Key Product Details
Species Reactivity
Human, Mouse
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, ELISA, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgM Clone # 2E1/53
Loading...
Product Specifications
Immunogen
Human placental HSP60.
Epitope
Epitope mapping studies using human Hsp 60 deletion mutants suggest that this antibody binds between amino acids 211-288.
Reactivity Notes
Cross-reactivity with Mouse, Rat and Monkey.
Localization
Mitochondrial/chloroplast
Marker
Mitochondria Marker
Specificity
Detects Hsp 60 from human cells, tissues and recombinant protein preparations. This displays no other protein or species cross-reactivity.
Clonality
Monoclonal
Host
Mouse
Isotype
IgM
Description
Novus Biologicals Mouse HSP60 Antibody (2E1/53) (NB120-5479) is a monoclonal antibody validated for use in IHC, WB, ELISA, ICC/IF and IP. All Novus Biologicals antibodies are covered by our 100% guarantee.
Scientific Data Images for HSP60 Antibody (2E1/53)
Western Blot: HSP60 Antibody (2E1/53) [NB120-5479]
Western Blot: HSP60 Antibody (2E1/53) [NB120-5479] - Analysis of Heat Shock Protein 60 (HSP 60) was performed by loading 50ug of the indicated whole cell lysates onto a 4-20% Tris-HCl polyacrylamide gel. Proteins were transferred to a PVDF membrane and blocked with 5% BSA/TBST for at least 1 hour. The membrane was probed with a HSP60 monoclonal antibody at a concentration of 1ug/ml overnight at 4C on a rocking platform, washed in TBS-0.1%Tween 20, and probed with a goat anti-mouse IgM secondary antibody at a dilution of 1:20,000 for at least 1 hour. Chemiluminescent detection was performed using SuperSignal West Pico.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Analysis of Heat Shock Protein 60 (HSP60) (green) in HeLa and NIH3T3 cells.Immunohistochemistry-Paraffin: HSP60 Antibody (2E1/53) [NB120-5479]
Immunohistochemistry-Paraffin: HSP60 Antibody (2E1/53) [NB120-5479] - Both normal and cancer biopsies of deparaffinized Human breast carcinoma tissues.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Anlysis of Hela Cells at a dilution of 1:200Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Formalin-fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 5-10 minutes at room temperature and blocked with 3% BSA-PBS for 30 minutes at room temperature. Cells were probed with a Heat Shock Protein 60 monoclonal antibody (2E1/53) at a dilution of 1:100 and incubated overnight in a humidified chamber. Cells were washed with PBST and incubated with a DyLight-conjugated secondary antibody for 45 minutes at room temperature in the dark. F-actin (red) was stained with a fluorescent phalloidin and nuclei (blue) were stained with DAPI.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Formalin-fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 5-10 minutes at room temperature and blocked with 3% BSA-PBS for 30 minutes at room temperature. Cells were probed with a Heat Shock Protein 60 monoclonal antibody (2E1/53) at a dilution of 1:20 and incubated overnight in a humidified chamber. Cells were washed with PBST and incubated with a DyLight-conjugated secondary antibody for 45 minutes at room temperature in the dark. F-actin (red) was stained with a fluorescent phalloidin and nuclei (blue) were stained with DAPI.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with a Heat Shock Protein 60 (Hsp60) monoclonal antibody at a dilution of 1:100 overnight at 4 C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody staining (green), F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with a Heat Shock Protein 60 (Hsp60) monoclonal antibody at a dilution of 1:100 overnight at 4 C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody staining (green), F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown.Immunocytochemistry/ Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479]
Immunocytochemistry/Immunofluorescence: HSP60 Antibody (2E1/53) [NB120-5479] - Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with a Heat Shock Protein 60 (Hsp60) monoclonal antibody at a dilution of 1:200 overnight at 4 C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody staining (green), F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown.Immunohistochemistry-Paraffin: HSP60 Antibody (2E1/53) [NB120-5479]
Immunohistochemistry-Paraffin: HSP60 Antibody (2E1/53) [NB120-5479] - Both normal and cancer biopsies of deparaffinized Human kidney tissue tissues.Immunoprecipitation: HSP60 Antibody (2E1/53) [NB120-5479]
Immunoprecipitation: HSP60 Antibody (2E1/53) [NB120-5479] - Analysis of Heat Shock Protein 60 (HSP60) was performed on HeLa cells. Antigen-antibody complexes were formed by incubating 500ug of whole cell lysate with 2ug of a HSP60 monoclonal antibody overnight on a rocking platform at 4C. The immune complexes were captured on 50ul Protein A/G Plus Agarose, washed extensively, and eluted with 5X Lane Marker Reducing Sample Buffer. Samples were resolved on a 4-20% Tris-HCl polyacrylamide gel, transferred to a PVDF membrane, and blocked with 5% BSA/TBST for at least 1 hour. The membrane was probed with a HSP60 monoclonal antibody at a concentration of 1ug/ml overnight rotating at 4C, washed in TBST, and probed with a goat anti-mouse IgM secondary antibody at a dilution of 1:20,000 for at least 1 hour. Chemiluminescent detection performed using SuperSignal West Dura.Applications for HSP60 Antibody (2E1/53)
Application
Recommended Usage
ELISA
1 - 10 ug/ml
Immunocytochemistry/ Immunofluorescence
1:20 - 1:200
Immunohistochemistry
1 - 10 ug/ml
Immunohistochemistry-Paraffin
1 - 10 ug/ml
Immunoprecipitation
2 ug
Western Blot
1 - 10 ug/ml
Application Notes
WB: Detects an approx. 58 kDa protein.
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Reconstitution
Reconstitute with PBS.
Formulation
PBS with 1 mg/ml BSA
Preservative
0.05% Sodium Azide
Concentration
LYOPH mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at -20C. Avoid freeze-thaw cycles.
Calculators
Background: HSP60
Long Name
Heat Shock Protein 60
Alternate Names
cpn60, GROEL, HSPD1, SPG13
Entrez Gene IDs
3329 (Human)
Gene Symbol
HSPD1
Additional HSP60 Products
Product Documents for HSP60 Antibody (2E1/53)
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for HSP60 Antibody (2E1/53)
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
