Actin Gamma 1 Antibody - BSA Free
Novus Biologicals | Catalog # NB600-533
Key Product Details
Validated by
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Format
Product Specifications
Immunogen
Reactivity Notes
Clonality
Host
Isotype
Theoretical MW
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for Actin Gamma 1 Antibody - BSA Free
Immunocytochemistry/ Immunofluorescence: Actin Gamma 1 Antibody [NB600-533]
Immunocytochemistry/Immunofluorescence: Actin Gamma 1 Antibody [NB600-533] - Detection of Actin Gamma 1 (Green) in Hela cells using NB600-533 at a 1:50 dilution. Nuclei (Blue) were counterstained using Hoechst 33258.Immunohistochemistry: Actin Gamma 1 Antibody [NB600-533]
Immunohistochemistry: Actin Gamma 1 Antibody [NB600-533] - Sample: FFPE section of human testicular seminoma. Antibody: Affinity purified rabbit anti-Actin used at a dilution of 1:1,000 (1ug/ml). Detection: DABWestern Blot: Actin Gamma 1 Antibody [NB600-533]
Western Blot: Actin Gamma 1 Antibody [NB600-533] - Whole cell lysate from HeLa (1, 2.5, 5, 15 and 50 ug) and mouse NIH3T3 cells (50 ug), probed with diluted at 0.04 ug/ml.Western Blot: Actin Gamma 1 Antibody [NB600-533]
Western Blot: Actin Gamma 1 Antibody [NB600-533] - Actin Antibody [NB600-533]-Detection of actin in 3T3 (20 ug) lysates. ECL detection 30 seconds. Lane 1 - 1:5,000 dilution Lane 2 - 1:10,000 dilution Lane 3 - 1:15,000 dilutionWestern Blot: Actin Gamma 1 Antibody [NB600-533]
Western Blot: Actin Gamma 1 Antibody [NB600-533] - Detection of human and mouse Cytoskeletal Actin by western blot. Samples: Whole cell lysate (15 ug) from HeLa, HEK293T, Jurkat, mouse TCMK-1, and mouse NIH 3T3 cells prepared using NETN lysis buffer. Antibody: Affinity purified rabbit anti-Cytoskeletal Actin antibody NB600-533 used for WB at 0.1 ug/ml. Detection: Chemiluminescence with an exposure time of 10 seconds.Simple Western: Actin Gamma 1 Antibody [NB600-533]
Simple Western: Actin Gamma 1 Antibody [NB600-533] - Simple Western lane view shows a specific band for Actin Gamma 1 in 1.0 mg/ml of HeLa lysate. This experiment was performed under reducing conditions using the 12-230kDa separation system.Western Blot: Actin Gamma 1 Antibody [NB600-533] -
Western Blot: Actin Gamma 1 Antibody [NB600-533] - Validation of RNA-seq data by qRT-PCR & Western blot analyses. a The relative mRNA level of DLK & axon guidance genes in infected cells was analyzed by qRT-PCR, normalized to three housekeeping genes & calculated with the delta delta CT method. The value of mRNA expression for each gene in control cells (pLKO.1) was arbitrarily set to 1. Data are the mean ± SEM (error bars) from three independent experiments carried out in triplicate. *, p < 0.05; **, p < 0.01; ***, p < 0.001; ****, p < 0.0001; ns, p > 0.05. b Representative Western blots showing levels of DLK, Plxna4, Nrp1 & actin in control & DLK-depleted Neuro-2a cells. c Quantitative densitometric measurements of DLK, Plxna4 & Nrp1 protein levels in infected cells. Results are normalized to actin level in control cells, which were set to 1, & represent mean ± SEM (error bars) from three independent experiments. *, p < 0.05; **, p < 0.01; ***, p < 0.001 Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/27468987), licensed under a CC-BY license. Not internally tested by Novus Biologicals.Applications for Actin Gamma 1 Antibody - BSA Free
Immunocytochemistry/ Immunofluorescence
Immunoprecipitation
Simple Western
In Simple Western only 10 - 15 uL of the recommended dilution is used per data point.
See Simple Western Antibody Database for Simple Western validation: Tested in HeLa lysate 1.0 mg/mL, separated by Size, antibody dilution of 1:100, apparent MW was 49 kDa. Separated by Size-Wes, Sally Sue/Peggy Sue.
The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.Use in FLOW reported in scientific literature (PMID 28501006).
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Formulation
Format
Preservative
Concentration
Shipping
Stability & Storage
Background: Actin Gamma 1
Actin Gamma 1 antibodies serve as excellent loading controls, due to the proteins' near ubiquitous expressn and strong conservation across most species. In vertebrates 3 main groups of actin isoforms, alpha, beta and gamma have been identified. The alpha actins are found in muscle tissues and are a major constituent of the contractile apparatus. The beta and gamma actins coexist in most cell types as components of the cyto-skeleton and as mediators of internal cell motility. Beta actins are highly conserved proteins that are involved in cell motility, structure and integrity. Beta actins are cytoplasmic proteins ubiquitously expressed in all eukaryotic cells. Polymerization of globular actin (G-actin) leads to a structural filament (F-actin) in the form of a two-stranded helix. Each actin can bind to 4 others. Actin Gamma 1 antibody serves as an excellent loading control.
Alternate Names
Gene Symbol
UniProt
Additional Actin Gamma 1 Products
Product Documents for Actin Gamma 1 Antibody - BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for Actin Gamma 1 Antibody - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Citations for Actin Gamma 1 Antibody - BSA Free
Customer Reviews for Actin Gamma 1 Antibody - BSA Free
There are currently no reviews for this product. Be the first to review Actin Gamma 1 Antibody - BSA Free and earn rewards!
Have you used Actin Gamma 1 Antibody - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
Protocols
View specific protocols for Actin Gamma 1 Antibody - BSA Free (NB600-533):
Western Blot Protocol
1. Perform SDS-PAGE (4-12%) on samples to be analyzed, loading 20 ug of total protein per lane.
2. Transfer proteins to Nitrocellulose according to the instructions provided by the manufacturer of the transfer apparatus.
3. Stain the blot using ponceau S for 1-2 minutes to access the transfer of proteins onto the nitrocellulose membrane. Rinse the blot in water to remove excess stain and mark the lane locations and locations of molecular weight markers using a pencil.
4. Rinse the blot in TBS for approximately 5 minutes.
5. Block the membrane using 5% non-fat dry milk + 1% BSA in TBS for 1 hour.
6. Dilute the rabbit anti-actin primary antibody (NB 600-533) in blocking buffer and incubate 2 hours at room temperature.
7. Wash the membrane in water for 5 minutes and apply the diluted rabbit-IgG HRP-conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) and incubate 1 hour at room temperature.
8. Wash the blot in TBS containing 0.05-0.1% Tween-20 for 10-20 minutes.
9. Wash the blot in type I water for an additional 10-20 minutes (this step can be repeated as required to reduce background).
10. Apply the detection reagent of choice in accordance with the manufacturer's instructions (Amersham's ECL is the standard reagent used at Novus Biologicals).
Note: Tween-20 can be added to the blocking buffer at a final concentration of 0.05-0.2%, provided it does not interfere with antibody-antigen binding.
