CD68/SR-D1 Antibody (3F7D3) - BSA Free

Novus Biologicals | Catalog # NBP2-37265

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Validated:

Human, Mouse

Cited:

Human, Mouse

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, ELISA, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, CyTOF-ready

Cited:

Western Blot, Immunocytochemistry/ Immunofluorescence, IF/IHC

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG1 Clone # 3F7D3

Format

BSA Free
View all CD68/SR-D1 Primary Antibodies »

Product Specifications

Immunogen

Purified recombinant fragment of human CD68/SR-D1 (AA: 42-155) expressed in E. Coli.

Reactivity Notes

Use in Mouse reported in scientific literature (PMID:35022438).

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1

Theoretical MW

37.4 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for CD68/SR-D1 Antibody (3F7D3) - BSA Free

Immunocytochemistry/ Immunofluorescence: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunocytochemistry/ Immunofluorescence: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunocytochemistry/Immunofluorescence: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Immunofluorescence analysis of Hela cells using CD68 mouse mAb (green). Blue: DRAQ5 fluorescent DNA dye.
Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Western blot analysis using CD68 mouse mAb against U937 (1), Hela (2), HepG2 (3), Jurkat (4) cell lysate.
Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Analysis of bladder cancer tissues using CD68 mouse mAb with DAB staining.
Flow Cytometry: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Flow Cytometry: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Flow Cytometry: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Flow cytometric analysis of Hela cells using CD68 mouse mAb (green) and negative control (red).
Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Western blot analysis using CD68 mAb against human CD68 (AA: 42-155) recombinant protein. (Expected MW is 37.4 kDa)
Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3)BSA Free [NBP2-37265]

Western Blot: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Western blot analysis using CD68 mAb against HEK293 (1) and CD68 (AA: 42-155)-hIgGFc transfected HEK293 (2) cell lysate.
Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

Immunohistochemistry-Paraffin: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Analysis of endometrial cancer tissues using CD68 mouse mAb with DAB staining.
ELISA: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

ELISA: CD68/SR-D1 Antibody (3F7D3) - BSA Free [NBP2-37265]

ELISA: CD68/SR-D1 Antibody (3F7D3) [NBP2-37265] - Red: Control Antigen (100ng); Purple: Antigen (10ng); Green: Antigen (50ng); Blue: Antigen (100ng);

Applications for CD68/SR-D1 Antibody (3F7D3) - BSA Free

Application
Recommended Usage

ELISA

1:10000

Flow Cytometry

1:200 - 1:400

Immunocytochemistry/ Immunofluorescence

1:200 - 1:1000

Immunohistochemistry

1:200 - 1:1000

Western Blot

1:500 - 1:2000
Application Notes
This antibody is Cytof ready.

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: CD68/SR-D1

Human CD68, also known as GP110, LAMP4, Scavenger Receptor D1 (SR-D1) or macrosialin in mouse, encodes a 110-kD transmembrane glycoprotein that belongs to the lysosomal/endosomal-associated membrane glycoprotein (LAMP) family. Members of the LAMP family include LAMP-1, LAMP-2, dendritic cell (DC)-LAMP (aka CD208), and brain and dendritic cell-associated (BAD)-LAMP (aka LAMP-5). Unlike the two LAMP domains facing the lysosomal lumen in LAMP-1 and LAMP-2, CD68 has a single LAMP domain containing four cystines spaced 36-37 residues apart along with an N-terminal Mucin-like domain. The 354 amino acid (a.a.) human CD68 and 326 a.a. murine ortholog share 80.6% a.a. sequence identity (1).

CD68 is highly expressed in cells of the mononuclear phagocyte system such as macrophages, microglia, osteoclasts, and myeloid dendritic cells (DCs); and is expressed to a lesser extent in lymphoid cells (CD19+ B lymphocytes and CD4+ T lymphocytes), human umbilical cord mesenchymal stem cells (MSCs), fibroblasts, endothelial cells, multiple non-hematopoietic cancer cell lines, and human arterial intimal smooth muscle cells (SMCs). Expression has been also observed in diseased states for granulocytes and neutrophils, in particular basophils from myeloproliferative disorders and intestinal neutrophils from inflammatory bowel disease (IBD), respectively (1).

Although the function of CD68 has yet to be established, it has often been used as an immunohistochemistry (IHC) marker of inflammation and for granular cell tumors (GCTs). CD68+ tumor associated macrophages (TAMs) has been suggested to be a predictive marker for poor cancer prognosis, but a meta-analysis showed the presence of CD68 is not correlated with survival (2). In addition, a role in hepatic malaria infection has been reported based on the finding that peptide P39 binds CD68, considered a receptor for malaria sporozoite, and inhibits parasite entry into Kupffer cells. CD68 was deemed a member of the Scavenger receptor family due to its upregulation in macrophages following inflammatory stimuli, ability to bind modified LDL, phosphatidylserine, and apoptotic cells, as well as shuttling between the plasma membrane and endosomes. CD68 has been linked to atherogenesis based on binding and internalization of its ligand, oxLDL (1).

References

1. Chistiakov, DA, Killingsworth, MC, Myasoedova, VA. Orekhov AN, Bobryshev YV. (2017) CD68/macrosialin: not just a histochemical marker. Lab Invest. 97:4-13. PMID: 27869795

2. Troiano G, Caponio VCA, Adipietro I, Tepedino M, Santoro R, Laino L, Lo Russo L, Cirillo N, Lo Muzio L. (2019) Prognostic significance of CD68+ and CD163+ tumor associated macrophages in head and neck squamous cell carcinoma: A systematic review and meta-analysis. Oral Oncol. 93:66-75. PMID: 31109698.

Alternate Names

CD68, gp110, Macrosialin, SCARD1, SR-D1, SRD1

Gene Symbol

CD68

Additional CD68/SR-D1 Products

Product Documents for CD68/SR-D1 Antibody (3F7D3) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for CD68/SR-D1 Antibody (3F7D3) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for CD68/SR-D1 Antibody (3F7D3) - BSA Free

Customer Reviews for CD68/SR-D1 Antibody (3F7D3) - BSA Free

There are currently no reviews for this product. Be the first to review CD68/SR-D1 Antibody (3F7D3) - BSA Free and earn rewards!

Have you used CD68/SR-D1 Antibody (3F7D3) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs

No product specific FAQs exist for this product.

View all FAQs for Antibodies
