Human CCL3/MIP-1 alpha Quantikine ELISA Kit

  (42 citations)
(1 Review)

Datasheet / CoA / SDS
Product Details
Assay Procedure
Citations (42)
FAQs
Supplemental Products
Reviews
  • Assay Type
    Solid Phase Sandwich ELISA
  • Format
    96-well strip plate
  • Assay Length
    3.5 hours or 4.5 hours
  • Sample Type & Volume Required Per Well
    Cell Culture Supernates (10 uL), Serum (200 uL), EDTA Plasma (200 uL), Heparin Plasma (200 uL), Citrate Plasma (200 uL)
  • Sensitivity
    10 pg/mL
  • Assay Range
    31.2 - 1,000 pg/mL (Cell Culture Supernates), 46.9 - 1,500 pg/mL (Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma)
  • Specificity
    Natural and recombinant human MIP-1 alpha
  • Cross-reactivity
    < 0.5% cross-reactivity observed with available related molecules.< 50% cross-species reactivity observed with species tested.
  • Interference
    No significant interference observed with available related molecules.
Control Available
QC20 , Quantikine Immunoassay Control Group 3 - Please Inquire
Product Summary
The Quantikine Human MIP-1 alpha Immunoassay is a 3.5 or 4.5 hour solid phase ELISA designed to measure MIP-1 alpha levels in cell culture supernates, serum, and plasma. It contains E. coli-expressed recombinant human MIP-1 alpha and antibodies raised against the recombinant protein. Results obtained for naturally occurring human MIP-1 alpha showed linear curves that were parallel to the standard curves obtained using the Quantikine kit standards. These results indicate that this kit can be used to determine relative mass values of natural human MIP-1 alpha.

Precision
Intra-Assay Precision (Precision within an assay) Three samples of known concentration were tested on one plate to assess intra-assay precision
Inter-Assay Precision (Precision between assays) Three samples of known concentration were tested in separate assays to assess inter-assay precision
Cell Culture Supernates
Intra-Assay Precision Inter-Assay Precision
Sample 1 2 3 1 2 3
n 20 20 20 20 20 20
Mean 116 442 726 53.6 313 623
Standard Deviation 3.3 5.9 14 3.7 13.4 25.7
CV% 2.8 1.3 1.9 6.9 4.3 4.1

Serum, EDTA Plasma, Heparin Plasma, Citrate Plasma
Intra-Assay Precision Inter-Assay Precision
Sample 1 2 3 1 2 3
n 20 20 20 20 20 20
Mean 140 688 1084 50.7 306 613
Standard Deviation 12.5 60.4 55.4 5.9 15.1 37.8
CV% 8.9 8.8 5.1 11.6 4.9 6.2

Recovery

The recovery of MIP-1 alpha spiked to different levels in samples throughout the range of the assay in various matrices was evaluated.

Sample Type Average % Recovery Range %
Cell Culture Media (n=5) 100 88-117
Citrate Plasma (n=5) 94 85-104
EDTA Plasma (n=5) 96 81-109
Heparin Plasma (n=5) 98 82-121
Serum (n=5) 95 87-113
Linearity
To assess the linearity of the assay, samples were spiked with high concentrations of MIP-1 alpha in various matrices and diluted with the appropriate Calibrator Diluent to produce samples with values within the dynamic range of the assay.
 CCL3/MIP-1 alpha [HRP]
Product Datasheets

Certificate of Analysis Lookup

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Certificate of Analysis Lookup

Certificate of Analysis Request Form

To download a Certificate of Analysis, please enter the catalog and lot numbers in the search box below.

Note: Certificate of Analysis not available for kit components.

Preparation and Storage
  • Storage
    Store the unopened product at 2 - 8 °C. Do not use past expiration date.
Background: CCL3/MIP-1 alpha

MIP-1 alpha (macrophage inflammatory protein 1 alpha) is a member of the CC or beta chemokine subfamily that was originally purified from the conditioned media of an LPS-stimulated murine macrophage cell line. MIP-1 alpha acts as a chemoattractant to a variety of cells including monocytes, T cells, B cells and eosinophils.

The two human MIP-1 alpha genes arise by duplication/mutation. They code for MIP-1 alpha isoforms CCL3/LD78a and CCL3L1/LD78b, which share 94% amino acid sequence homology. Whereas the human CCL3/LD78a is a single-copy gene, the human CCL3L1/LD78b gene copy number varies within the population. Human CCL3L1/LD78b binds and signals through chemokine receptors CCR1, CCR5. When compared to CCL3/LD78a, CCL3L1/LD78b has higher binding affinity to CCR5, which also functions as a coreceptor for HIV-1 entry. The copy number of CCL3L1 is one of several genetic determinants of HIV-1 susceptibility.

  • Entrez Gene IDs:
    6348 (Human); 20302 (Mouse); 25542 (Rat); 448787 (Canine)
  • Alternate Names:
    C-C motif chemokine 3; MIP1-(a); AI323804; CCL3; chemokine (C-C motif) ligand 3; G0S19-1; LD78a; LD78alpha; MIP1 alpha; MIP-1 alpha; Mip1a; MIP-1alpha; MIP1-alpha; Scya3
Related Research Areas
Assay Procedure
Refer to the product for complete assay procedure.

Bring all reagents and samples to room temperature before use. It is recommended that all samples, standards, and controls be assayed in duplicate.
  1.   Prepare all reagents, standard dilutions, and samples as directed in the product insert.
  2.   Remove excess microplate strips from the plate frame, return them to the foil pouch containing the desiccant pack, and reseal.

  3. For Serum & Plasma Samples Only: Add 50 µL Assay Diluent
  4.   For Serum & Plasma Samples Only: Add 50 µL of Assay Diluent to each well.

  5. 200 µL Standard, Control, or Sample
  6.   Add 200 µL of Standard, control, or sample to each well. Cover with a plate sealer, and incubate at room temperature for 2 hours.
  7.   Aspirate each well and wash, repeating the process twice for a total of 3 washes.

  8. 200 µL Conjugate
  9.   Add 200 µL of Conjugate to each well.
  10.   For Serum & Plasma Samples: Cover with a new plate sealer, and incubate at room temperature for 2 hours.
    For Cell Culture Supernate Samples: Cover with a new plate sealer, and incubate at room temperature for 1 hour.
  11.   Aspirate and wash 3 times.

  12. 200 µL Substrate Solution
  13.   Add 200 µL Substrate Solution to each well. Incubate at room temperature for 20 minutes. PROTECT FROM LIGHT.

  14. 50 µL Stop Solution
  15. Add 50 µL of Stop Solution to each well. Read at 450 nm within 30 minutes. Set wavelength correction to 540 nm or 570 nm.
