Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free
Novus Biologicals | Catalog # NBP2-47816
Key Product Details
Species Reactivity
Human
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunofluorescence, Immunocytochemistry/ Immunofluorescence, Simple Western, CyTOF-ready
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG1 kappa Clone # h-CALD
Format
Azide and BSA Free
Loading...
Product Specifications
Immunogen
Crude human uterus extract
Localization
Cytoplasmic
Marker
Smooth Muscle Marker
Specificity
Recognizes a protein of 150kDa, which is identified as the high molecular weight variant of Caldesmon. Two closely related variants of human caldesmon have been identified which are different in their electrophoretic mobility and cellular distribution. The h-caldesmon variant (12080kDa) is found in non- muscle tissue and cells. Neither of the two variants has been detected in skeletal muscle. This monoclonal antibody recognizes only the 150kDa variant (h-caldesmon) in Western blots of human aortic media extracts and is unreactive with fibroblast extracts from cultivated human foreskin. Caldesmon is a developmentally regulated protein involved in smooth muscle and non-muscle contraction.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG1 kappa
Theoretical MW
150 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Description
1.0 mg/ml of antibody purified from Bioreactor Concentrate by Protein A/G. Prepared in 10mM PBS WITHOUT BSA & azide. Also available at 200 ug/ml WITH BSA & azide (NBP2-44421).
Antibody with azide - store at 2 to 8C. Antibody without azide - store at -20 to -80C.
Antibody with azide - store at 2 to 8C. Antibody without azide - store at -20 to -80C.
Scientific Data Images for Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free
![Western Blot: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]](https://resources.rndsystems.com/images/products/Caldesmon-CALD1-Antibody-h-CALD-Azide-and-BSA-Free-Western-Blot-NBP2-47816-img0004.jpg "Western Blot: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]")
Western Blot: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]
Western Blot: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816] - Western Blot Analysis of human Ovary tissue using Caldesmon/CALD1 antibody (h-CALD).![Immunohistochemistry-Paraffin: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816]](https://resources.rndsystems.com/images/products/Caldesmon-CALD1-Antibody-h-CALD-Azide-and-BSA-Free-Immunohistochemistry-Paraffin-NBP2-47816-img0003.jpg "Immunohistochemistry-Paraffin: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816]")
Immunohistochemistry-Paraffin: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816]
Immunohistochemistry-Paraffin: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816] - Human Uterus stained with Caldesmon Monoclonal Antibody (h-CALD).![Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]](https://resources.rndsystems.com/images/products/Caldesmon-CALD1-Antibody-h-CALD-Azide-and-BSA-Free-Simple-Western-NBP2-47816-img0001.jpg "Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]")
Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]
Simple Western: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816] - Electropherogram image of the corresponding Simple Western lane. Caldesmon/CALD1 antibody was used at 10 ug/ml dilution of h. Aorta and h. Uterus lysates(s) respectively.![Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]](https://resources.rndsystems.com/images/products/Caldesmon-CALD1-Antibody-h-CALD-Azide-and-BSA-Free-Simple-Western-NBP2-47816-img0002.jpg "Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]")
Simple Western: Caldesmon/CALD1 Antibody (h-CALD)Azide and BSA Free [NBP2-47816]
Simple Western: Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free [NBP2-47816] - Simple Western lane view shows a specific band for Caldesmon/CALD1 in 0.2 mg/ml of h. Aorta lysate(s). This experiment was performed under reducing conditions using the 12-230 kDa separation system.Applications for Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free
Application
Recommended Usage
Flow Cytometry
0.5 - 1 ug/million cells in 0.1 ml
Immunocytochemistry/ Immunofluorescence
1-2 ug/ml
Immunofluorescence
1 - 2 ug/ml
Immunohistochemistry-Paraffin
0.25 - 0.5 ug/ml
Simple Western
10 ug/ml
Western Blot
2-4 ug/ml
Application Notes
Immunohistochemistry (Formalin-fixed): 1-2ug/ml for 30 minutes at RT. Staining of formalin-fixed tissues requires heating tissue sections in 10mM Tris with 1mM EDTA, pH 9.0, for 45 min at 95C followed by cooling at RT for 20 minutes.
Optimal dilution for a specific application should be determined.
In Simple Western only 10 - 15 ul of the recommended dilution is used per data point.
See Simple Western Antibody Database for Simple Western validation: antibody dilution of 10 ug/mL
Optimal dilution for a specific application should be determined.
In Simple Western only 10 - 15 ul of the recommended dilution is used per data point.
See Simple Western Antibody Database for Simple Western validation: antibody dilution of 10 ug/mL
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Protein A or G purified
Formulation
10 mM PBS
Format
Azide and BSA Free
Preservative
No Preservative
Concentration
1.0 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20 to -80C. Avoid freeze-thaw cycles.
Background: Caldesmon/CALD1
Alternate Names
CALD1, CDM, HCAD, LCAD, NAG22
Gene Symbol
CALD1
Additional Caldesmon/CALD1 Products
Product Documents for Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for Caldesmon/CALD1 Antibody (h-CALD) - Azide and BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
