Key Product Details

Species Reactivity

Human, Mouse

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Polyclonal Rabbit IgG

Format

BSA Free
Loading...

Product Specifications

Immunogen

Synthetic peptide made to an N-terminal portion of human TMEM49 (between amino acids 1-75) [UniProt Q96GC9]

Clonality

Polyclonal

Host

Rabbit

Isotype

IgG

Description

Novus Biologicals Rabbit TMEM49 Antibody - BSA Free (NBP2-78784) is a polyclonal antibody validated for use in IHC, WB and ICC/IF. All Novus Biologicals antibodies are covered by our 100% guarantee.

Scientific Data Images for TMEM49 Antibody - BSA Free

Western Blot: TMEM49 AntibodyBSA Free [NBP2-78784]

Western Blot: TMEM49 AntibodyBSA Free [NBP2-78784]

Western Blot: TMEM49 Antibody [NBP2-78784] - Total protein from human U2OS, HeLa, MCF7 and mouse 3T3 cell lines was separated on a 12% gel by SDS-PAGE, transferred to PVDF membrane and blocked in 5% non-fat milk in TBST. The membrane was probed with 2.0 ug/ml anti-TMEM49 in block buffer and detected with an anti-rabbit HRP secondary antibody using West Pico PLUS chemiluminescence detection reagent.
Immunocytochemistry/ Immunofluorescence: TMEM49 Antibody - BSA Free [NBP2-78784]

Immunocytochemistry/ Immunofluorescence: TMEM49 Antibody - BSA Free [NBP2-78784]

Immunocytochemistry/Immunofluorescence: TMEM49 Antibody [NBP2-78784] - HeLa cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X PBS + 0.05% Triton-X100. The cells were incubated with anti-TMEM49 at 10 ug/ml overnight at 4C and detected with an anti-rabbit Dylight 488 (Green) at a 1:500 dilution. Alpha tubulin (DM1A) NB100-690 was used as a co-stain at a 1:1000 dilution and detected with an anti-mouse Dylight 550 (Red) at a 1:500 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.
Immunohistochemistry-Paraffin: TMEM49 Antibody - BSA Free [NBP2-78784]

Immunohistochemistry-Paraffin: TMEM49 Antibody - BSA Free [NBP2-78784]

Immunohistochemistry-Paraffin: TMEM49 Antibody [NBP2-78784] - Analysis of a FFPE tissue section of the human testis using 1:200 dilution of TMEM49 antibody (NBP2-78784). The signal was developed using HRP-DAB method which followed counterstaining of the cells with hematoxylin. The antibody generated mainly strong cytoplasmic staining in cytoplasm and membrane in seminiferous tubules.

Applications for TMEM49 Antibody - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

10 - 20 ug/ml

Immunohistochemistry

1:200 - 1:500

Immunohistochemistry-Paraffin

1:200 - 1:500

Western Blot

1 - 5 ug/ml

Formulation, Preparation, and Storage

Purification

Immunogen affinity purified

Formulation

PBS

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

0.7 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C for up to 3 months. For longer storage, aliquot and store at -20C.

Background: TMEM49

Transmembrane protein 49 (TMEM49), also known as vacuole membrane protein 1 (VMP1), is an endoplasmic reticulum (ER)-localized protein that plays an important role in autophagy and, specifically, autophagosome formation (1). TMEM49/VMP1 is synthesized as 406 amino acid (aa) transmembrane protein containing a VTT (VMP1-TMEM41b-TVP38) domain and with a theoretical molecular weight of 46 kDa (1,2). TMEM49 helps regulate ER contacts with membranes such as isolation membranes, mitochondria, endosomes, and lipid droplets (1). TMEM49/VMP1 deficiency leads to tighter ER contacts and, in the context of autophagy, results in failure of the autophagosome and lysosome to fuse and eventual disruption of autophagic flux (1).

TMEM49/VMP1 was first implicated in pancreatitis and its overexpression, together with KRAS oncogene activation, leads to development of pancreatic ductal adenocarcinoma (PDAC) (3). Aside from pancreatitis, TMEM49/VMP1 is also associated with a number of other pathologies including cancer, inflammatory bowel disease, and, potentially, neurodegenerative disorders such as Parkinson's Disease (PD) and Alzheimer's Disease (AD) (1). It is suggested that TMEM49/VMP1 deficiency in neurons results in disrupted autophagy and protein aggregation, increased ER-membrane contacts, and dysfunctional mitochondrial homeostasis, all of which contribute to neurodegeneration (1).

References

1. Wang, P., Kou, D., & Le, W. (2020). Roles of VMP1 in Autophagy and ER-Membrane Contact: Potential Implications in Neurodegenerative Disorders. Frontiers in molecular neuroscience, 13, 42. https://doi.org/10.3389/fnmol.2020.00042

2. Uniprot (Q96GC9)

3. Iovanna J. L. (2016). Autophagy Induced during Pancreatitis Promotes KRAS-Dependent Transformation in the Pancreas. Frontiers in oncology, 6, 226. https://doi.org/10.3389/fonc.2016.00226

Alternate Names

DKFZp566I133, EPG3, TDC1, transmembrane protein 49TMEM49, vacuole membrane protein 1

Gene Symbol

VMP1

Additional TMEM49 Products

Product Documents for TMEM49 Antibody - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for TMEM49 Antibody - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Customer Reviews for TMEM49 Antibody - BSA Free

There are currently no reviews for this product. Be the first to review TMEM49 Antibody - BSA Free and earn rewards!

Have you used TMEM49 Antibody - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for TMEM49 Antibody - BSA Free (NBP2-78784):

TMEM49 Antibody:
Immunocytochemistry Protocol

Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.

1. Remove culture medium and wash the cells briefly in PBS. Add 10% formalin to the dish and fix at room temperature for 10 minutes.
2. Remove the formalin and wash the cells in PBS.
3. Permeablize the cells with 0.1% Triton X100 or other suitable detergent for 10 min.
4. Remove the permeablization buffer and wash three times for 10 minutes each in PBS. Be sure to not let the specimen dry out.
5. To block nonspecific antibody binding, incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
6. Add primary antibody at appropriate dilution and incubate overnight at 4C.
7. Remove primary antibody and replace with PBS. Wash three times for 10 minutes each.
8. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
9. Remove secondary antibody and replace with PBS. Wash three times for 10 minutes each.
10. Counter stain DNA with DAPi if required.

TMEM49 Antibody:
Immunohistochemistry-Paraffin Embedded Sections

Antigen Unmasking:
Bring slides to a boil in 10 mM sodium citrate buffer (pH 6.0) then maintain at a sub-boiling temperature for 10 minutes. Cool slides on bench-top for 30 minutes.

Staining:
1. Wash sections in deionized water three times for 5 minutes each.
2. Wash sections in wash buffer for 5 minutes.
3. Block each section with 100-400 ul blocking solution for 1 hour at room temperature.
4. Remove blocking solution and add 100-400 ul diluted primary antibody. Incubate overnight at 4 C.
5. Remove antibody solution and wash sections in wash buffer three times for 5 minutes each.
6. Add 100-400 ul biotinylated diluted secondary antibody. Incubate 30 minutes at room temperature.
7. Remove secondary antibody solution and wash sections three times with wash buffer for 5 minutes each.
8. Add 100-400 ul Streptavidin-HRP reagent to each section and incubate for 30 minutes at room temperature.
9. Wash sections three times in wash buffer for 5 minutes each.
10. Add 100-400 ul DAB substrate to each section and monitor staining closely.
11. As soon as the sections develop, immerse slides in deionized water.
12. Counterstain sections in hematoxylin.
13. Wash sections in deionized water two times for 5 minutes each.
14. Dehydrate sections.
15. Mount coverslips.


TMEM49 Antibody:
Western Blot Protocol

1. Perform SDS-PAGE on samples to be analyzed, loading 10-25 ug of total protein per lane.
2. Transfer proteins to PVDF membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain the membrane with Ponceau S (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot TBS -0.05% Tween 20 (TBST).
5. Block the membrane in 5% Non-fat milk in TBST (blocking buffer) for at least 1 hour.
6. Wash the membrane in TBST three times for 10 minutes each.
7. Dilute anti-TMEM49 primary antibody in blocking buffer and incubate overnight at 4C with gentle rocking.
8. Wash the membrane in TBST three times for 10 minutes each.
9. Incubate the membrane in diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) for 1 hour at room temperature.
10. Wash the blot in TBST three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs

No product specific FAQs exist for this product.
