HLA DMA Antibody (5C9NB) - BSA Free

Novus Biologicals | Catalog # NBP2-44300

Novus Biologicals
Loading...

Key Product Details

Species Reactivity

Human

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow (Cell Surface), Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG1 kappa Clone # 5C9NB

Format

BSA Free
Loading...

Product Specifications

Immunogen

Partial recombinant human HLA DMA protein (between amino acids 10-300) [Entrez NP_006111]

Localization

Membranes of Late Endosomes / Lysosomes

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1 kappa

Scientific Data Images for HLA DMA Antibody (5C9NB) - BSA Free

Western Blot: HLA DMA Antibody (5C9NB)BSA Free [NBP2-44300]

Western Blot: HLA DMA Antibody (5C9NB)BSA Free [NBP2-44300]

Western Blot: HLA DMA Antibody (5C9NB) [NBP2-44300] - Western blot analysis of HLA DMA (5C9NB) in A. partial recombinant human HLA DMA protein B. Ramos lysate and C. Raji lysate.
Immunocytochemistry/ Immunofluorescence: HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Immunocytochemistry/ Immunofluorescence: HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Immunocytochemistry/Immunofluorescence: HLA DMA Antibody (5C9NB) [NBP2-44300] - Daudi cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X TBS + 0.5% Triton-X100. The cells were incubated with MHC Class II (5C9NB) at a 1:40 dilution for 1 hour at room temperature and detected with Dylight 488 (Green). Actin was detected using Phalloidin 568 (Red). Nuclei were detected using DAPI (Blue). Cells were imaged using a 40X objective.
Immunohistochemistry: HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Immunohistochemistry: HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Immunohistochemistry: HLA DMA Antibody (5C9NB) [NBP2-44300] - IHC analysis of a formalin fixed and paraffin embedded tissue section of normal human tonsil using 1:200 dilution of HLA DMA antibody (clone 5C9NB). The antibody generated a diffused to punctate staining in cellular membranes and cytoplasm, especially in the perinuclear region representing late endosomal localization of major histocompatibility complex, class II, DM alpha/HLA DMA protein.
Flow (Cell Surface): HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Flow (Cell Surface): HLA DMA Antibody (5C9NB) - BSA Free [NBP2-44300]

Flow (Cell Surface): HLA DMA Antibody (5C9NB) [NBP2-44300] - Analysis using the Azide Free version of NBP2-44300. Detection of Human PBMC cells (surface) with HLA DMA (5C9NB) antibody (red) or isotype control (mouse IgG1; green). Blue line represents cells alone. Positive staining was observed using PE conjugated mouse anti-IgG(H+L) secondary antibody. Live cells were gated (FL-2) for analysis.

Applications for HLA DMA Antibody (5C9NB) - BSA Free

Application
Recommended Usage

Flow (Cell Surface)

2.5 ug / million cells

Immunocytochemistry/ Immunofluorescence

1:50 - 1:100

Immunohistochemistry

1:200

Immunohistochemistry-Paraffin

1:200

Western Blot

1:500

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: HLA DMA

HLA-DMA belongs to the HLA class II alpha chain paralogues. This class II molecule is a heterodimer consisting of an alpha (DMA) and a beta chain (DMB), both anchored in the membrane. It is located in intracellular vesicles. DM plays a central role in the peptide loading of MHC class II molecules by helping to release the CLIP molecule from the peptide binding site. Class II molecules are expressed in antigen presenting cells (APC: B lymphocytes, dendritic cells, macrophages). The alpha chain is approximately 33-35 kDa and its gene contains 5 exons. Exon one encodes the leader peptide, exons 2 and 3 encode the two extracellular domains, exon 4 encodes the transmembrane domain and the cytoplasmic tail.

Alternate Names

class II histocompatibility antigen, M alpha chain, D6S222E, DMA, HLA class II histocompatibility antigen, DM alpha chain, major histocompatibility complex, class II, DM alpha, MHC class II antigen DMA, Really interesting new gene 6 protein, RING6HLADM

Gene Symbol

HLA-DMA

Additional HLA DMA Products

Product Documents for HLA DMA Antibody (5C9NB) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for HLA DMA Antibody (5C9NB) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Customer Reviews for HLA DMA Antibody (5C9NB) - BSA Free

There are currently no reviews for this product. Be the first to review HLA DMA Antibody (5C9NB) - BSA Free and earn rewards!

Have you used HLA DMA Antibody (5C9NB) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for HLA DMA Antibody (5C9NB) - BSA Free (NBP2-44300):

HLA DMA Antibody (5C9NB):
Immunocytochemistry Protocol

Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.

1. Remove culture medium and add 10% formalin to the dish. Fix at room temperature for 30 minutes.
2. Remove the formalin and add ice cold methanol. Incubate for 5-10 minutes.
3. Remove methanol and add washing solution (i.e. PBS). Be sure to not let the specimen dry out. Wash three times for 10 minutes.
4. To block nonspecific antibody binding incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
5. Add primary antibody at appropriate dilution and incubate at room temperature from 2 hours to overnight at room temperature.
6. Remove primary antibody and replace with washing solution. Wash three times for 10 minutes.
7. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
8. Remove antibody and replace with wash solution, then wash for 10 minutes. Add Hoechst 33258 to wash solution at 1:25,0000 and incubate for 10 minutes. Wash a third time for 10 minutes.
9. Cells can be viewed directly after washing. The plates can also be stored in PBS containing Azide covered in Parafilm (TM). Cells can also be cover-slipped using Fluoromount, with appropriate sealing.

*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.

HLA DMA Antibody (5C9NB):
1. Deparaffinize the tissue sections by immersing the slides in Xylene with two changes for 10 min each. Sections should not get dried at any stage from this point.
2. Rehydrate the tissue sections by immersing the slides in decreasing grades of ethanol as follows:
a. Immerse in 100% ethanol with 2 changes for 5 minutes each
b. Immerse in 95% ethanol with 2 changes for 5 minutes each
c. Immerse in 90% ethanol for 5 minutes
d. Immerse in 70% ethanol for 5 minutes
e. Immerse in 50% ethanol for 5 minutes
f. Immerse in distilled water for 5 minutes
3. Antigen Retrieval (Microwave Method):
a. Immerse the slides in a microwave compatible tray containing 10 mM Sodium Citrate buffer (pH 6.0) with 0.05% Tween 20.
b. Boil the slides and maintain the sub-boiling temperature for 5 minutes in the microwave. Thereafter, take out the tray very carefully and cool it at room temperature (RT) for about 30 minutes.
c. Wash the slides 3 times, 3 minutes each by immersing them in TBST (Tris Buffered Saline having 0.05% Tween 20).
4. Quenching of Endogenous Peroxidase:
a. Incubate the slides in 3% hydrogen peroxide prepared in methanol for 15 minutes (at RT, in dark conditions).
b. Wash the slides in TBST 3 times, 3 minutes each.
5. Protein Blocking:
a. Incubate the sections with background sniper solution at RT for 15 minutes (Biocare Medicals, USA).
b. Wash the sections 3 times, 3 min each by immersing the slides in TBST.
6. Primary Antibody:
a. Dilute the primary antibody at 5ug/ml concentration using PBS as a diluent.
b. Incubate the sections with diluted primary antibody for 90 minutes at RT in a humidified chamber.
c. Thereafter, wash the slides 4 times, 5 minutes each with TBST.
7. Probe (Secondary Reagent):
a. Incubate with MACH 1 Mouse probe for 15 minutes at RT.
b. Incubate for 30 min at room temperature with HRP-Polymer (Biocare Medical, USA).
c. Wash the slides with TBST 4 times, 5 minutes each
8. Chromogen:
a. Mix 32ul of DAB Chromogen with 1 ml of DAB substrate buffer (Biocare Medical, USA).
b. Apply 200ul DAB mixture/section and incubate at RT in dark conditions (few seconds - 5 minutes).
c. As soon as an appropriate color develops, rinse the slides with deionized water (2-3 brief rinses).
9. Counter stain:
a. Counter stain with Hematoxylin for 30 seconds (Vector Labs, USA).
b. Wash in deionized water for 1-2 minutes to clear the extra stain.
c. Incubate the slides in bluing solution or Scott's water twice for 2 minutes each time.
10. Dehydrate the sections in increasing grades of alcohols:
a. 50% alcohol for 1 minute
b. 70% for 1 minute
c. 90% for 1 minute
d. 95% for 1 minute
e. 100% for 1 minute
f. Xylene with 2 changes for 2 minutes each
11. Mount with DPX mount and cover-slip glass (Fisher Scientific, USA), carefully not allowing any air bubbles to enter.

NOTE:- This protocol is provided as a reference tool only. Depending upon the type of tissues /tissue processing and reagents employed, the end user will need to optimize the final conditions for achieving an expected staining.

HLA DMA Antibody (5C9NB):
1. Perform SDS-PAGE on samples to be analyzed, loading 25 ug of total protein per lane.
2. Transfer proteins to membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain according to standard Ponceau S procedure (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot.
5. Block the membrane using standard blocking buffer for at least 1 hour.
6. Wash the membrane in wash buffer three times for 10 minutes each.
7. Dilute anti-HLA DMA primary antibody in blocking buffer and incubate 1 hour at room temperature.
8. Wash the membrane in wash buffer three times for 10 minutes each.
9. Apply the diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturers instructions) and incubate 1 hour at room temperature.
10. Wash the blot in wash buffer three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
Note: Tween-20 can be added to the blocking or antibody dilution buffer at a final concentration of 0.05-0.2%.
