Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free
Novus Biologicals | Catalog # NBP2-71556
![Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Western-Blot-NBP2-71556-img0002.jpg "Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]")
Key Product Details
Species Reactivity
Human, Mouse, Rat, Monkey
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, CyTOF-ready
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG2A Clone # OTI3B6
Format
Azide and BSA Free
Loading...
Product Specifications
Immunogen
Full length human recombinant protein of human GPHN (NP_065857) produced in HEK293T cell.
Reactivity Notes
Please note that this antibody is reactive to Mouse and derived from the same host, Mouse. Mouse-On-Mouse blocking reagent may be needed for IHC and ICC experiments to reduce high background signal. You can find these reagents under catalog numbers PK-2200-NB and MP-2400-NB. Please contact Technical Support if you have any questions.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG2A
Theoretical MW
83.3 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free
Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]
Western Blot: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - HEK293T cells were transfected with the pCMV6-ENTRY control (Left lane) or pCMV6-ENTRY Gephyrin (Right lane) cDNA for 48 hrs and lysed. Equivalent amounts of cell lysates (5 ug per lane) were separated by SDS-PAGE and immunoblotted with anti-Gephyrin.![Immunocytochemistry/ Immunofluorescence: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Immunocytochemistry-Immunofluorescence-NBP2-71556-img0005.jpg "Immunocytochemistry/ Immunofluorescence: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Immunocytochemistry/ Immunofluorescence: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Immunocytochemistry/Immunofluorescence: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Staining of COS7 cells transiently transfected by pCMV6-ENTRY Gephyrin.![Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Immunohistochemistry-NBP2-71556-img0008.jpg "Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Staining of paraffin-embedded Human liver tissue using anti-Gephyrin mouse monoclonal antibody.![Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Flow-Cytometry-NBP2-71556-img0004.jpg "Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - HEK293T cells transfected with either overexpression plasmid (Red) or empty vector control plasmid (Blue) were immunostaining by anti-Gephyrin antibody, and then analyzed by flow cytometry.![Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Western-Blot-NBP2-71556-img0001.jpg "Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]")
Western Blot: Gephyrin/GPHN Antibody (OTI3B6)Azide and BSA Free [NBP2-71556]
Western Blot: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Analysis of extracts (35ug) from 9 different cell lines by using anti-Gephyrin monoclonal antibody.![Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Immunohistochemistry-NBP2-71556-img0006.jpg "Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Staining of paraffin-embedded Adenocarcinoma of Human colon tissue using anti-Gephyrin mouse monoclonal antibody.![Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Immunohistochemistry-NBP2-71556-img0007.jpg "Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Staining of paraffin-embedded Adenocarcinoma of Human ovary tissue using anti-Gephyrin mouse monoclonal antibody.![Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Immunohistochemistry-NBP2-71556-img0009.jpg "Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Immunohistochemistry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Staining of paraffin-embedded Human prostate tissue using anti-Gephyrin mouse monoclonal antibody.![Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]](https://resources.rndsystems.com/images/products/Gephyrin-GPHN-Antibody-OTI3B6-Azide-and-BSA-Free-Flow-Cytometry-NBP2-71556-img0003.jpg "Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]")
Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556]
Flow Cytometry: Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free [NBP2-71556] - Analysis of Jurkat cells, using anti-Gephyrin antibody, (Red), compared to a nonspecific negative control antibody (Blue).Applications for Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free
Application
Recommended Usage
Flow Cytometry
1:100
Immunocytochemistry/ Immunofluorescence
1:100
Immunohistochemistry
1:150
Western Blot
1:500-2000
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Reconstitution
we recommend adding 100uL distilled water to a final antibody concentration of about 1 mg/mL. To use this carrier-free antibody for conjugation experiment, we strongly recommend performing another round of desalting process.
Formulation
Lyophilized from PBS (pH 7.3) with 8% Trehalose
Format
Azide and BSA Free
Preservative
No Preservative
Concentration
LYOPH mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Calculators
Background: Gephyrin/GPHN
Alternate Names
GEPH, GPH, GPHN, GPHRYN
Gene Symbol
GPHN
Additional Gephyrin/GPHN Products
Product Documents for Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for Gephyrin/GPHN Antibody (OTI3B6) - Azide and BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
