Key Product Details

Species Reactivity

Validated:

Human, Mouse, Porcine, Primate

Cited:

Human, Mouse, Porcine

Applications

Validated:

Western Blot, Immunocytochemistry/ Immunofluorescence

Cited:

Western Blot, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Polyclonal Rabbit IgG

Format

BSA Free
Loading...

Product Specifications

Immunogen

A synthetic peptide made to a region within the C-terminus (within residues 350-435) of the human TIP47 protein. [Swiss-Prot# O60664]

Localization

Cytoplasm. Endosome. Membrane associated on endosomes. Detected in the envelope and the core of lipid bodies and in lipid sails.

Clonality

Polyclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for Perilipin-3/TIP47 Antibody - BSA Free

Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764] - A431 cells were fixed in 4% paraformaldehyde for 10 minutes and permeabilized in 0.05% Triton X-100 in PBS for 5 minutes. The cells were incubated with Perilipin-3/TIP47 Antibody (NB110-40764) at 2ug/ml overnight at 4C and detected with an anti-rabbit DyLight 488 (Green) at a 1:1000 dilution for 60 minutes. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 100X objective and digitally deconvolved.
Western Blot: Perilipin-3/TIP47 Antibody [NB110-40764]

Western Blot: Perilipin-3/TIP47 Antibody [NB110-40764]

Western Blot: Perilipin-3/TIP47 Antibody [NB110-40764] - Detection of TIP47 in 3T3 L1 lysate.
Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764] - A431 cells were fixed in 4% paraformaldehyde for 10 minutes and permeabilized in 0.05% Triton X-100 in PBS for 5 minutes. The cells were incubated with Perilipin-3/TIP47 Antibody conjugated to DyLight 550 (NB110-40764R) at 5 ug/ml for 1 hour at room temperature. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 100X objective and digitally deconvolved.
Western Blot: Perilipin-3/TIP47 Antibody [NB110-40764]

Western Blot: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/ Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764]

Immunocytochemistry/Immunofluorescence: Perilipin-3/TIP47 Antibody [NB110-40764] - TIP47 antibody was tested in U2OS cells with Dylight 488 (green). Nuclei and alpha-tubulin were counterstained with DAPI (blue) and Dylight 549 (red).

Applications for Perilipin-3/TIP47 Antibody - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:100

Western Blot

2 ug/ml
Application Notes
This TIP47 antibody is useful for Western Blot and Immunocytochemistry/Immunofluorescence. In Western Blot analysis, a band is seen at ~47 kDa, representing isoform B in both human (faint) and mouse lysates. In some samples, a ~28 kDa band may be observed which represents a splice isoform. In ICC/IF, endosomal staining was observed in U2OS cells.

Formulation, Preparation, and Storage

Purification

Immunogen affinity purified

Formulation

PBS

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

1.00 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Aliquot and store at -20C or -80C. Avoid freeze-thaw cycles.

Background: Perilipin-3

TIP47 (tail-interacting protein 47) is a member of PAT family of proteins (perilipin, ADRP, S3-12 and OXPAT) which plays a key role in the packaging/storage of neutral lipids and is required for mannose 6-phosphate receptors (M6PR) transport from endosomes to trans-Golgi network (TGN). TIP47 localizes in cytoplasm, endosome membrane as peripheral membrane protein towards cytoplasmic side, core of lipid bodies/ lipid droplet, in lipid sails and in the envelope, and it interacts with M6PR, IGF2R etc. via the cytoplasmic domain. As a cargo protein, TIP47 facilitates the delivery of M6PR from endosomes to TGN where it binds to cytoplasmic domains of cation-independent/-dependent M6PR and translocates to late endosomes by binding to Rab9 GTPase. Like other PAT family members, TIP47 associates with lipid droplets and influence insulin signaling as evidenced by combined knockout of ADRP /TIP47 leading to decreased insulin sensitivity. During HIV-1 infection, TIP47 acts as a cellular cofactor playing a part in Env incorporation, allowing the encounter and physical association between HIV-1 Gag and Env proteins during viral assembly process. TIP47 is identical to pregnancy-related placental tissue protein 17b (PP17b) and is overexpressed in cervical carcinoma patients wherein it is considered a serum tumor marker.

Alternate Names

M6PRBP1, Perilipin3, PLIN3, PP17, TIP47

Gene Symbol

PLIN3

Additional Perilipin-3 Products

Product Documents for Perilipin-3/TIP47 Antibody - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for Perilipin-3/TIP47 Antibody - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Related Research Areas

Citations for Perilipin-3/TIP47 Antibody - BSA Free

Customer Reviews for Perilipin-3/TIP47 Antibody - BSA Free

There are currently no reviews for this product. Be the first to review Perilipin-3/TIP47 Antibody - BSA Free and earn rewards!

Have you used Perilipin-3/TIP47 Antibody - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for Perilipin-3/TIP47 Antibody - BSA Free (NB110-40764):

Immunocytochemistry Protocol

Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.

1. Remove culture medium and wash the cells briefly in PBS. Add 10% formalin to the dish and fix at room temperature for 10 minutes.
2. Remove the formalin and wash the cells in PBS.
3. Permeablize the cells with 0.1% Triton X100 or other suitable detergent for 10 min.
4. Remove the permeablization buffer and wash three times for 10 minutes each in PBS. Be sure to not let the specimen dry out.
5. To block nonspecific antibody binding, incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
6. Add primary antibody at appropriate dilution and incubate overnight at 4C.
7. Remove primary antibody and replace with PBS. Wash three times for 10 minutes each.
8. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
9. Remove secondary antibody and replace with PBS. Wash three times for 10 minutes each.
10. Counter stain DNA with DAPi if required.

Immunohistochemistry-Paraffin Embedded Sections

Antigen Unmasking:
Bring slides to a boil in 10 mM sodium citrate buffer (pH 6.0) then maintain at a sub-boiling temperature for 10 minutes. Cool slides on bench-top for 30 minutes (keep slides in the sodium citrate buffer at all times).

Staining:
1. Wash sections in deionized water three times for 5 minutes each.
2. Wash sections in PBS for 5 minutes.
3. Block each section with 100-400 ul blocking solution (1% BSA in PBS) for 1 hour at room temperature.
4. Remove blocking solution and add 100-400 ul diluted primary antibody. Incubate overnight at 4 C.
5. Remove antibody solution and wash sections in wash buffer three times for 5 minutes each.
6. Add 100-400 ul HRP polymer conjugated secondary antibody. Incubate 30 minutes at room temperature.
7. Wash sections three times in wash buffer for 5 minutes each.
8. Add 100-400 ul DAB substrate to each section and monitor staining closely.
9. As soon as the sections develop, immerse slides in deionized water.
10. Counterstain sections in hematoxylin.
11. Wash sections in deionized water two times for 5 minutes each.
12. Dehydrate sections.
13. Mount coverslips.


Western Blot Protocol

1. Perform SDS-PAGE on samples to be analyzed, loading 10-25 ug of total protein per lane.
2. Transfer proteins to PVDF membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain the membrane with Ponceau S (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot TBS -0.05% Tween 20 (TBST).
5. Block the membrane in 5% Non-fat milk in TBST (blocking buffer) for at least 1 hour.
6. Wash the membrane in TBST three times for 10 minutes each.
7. Dilute primary antibody in blocking buffer and incubate overnight at 4C with gentle rocking.
8. Wash the membrane in TBST three times for 10 minutes each.
9. Incubate the membrane in diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) for 1 hour at room temperature.
10. Wash the blot in TBST three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturer's instructions.
