times for 10 minutes each.
9. Apply the diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturers instructions) and incubate 1 hour at room temperature.
10. Wash the blot in wash buffer three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
Note: Tween-20 can be added to the blocking or antibody dilution buffer at a final concentration of 0.05-0.2%.

*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.
