Recombinant Human Sonic Hedgehog/Shh, N-Terminus Protein

A New rhShh is Available! C-term cholesterol, N-term fatty acid-modified; 250-fold activity!
New Product 8908-SH.
(7 citations)
  • Purity
    >97%, by SDS-PAGE with silver staining, under reducing conditions
  • Endotoxin Level
    <0.10 EU per 1 μg of the protein by the LAL method.
  • Activity
    Measured by its ability to induce alkaline phosphatase production by C3H10T1/2 mouse embryonic fibroblast cells. Nakamura, T. et al. (1997) Biochem. Biophys. Res. Commun. 237:465. The ED50 for this effect is <5 µg/mL.
  • Source
    E. coli-derived Cys24-Gly197, with a C-terminal 6-His tag
  • Accession #
  • N-terminal Sequence
    Analysis
    Cys24
  • Predicted Molecular Mass
    20 kDa
  • SDS-PAGE
    22 kDa, reducing conditions
Carrier Free
What does CF mean?
CF stands for Carrier Free (CF). We typically add Bovine Serum Albumin (BSA) as a carrier protein to our recombinant proteins. Adding a carrier protein enhances protein stability, increases shelf-life, and allows the recombinant protein to be stored at a more dilute concentration. The carrier free version does not contain BSA.
What formulation is right for me?
In general, we advise purchasing the recombinant protein with BSA for use in cell or tissue culture, or as an ELISA standard. In contrast, the carrier free protein is recommended for applications, in which the presence of BSA could interfere.
1314-SH

1314-SH/CF
Formulation Lyophilized from a 0.2 μm filtered solution in NaH2PO4, NaCl and DTT with BSA as a carrier protein.
Formulation Lyophilized from a 0.2 μm filtered solution in NaH2PO4, NaCl and DTT.
Reconstitution Reconstitute at 100 μg/mL in sterile PBS containing at least 0.1% human or bovine serum albumin.
Reconstitution Reconstitute at 100 μg/mL in PBS.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Shipping The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Stability & Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Data Images
Recombinant Human Sonic Hedgehog/Shh, N-Terminus (Catalog # 1314-SH) induces alkaline phosphatase production by the C3H10T1/2 mouse embryonic fibroblast cell line. The ED50 for this effect is 5 μg/mL.
1 μg/lane of Recombinant Human Sonic Hedgehog/Shh, N-Terminus was resolved with SDS-PAGE under reducing (R) conditions and visualized by silver staining, showing a single band at 22 kDa.
Background: Sonic Hedgehog/Shh
Sonic Hedgehog (Shh) is expressed in embryonic tissues that are critical for the patterning of the developing central nervous system, somite, and limb. It is also involved in whisker, hair, foregut, tooth, and bone development. Shh regulates neural and hematopoietic stem cell fate and is important for thymocyte differentiation and proliferation as well as T cell determination. In adult tissue Shh is associated with cancer development and tissue remodeling following injury (1-3). Human Shh encodes a 462 amino acid (aa) precursor protein that is autocatalytically processed to yield a non-glycosylated 19 kDa N-terminal fragment (Shh-N) and a glycosylated 25 kDa C-terminal protein (Shh-C) (4). Shh-C, which is responsible for the intramolecular processing of Shh, is rapidly degraded following Shh proteolysis (5). Shh-N is highly conserved, sharing >98% aa identity between mouse, human, rat, canine, porcine, and chicken Shh-N. Shh-N can be palmitoylated at its
N-terminal cysteine and modified by cholesterol addition at its C-terminus (6). These modifications contribute to the membrane tethering of Shh as well as its assembly into various sized multimers (6-9). Lipid modification and multimerization greatly increase Shh-N receptor binding affinity and signaling potency (5, 6, 8, 9). Monomeric and multimeric Shh can be released from the plasma membrane by the cooperative action of DISP1, SCUBE2, and TACE/ADAM17 (10-12). Modifications also extend the effective range of Shh functionality and are required for the development of protein gradients important in tissue morphogenesis (9, 13). Canonical signaling of Shh is mediated by a multicomponent receptor complex that includes Patched (PTCH1, PTCH2) and Smoothened (SMO) (14). The binding of Shh to PTCH releases the basal repression of SMO by PTCH. Shh activity can also be regulated through interactions with heparin, glypicans, and membrane-associated Hip (hedgehog interacting protein) (13, 15, 16).
  • References:
    1. Briscoe, J. and P.P. Therond (2013) Mol. Cell. Biol. 14:416.
    2. Aviles, E.C. et al. (2013) Front. Cell. Neurosci. 7:86.
    3. Xie, J. et al. (2013) OncoTargets Ther. 6:1425.
    4. Marigo, V. et al. (1995) Genomics 28:44.
    5. Zeng, X. et al. (2001) Nature 411:716.
    6. Feng, J. et al. (2004) Development 131:4357.
    7. Goetz, J.A. et al. (2006) J. Biol. Chem. 281:4087.
    8. Pepinsky, R.B. et al. (1998) J. Biol. Chem. 273:14037.
    9. Chen, M.-H. et al. (2004) Genes Dev. 18:641.
    10. Etheridge, L.A. et al. (2010) Development 137:133.
    11. Jakobs, P. et al. (2014) J. Cell Sci. 127:1726.
    12. Dierker, T. et al. (2009) J. Biol. Chem. 284:8013.
    13. Lewis, P.M. et al. (2001) Cell 105:599.
    14. Carpenter, D. et al. (1998) Proc. Natl. Acad. Sci. USA 95:13630.
    15. Filmus, J. and M. Capurro (2014) Matrix Biol. 35:248.
    16. Chuang, P.-T. and A.P. McMahon (1999) Nature 397:617.
  • Entrez Gene IDs:
    6469 (Human); 20423 (Mouse)
  • Alternate Names:
    HHG1; HHG-1; HLP3; HPE3; MCOPCB5sonic hedgehog (Drosophila) homolog; Shh; SMMCIsonic hedgehog homolog (Drosophila); sonic hedgehog homolog; sonic hedgehog protein; Sonic Hedgehog; TPT; TPTPS
Related Research Areas
Citations:

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

7 Citations: Showing 1 - 7
Filter your results:

Species
Applications
Sample Type
  1. Inhibition of the Hedgehog pathway induces autophagy in pancreatic ductal adenocarcinoma cells.
    Authors: Xu Y, An Y, Wang X, Zha W, Li X
    Oncol Rep, 2014;31(2):707-12.
    Species: Human
    Sample Type: Whole Cells
    Application: Bioassay
  2. The hedgehog system in ovarian follicles of cattle selected for twin ovulations and births: evidence of a link between the IGF and hedgehog systems.
    Authors: Aad, Pauline, Echternkamp, Sherrill, Sypherd, David D, Schreiber, Nicole B, Spicer, Leon J
    Biol Reprod, 2012;87(4):79.
    Species: Bovine
    Sample Type: Whole Cells
    Application: Bioassay
  3. Derivation of cerebellar neurons from human pluripotent stem cells.
    Authors: Erceg S, Lukovic D, Moreno-Manzano V, Stojkovic M, Bhattacharya S
    Curr Protoc Stem Cell Biol, 2012;20(0):1H.51.
    Species: Human
    Sample Type: Whole Cells
    Application: Bioassay
  4. Vitronectin promotes oligodendrocyte differentiation during neurogenesis of human embryonic stem cells.
    Authors: Gil JE, Woo DH, Shim JH, Kim SE, You HJ, Park SH, Paek SH, Kim SK, Kim JH
    FEBS Lett., 2009;583(3):561-7.
    Species: Human
    Sample Type: Whole Cells
    Application: Bioassay
  5. Human ES cell-derived neural rosettes reveal a functionally distinct early neural stem cell stage.
    Authors: Elkabetz Y, Panagiotakos G, Al Shamy G, Socci ND, Tabar V, Studer L
    Genes Dev., 2008;22(2):152-65.
    Species: Human
    Sample Type: Whole Cells
    Application: Bioassay
  6. Reduced pepsin A processing of sonic hedgehog in parietal cells precedes gastric atrophy and transformation.
    Authors: Zavros Y, Waghray M, Tessier A, Bai L, Todisco A, L Gumucio D, Samuelson LC, Dlugosz A, Merchant JL
    J. Biol. Chem., 2007;282(46):33265-74.
    Species: N/A
    Sample Type: N/A
    Application: SDS-page
  7. An early role for WNT signaling in specifying neural patterns of Cdx and Hox gene expression and motor neuron subtype identity.
    Authors: Nordstrom U, Maier E, Jessell TM, Edlund T
    PLoS Biol., 2006;4(8):e252.
    Species: Chicken
    Sample Type: Whole Tissue
    Application: Bioassay
Primary Antibodies
Description Application Cat# Citations Images

His Tag Antibody

WB, Simple Western, Flow, AP, CyTOF-ready MAB050 26
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag HRP-conjugated Antibody

WB, Simple Western MAB050H 3
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag APC-conjugated Antibody

ICFlow IC050A
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag Biotinylated Antibody

WB BAM050 4
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag PE-conjugated Antibody

ICFlow IC050P 2
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag Antibody

WB, Flow, AP MAB050R
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag Alexa Fluor® 488-conjugated Antibody

ICFlow IC050G
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag PerCP-conjugated Antibody

ICFlow IC050C
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

His Tag Alexa Fluor® 700-conjugated Antibody

ICFlow IC050N
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....
Protein Purification Kits
Description Application Cat# Citations Images

Histidine-tagged Protein Purification Resin

IP999 1
View Sizes & Prices
Catalog# Size Price Stock Quantity
Loading Information....

Have you used Recombinant Human Sonic Hedgehog/Shh, N-Terminus Protein?

Submit a review and receive a $25US/€18/£15/$25CAN amazon gift card if you include an image - $10US/€7/£6/$10CAN Amazon card for reviews without an image. Limited to verified customers in USA, Canada and Europe.

FAQs

  1. What is the difference between Recombinant Human Sonic Hedgehog Catalog # 1845-SH and Catalog # 1314-SH?

    • Recombinant Human Sonic Hedgehog, Catalog # 1845-SH, possesses a N-terminal mutation that increases its potency in bioassay tests. The amino acid sequence is Cys24-Gly197 (Cys24Ile-Ile), accession number NP_000184. The Cys24Ile-Ile mutation was created to match a publication that describes enhanced activity with these modifications: "http://www.ncbi.nlm.nih.gov/pubmed/11284692". Catalog # 1314-SH does not possess this mutation.
